- Page 1 User Manual Barcode label scale RLS Series Rongta Technology (Xiamen) Group Co., Ltd. www.rongtatech.com V1.0...
-
Page 2: Table Of Contents
Contents Introduction........................1 1. The Label scale’s specification................2 2. Features Summary....................3 2.1 Unique and powerful network..............3 2.2 Usage is easy to learn..................3 2.3 Advanced functions and durable quality............3 3. Label scale installation steps.................4 3.1 Installation...................... 4 3.2 The installation of the thermal label paper..........6 3.3 Keyboard...................... -
Page 3: Introduction
Introduction Thank you for choosing our Label scale RLS. In order to operate RLS correctly, User manual is detailed in function and operation method of RLS , which help user with doubt quickly when come up against mechanical fault . Rongta research, develop, produce and sale RLS independently, which is high-performance barcode label scale. -
Page 4: The Label Scale's Specification
1. The Label scale’s specification The weighing range and accuracy RLS1000/RLS1000A/RLS1000B/RLS1000C/RLS1000D Max weight: 6kg/15kg Min weight: 40g 0kg to 6kg * 0.002kg (e=2g) 6kg to 15kg * 0.005kg (e=5g) RLS1100/RLS1100A/RLS1100B/RLS1100C/RLS1100D Max weight: 15kg/30kg Min weight: 100g 0kg to 15kg * 0.005kg (e=5g) 15kg to 30kg * 0.010kg (e=10g) The accuracy grade: ... -
Page 5: Features Summary
2. Features Summary 2.1 Unique and powerful network Use the Ethernet interface technology and the data transfer rate has been improved drastically Advice: When you use the Ethernet interface, suggest using the shielded cable. 2.2 Usage is easy to learn Operate the PLU by single bond to make fast sales, and the front desk staff could use it without training. -
Page 6: Label Scale Installation Steps
3. Label scale installation steps 3.1 Installation RLS1000/RLS1000A/RLS1000B/RLS1100/RLS1100A/RLS1100B b.Put the air fittings inside c.Install the display bar a.Connect air fittings the display bar and put the tray d.Take up the tray the level tool under the tray. e.Adjust the feet to make the level tool inside the little circle... - Page 7 RLS1000C/RLS1000D/RLS1100C/RLS1100D c.Install the display bar a.Connect air fittings b.Put the air fittings inside the display bar d.Take up the tray the level tool under the tray. e.Adjust the feet to make the level tool inside the little circle...
-
Page 8: The Installation Of The Thermal Label Paper
3.2 The installation of the thermal label paper a. Open the side panel b. Take out the printer d. Remove first few labels, and then c. Open the print head loading the roll Thread the front of new label roll through the Press [] button to roll the label paper filter plate and wrap in pick-up clamp ,and close the printing head (As shown in the figure) -
Page 9: Keyboard
3.3 Keyboard Press [] button to adjust label position and long press [] button to align paper. RLS1000/RLS1000A/RLS1100/RLS1100A/RLS1000C/RLS1100C/RLS1000D/RLS1100D keyboard RLS1000B/RLS1100B keyboard 3.4 Description of label paper The label which is used at RONGTA Label Scale is: Thermal Seam Marking Label. As shown below: Height：60mm，width：(30~60)mm，Max outside diameter: 100mm，Minimum inner diameter：40mm or 26.8mm. -
Page 10: Overall Appearance
4. Overall Appearance a. Host b. Tray c. Display group(A liquid crystal display, display bar, the four screws) d. Thermal label paper e. One fuses User manual g. Serial cable h. Power cable RLS1000A/RLS1100A RLS1000/RLS1100 Physical appearance: 437 372 523mm Physical appearance: 437 372... -
Page 11: Common Easy-To -Use Operations
5. Common easy-to -use operations 5.1 Switch on and off Hard disk switch on/turn on: After connecting power supply, switch on the power button at the bottom of the scale. After the screen shows one by one the information of edition No., IP address, self-test countdown “0 、1、2、……8”,the scale enter into sale pattern. -
Page 12: Tare Operation
224 hotkeys in total and is changeable and can be printed by control PC. The above operation is suitable for hotkey 1-112; as for hot button 113-224, the operation is pressing the button [PLU] + the corresponding hotkey. For easy operation, all the PLU can print the latest illustration. -
Page 13: Price Changing
