- Page 1 Model F3 User Manual Wall Mount Static Transfer Switch iSTS F3 – User Manual R02...
-
Page 2: Table Of Contents
6.8 Input Transient Settings 6.9 Output Settings 7. FAULT DIAG N OSIS 7.1 Fault Codes 7.2 Load Fault 8. R ECOM M EN DED M AIN TEN AN CE SCH EDULE 9. SPECIFICATION S iSTS F3 – User Manual Page 1... -
Page 3: Safety Instructions
▪ Once the connections have been made on the terminals, all terminal covers must be replaced before operation. ▪ Connecting cables must be supported. ▪ Earth connection must be checked for safe function after assembly. iSTS F3 – User Manual Page 2... -
Page 4: Maintenance Bypass
1.7 Warranty Static Power operating through its authorised agents warrants that the standard products will be free of defects in materials and workmanship for a period of 24 months after the date of invoice, or such other period as may be specified. -
Page 5: System Overview & Operation
2.2 Overview The iSTS is housed in a wall mounted IP54 rated enclosure. Repair is achieved in conjunction with the Maintenance Bypass Switch located at the bottom of the iSTS. iSTS F3 – User Manual Page 4... -
Page 6: Operational Parameters
*Due to the nature of the silicone controlled rectifiers used in all static transfer switches, some current must be applied to the iSTS to ensure a clean break during transfers. Overload Capacity Time @45°C 125% 150% 400% 0.1s 2000A 1 cycle 2.4 Line Diagram: Single phase/2-Poles iSTS F3 – User Manual Page 5... -
Page 7: Line Diagram: 3 Phases, Neutral Available And Not Switched
F3 2.5 Line Diagram: 3 Phases, Neutral available and not switched 2.6 Line Diagram: 3 Phases, Neutral switched iSTS F3 – User Manual Page 6... -
Page 8: Operation
This equipment is not suitable for installation into environments that utilise RCD earth leakage detectors on the inputs of the static transfer switch. Consult Static Power for special considerations. EARTH CONNECTION IS ESSENTIAL BEFORE WORKING ON CIRCUITS OR CONNECTING / DISCONNECTING SUPPLIES. -
Page 9: Installation
8. Apply power to the STS. After a few seconds the LED mimic will show the direction of power flow. When working on live iSTS, be sure to comply with the applicable national standards and accident prevention rules. iSTS F3 – User Manual Page 8... -
Page 10: Synchronism
- Supply 1 & 2 are not in synchronism - The unit is too hot (thermal bi-metal switch on H.S. activated) - There is / was an overcurrent/ overload / load fault condition iSTS F3 – User Manual Page 9... -
Page 11: User Interface
GREEN if load is Supply 1 ON SUPPLY 2 LED Load is on Supply 2 Load is not on Supply 2 GREEN if load is Supply 2 10 iSTS OUTPUT LED Output is OK Output is faulty GREEN iSTS F3 – User Manual Page 10... -
Page 12: User Interface Board
RED, variables display will show degrees out of synchronism. Only operate when less than 10 degrees). If the control is not operating you may need to use other means to determine that the supplies are in synchronism. Do not operate the OVERRIDE switch onto an absent supply. iSTS F3 – User Manual Page 11... -
Page 13: Remote Connection Port - High Density
15 to 14 Normally Closed ON A (Supply 1) 16 to 19 REMOTE CONTACT Emergency power off 17 to 19 REMOTE CONTACT Transfer to Supply 1 18 to 19 REMOTE CONTACT Transfer to Supply 2 iSTS F3 – User Manual Page 12... -
Page 14: Confirm Operation
To service the switch and before removing the internal Gal panel turn-off the isolators ion the terminal enclosure and remove the control fuses. This will not affect power flow to the load when in maintenance bypass. iSTS F3 – User Manual Page 13... -
Page 15: Reinstatement From Maintenance Bypass
IP Allocation to Static allows for manual input of IP address, subnet and gateway. If you have lost the IP address use a suitable App to scan for the set IP address of the STS. iSTS F3 – User Manual Page 14... -
Page 16: Connecting To A Pc
5 to 10 seconds and reconnect the cable, this in turn should re-register the device on the network. iSTS F3 – User Manual Page 15... -
Page 17: Control Panel
• Setting the preferred supply • Setting the name and location information • Adjusting the time and date • Setting the IP address NOTE: You must press update for the information to be saved on the device iSTS F3 – User Manual Page 16... - Page 18 The default settings is set to DHCP mode “On”, when this is set to “Off” then the other options become available to change. From here you can change the IP, Mask and the Gateway. After pressing update these details will be saved on the unit. iSTS F3 – User Manual Page 17...
-
Page 19: Email
This is where the email notification will be sent. It can be the same as the above email. Email List In this section you can select which event types should trigger an email notification to be sent. EMAIL SCREEN iSTS F3 – User Manual Page 18... -
Page 20: Advanced Settings
These settings should only be changed under the certain operating conditions and it is advised that you consult with us before doing so, as wrong settings can make the system unstable and damage equipment. iSTS F3 – User Manual Page 19... -
Page 21: Input Steady State Settings
(except manually) will occur without a break. Once the displacement between the two phases is more than this value, a break is inserted as defined by “Phase error detection break”. iSTS F3 – User Manual Page 20... -
Page 22: Input Transient Settings
NOTE: Adjustment may be required to the Transient values if the source supply voltages are distorted or above or below nominal. Setting too close a limit to the actual operating Steady State voltage may cause erratic Static Transfer Switch operation. iSTS F3 – User Manual Page 21... -
Page 23: Output Settings
150% for 10 seconds OR 200% for 1 second will not affect the critical load and no switching occurs. It is intended as a warning that the STS is overloaded. Failure to reduce the load will cause semiconductor failures. iSTS F3 – User Manual Page 22... -
Page 24: Fault Diagnosis
PREF 1/2/OFF Preferred Source Set 1, 2 or none User - Manual Switch Only Contact Static Power – Locks to safe SCR SC SCR on S1 or S2 short circuit detected on Supply 1 or 2 source Contact Static Power – Locks to safe... -
Page 25: Recommended Maintenance Schedule
Report / investigate any suspicious entries. ▪ Inspect cable connections for overheating. Contact Static Power for help with troubleshooting and parts replacement. NOTE: The user should not undertake repair procedures or gain access to the internal of the equipment. iSTS F3 – User Manual... -
Page 26: Specifications
IEC 62310-1,2,3 - IEC 60950 - IEC 61000-6-1,2,3,4 – CE – RCM - UL Capable - RoHS Standard warranty 24 months offsite repair or replacement policy Specifications are subject to change without notice iSTS F3 – User Manual Page 25... - Page 27 STATIC POWER Pty Ltd Post to: Manufactured at: Contact us: ABN 42 101 765 913 Box 2003 5 Candlebark Court +61 3 9437 0494 Research Delivery centre Research, VIC 3095 support@staticpower.com.au iSTS F3 – User Manual Research, VIC 3095 - Australia Australia www.staticpower.com.au...
