freeConnect Smart
24-port Web Smart
Networking Switch
freeConnect Smart 2420 > 24-port 10/100 + 2
Combo SFP Web Smart switch
Networking switch: Affordable - manageable
The freeConnect Smart 2420 offers network manageability at
an affordable price. Designed for deployment at the network
edge, this versatile switch contains two gigabit ports for
connecting to backbone switches or directly to servers to
reduce traffic bottleneck, while its 10/100 ports connect up to
24 other devices to the network. The wire-speed backplane
combined with flow control further reduces any traffic conges-
tion on the switch.
The freeConnect Smart 2420 supports quality of service (QoS)
which gives latency-sensitive traffic such as multimedia, video
conferencing, and VoIP higher priority over standard traffic.
The switch also supports VLANs for network segmentation and
port trunking for increased bandwidth between switches.
Specifications
Standards
Ports
Transfer Rate
Power
Power Consumption
Network Cables
Filtering Address Table
Switching Fabric
Dimensions (w x h x d)
Temperature
Humidity
EMI
Model Numbers
Model Name
Description
Part Number
Revision 2.0 Specifications are subject to change without notice. Copyright 2007 Freedom9 Inc.
2420
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3x full-duplex flow control
24 x RJ-45 Auto-MDIX ports
2 x Shared RJ-45 Auto-MDIX ports/SFP slots
Ethernet 10Mbps/20Mbps Full-duplex
Fast Ethernet 100Mbps/200Mbps full-duplex
Gigabit Ethernet 2000Mbps full-duplex
100-240 VAC, 50/60 Hz
16W (Max.)
Ethernet - Cat 3, 4, 5, 6 UTP
Fast Ethernet - Cat 5, 6 UTP
Gigabit Ethernet - Cat 5e, 6 UTP, Multi or Singlemode
6K entries
Wire-speed non-blocking
17.3" x 1.7" x 5.5" (440 x 44 x 140 mm)
Operating 32°F - 104°F (0°C - 40°C)
Storage 14°F - 158°F (-10°C - 70°C)
Operating 10% - 90% RH
Storage 5% - 90% RH
FCC Class A/CE Mark A/VCCI-A
freeConnect Smart 2420
24-port 10/100 + 2-port Combo SFP Web Smart Switch
S102411200
Features:
• 24 10/100Mbps Auto-Negotiation Ethernet
ports
• 2 Gigabit ports supporting copper and fiber
interfaces
• Supports Auto-MDI/MDIX for each port
• Supports Full/Half-Duplex transfer mode
for 10 and 100Mbps
• Full wire speed reception and transmission
• Web-based management
• Port-based VLAN
• Port-based QoS
• Port trunking and Mirroring
www.freedom9.com
1-888-998-9189