5.5 Price Changing 5.5.1 Permanent Changing Method 1: Example: before changing, apple's unit price is €4.00/kg, after changing, its unit price is €3.00/kg. And hotkey is 05. Steps: press the apple's hoykey 05 press button[PRICE] input new price €3.00/kg press button[PRN/ENTER] weighing and pricing Method 2: Example: before changing, apple's unit price is €4.00/kg, after changing, its unit price is €3.00/kg. -
Page 14: Price Tag Printing
for multiple items-Method 1: input item's quantity(number) press button[UNIT/X] input single item's price press button[NET CHECK/SET AMT] input relevant item's fresh commodity code (or press the hotkey) (P.S.in the non-auto printing status, you need to press button[PRN/ENTER] ) for multiple items-Method 2: input single item's price press button[NET CHECK/SET AMT] input item's quantity(number) -
Page 15: Wireless Label Scale Setting Instruction
Discount: Enter the discount rate (e.g.: enter 80 for 80% discount) and press button [DISCOUNT] to calculate Enter hotkey of the goods put good on the scale and start printing Zero: press button [ZERO] to make zero of all the data. ... -
Page 16: Computer Rls1000 Software Settings
6.4 Computer RLS1000 software settings Set label scale corresponding to the IP address, after setting, Use software’s “test network” icon for network testing, then connectivity can be normal communication, if it’s failure, please check and make sure PC’s IP address is in the same segment. 7. - Page 17 Set menu items as below: @ IP address: set IP address of label scale. D print density set: press []/[] to select 0~7,from low to high, total 8 levels. V print speed set: press []/[] to select 0~7, from low to high, total 8 levels. ...
-
Page 18: Lock
7.3 Lock SETTING, PLU, DISCOUNT, PRICE, and TARE functions can be locked via pass code. Password of each function is independent, which can be set via pc software then download to each scale, and it can be change at any time. more details please check the security item in the function setting II which is in the software operating instructions . -
Page 19: Troubleshooting
Troubleshooting 8.1 Scales crash Boot up without any response Reasons: a. Bad contact between the power plug and socket. b. The power cord is disconnected. c. Filtering group Fuse is disconnected. d. Transformer is broken. e. Motherboard is broken. Solutions: use millimeter to check them one by one, use method of exclusion to find the solution. - Page 20 Print half or a half label, paper orientation is abnormal. Reasons: a. Set paper type detection error. b. Printer rear photoelectric has slanting direction or is dust. c. Photovoltaic panels was damage. d. Photoelectric pair of printer rear photoelectric is bad. Solutions: a.
- Page 21 3. Take a clean cotton swab dipping alcohol and cleaning the roller back and forth. Fuzzy print and it is not black enough Reasons: a. Printer head has not been fasten well. b. Thermal head is dirty. c. Print density is too low. Solutions: a.
-
Page 22: The Key Issues
Weird character show on label or character can’t be printed out(including Chinese and English) Reasons: a. Haven’t download fonts or single-byte character. b. Font conflict. Solutions: a. Re-download fonts (including single-byte and double-byte character.) b. Re-select single-byte and double-byte fonts by files/option/label scale fonts, then download Chinese and English fonts. -
Page 23: Communication Problem
Solutions: a. Check the top cover is installed well, or not. If yes, reinstall load cell’s support frame. b. Leaning the Zero/Full weigh again. Replace the mainboard, AD board, even load cell if the problem could not be solved. c. Replace the load cell and support frame. d. -
Page 24: Display Problem
Solutions: a. Confirm the available communication ports. b. Confirm the same serial number in scale and RLS1000, and same IP address in scale and RLS1000. c. Check if the network cable is damaged and the network port is securely inserted. d. -
Page 25: Other Problems
8.8 Other problems Print paper difficultly, paper roll fixed. Reasons：Maybe the mismatch between paper roll and shaft, or the wrong installation of shaft. Solutions：It is better to return this printer to factory for reinstallation. “KaKa” sound when printing, don’t feed paper(note: if appear this problem, please don't ... -
Page 26: The Acceleration Of Gravity Revised Table
9. The acceleration of gravity revised table COUNTRY CITY G(m/sec COUNTRY CITY G(m/sec Greece Athens 9.800 Scotland Glasgow 9.816 South Africa Cape town 9.796 Spain Madrid 9.800 Netherlands Amsterdam 9.813 Singapore Singapore 9.781 Norway Oslo 9.815 Argentina Buenos Aires 9.797 New Zealand Auckland,NZ 9.799...
