iSTS Model R User Manual Rail Mount Static Transfer Switch iSTS R – User Manual R02...
Page 2
STATIC POWER Pty Ltd Post to: Manufactured at: Contact us: ABN 42 101 765 913 Box 2003 5 Candlebark Court +61 3 9437 0494 Research Delivery centre Research, VIC 3095 support@staticpower.com.au R Research, VIC 3095 ‐ Australia Australia www.staticpower.com.au iSTS – User Manual...
R 1. SAFETY INSTRUCTIONS 1.1 Introduction Some aspects of this manuals contents may differ to the equipment as supplied due to technical improvements, specific model variations etc. If in any doubt in respect to the procedures and safety issues consult the manufacturer and do not proceed until clarification is received.
Halon must be used. Do not inhale vapours. 1.7 Standards Applied & Conformity The iSTS R conforms to the following standards and European Council Directives: Standards to which conformity declared: IEC 60950‐1 Information technology equipment Safety ‐ General requirements ...
The iSTS R is a 2 pole, single phase DIN Rail mount STS that suits 35mm x 7.5mm rail. Both the active conductor and the neutral are switched. Thyristors are used to undertake the switching process. These are many times faster and more reliable than their electromechanical equivalents.
2.3 Overview & Operations 7 9 10 13 14 N P ≠ N P N P Push‐in terminal suits 4mm² cable, use a small blade type screwdriver in the top slot and press in; insert 1 Supply 1 Input the cable and release. Repeat for the Neutral Conductor. Note the neutral is not fused. Bare the wire just 8mm. Push‐in terminal suits 4mm² cable, use a small blade type screwdriver in the top slot and press in; 2 Output Terminal insert the cable and release. Bare the wire just 8mm. When there is an alarm that has not been acknowledged this LEDs will flash.
The iSTS R is supplied with 2 Din Rail Mounted Fuse‐switch disconnectors complete with cylindrical fuse‐links (10x38 type aR ‐ 16/20A) and these should be placed adjacent to the “iSTS R”. Ensure that there is sufficient space between the iSTS and the fuse holders and adjacent equipment for cooling of the iSTS.
3.2 Synchronism The smoothest change‐over occurs when the supplies are in synchronism, so it is best to make sure the input supplies are in synchronism. Some equipment (like transformers) may saturate when a transfer occurs when not in synchronism. This causes large currents to flow into the load which could cause damage to the transformer, trip protective devices or blow fuses.
If the unit is inoperable then it should be returned to the manufacturer for repair or replacement. 3.8 Diagnostic Guide Before starting this guide it is important that you are familiar with the unit and have read the iSTS R User Manual.
Once every 6 months, (sooner if the environment is bad), vacuum dust from grills at top and bottom of unit. Inspect cable / plug connections for overheating. Please contact Static Power for help with troubleshooting and parts replacement. 5. SPECIFICATIONS Current rating...
Page 12
STATIC POWER Pty Ltd Post to: Manufactured at: Contact us: ABN 42 101 765 913 Box 2003 5 Candlebark Court +61 3 9437 0494 Research Delivery centre Research, VIC 3095 support@staticpower.com.au Research, VIC 3095 ‐ Australia Australia www.staticpower.com.au iSTS – User Manual...
