- Page 1 Salamamder Heater With Cart OWNER’S MANUAL PS-10241P 10KW 240V 60Hz 1P PS-15243 15KW 240V 60Hz 3P PS-15203 15KW 208V 60Hz 3P PS-30483 30KW 480V 60Hz 3P IMPORTANT INSTRUCTIONS READ & SAVE Technical support: 1-866-206-0888 Service email: info@mecanair.net...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Important Instructions………………………………………..3-4 Specifications and Wiring Diagram………………………. .5-9 Parts of the heater ……………………….……………………10 Installing Instructions……………………….…………..…….11-12 Operating Instructions……………………….………..……..13 Maintenance and Cleaning……………………………………14 Warranty Information ………………………………………….14 ARRANTY INFORMATION... -
Page 3: Important Instructions
IMPORTANT INSTRUCTIONS PLEASE READ ALL INSTRUCTIONS BEFORE USING THIS HEATER NOTE: There may be a trace of smoke or odor when unit is first operated. Don’t be alarmed. This indicates that a drop of oil fell on the heating coil during the manufacturing process. It will quickly evaporate and should not re-occur. - Page 4 9) For floor standing by the cart, position it at a level floor; keep at least 4 feet (1.2m) from any adjacent vertical surface or walls. Keep at least 1 foot (0.3m) from the back wall. 10) Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this may cause an electric shock or fire, or damage the heater.
-
Page 5: Specifications And Wiring Diagram
SPECIFICATIONS Salamander Heater with cart Model: PS-10241 MANUFACTURER No.: PS-10241P Volt: 240 V, 1P Watts: 10KW Frequency: 60 Hz Wiring diagram:... - Page 6 Model: PS-15243 MANUFACTURER No.: PS-15243 Volt: 240 V, 3P Watts: 15KW Frequency: 60 Hz Wiring diagram:...
- Page 7 Model: PS-15203 MANUFACTURER No.: PS-15203 Volt: 208 V, 3P Watts: 15KW Frequency: 60 Hz Wiring diagram:...
- Page 8 Model: PS-30483 MANUFACTURER No.: PS-30483 Volt: 480 V, 3P Watts: 30KW Frequency: 60 Hz Wiring diagram:...
- Page 9 Wiring Instruction For 3 Phase Model: PS-30483 Open the cover. After connection. L1 (Live Wire1 White) L2 (Live Wire2 Black) L3 (Live Wire3 Red) Earth Wire...
-
Page 10: Parts Of The Heater
PARTS OF THE HEATER Handle Heater Housing C. Tilt adjustable knob D. Wheel Front Grill ON/OFF Switch G. Temperature Setting Knob... -
Page 11: Installing Instructions
INSTALLING INSTRUCTIONS WARNING: All wiring must be installed by a certified electrician according to the electrical safety. The heater must be grounded in accordance with all national and local building codes. All wiring procedures and connections shall be in accordance with the national and local codes having jurisdiction. - Page 12 INSTALLATION INSTRUCTION: 1. Open the package, take out the heater. 2. Loosen the four screws in the handle, move the handle to the upper of the cart stand. 3 Align the screw holes on the handle to the cart stand, re-insert the four screws and tighten.
-
Page 13: Operating Instructions
OPERATING INSTRUCTIONS WARNING - The heater must be properly installed before it is used. HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH : Apply appropriate personal protective equipment (PPE) and follow safe electrical work practices. See NFPA 70E. A circuit breaker must be installed and serviced only by qualified electrical personnel. -
Page 14: Maintenance And Cleaning
WARRANTY INFORMATION This product carries a one (1) year warranty against defects in workmanship and materials. Profusion Heat agrees to replace a defective product, within the stated warranty period, when returned to the place of purchase with proof of purchase. This product is not guaranteed against...
