- Page 1 Model B1 User Manual 19-inch Rack Mount Static Transfer Switch iSTS B1 – User Manual R12...
- Page 2 STATIC POWER Pty Ltd Post to: Manufactured at: Contact us: ABN 42 101 765 913 Box 2003 5 Candlebark Court +61 3 9437 0494 Research Delivery centre Research, VIC 3095 support@staticpower.com.au Research, VIC 3095 - Australia Australia www.staticpower.com.au iSTS – User Manual...
-
Page 3: Table Of Contents
4.4 Control Panel 4.5 Email 4.6 Advanced Settings 4.7 Input Steady State Settings 4.8 Input Transient Settings 4.9 Output Settings 5. FAULT DIAGNOSIS 5.1 Fault Codes 5.2 Load Fault 6. RECOMMENDED MAINTENANCE SCHEDULE 7. SPECIFICATIONS iSTS B1 – User Manual Page 1... -
Page 4: Safety Instructions
▪ Once the connections have been made on the terminals, all terminal covers must be replaced before operation. ▪ Connecting cables must be supported. ▪ Earth connection must be checked for safe function after assembly. iSTS B1 – User Manual Page 2... -
Page 5: Fire Regulations
1.6 Warranty Static Power operating through its authorised agents warrants that the standard products will be free of defects in materials and workmanship for a period of 24 months after the date of invoice, or such other period as may be specified. -
Page 6: System Overview & Operation
The iSTS B1 is a 2 pole, single phase 1RU 19-inch rack mount iSTS with a maintenance bypass feature. Both the active conductor and the neutral are switched. Thyristors are used to undertake the switching process. These are many times faster and more reliable than their electromechanical equivalents. -
Page 7: Inputs & Output
Turns incoming Supply 2 ON or OFF. When switched OFF, power will not go through the STS 15 Supply 2 Isolator Switch* circuit and Supply 1 Okay LED will show red. *Optional features iSTS B1 – User Manual Page 5... -
Page 8: Operation
The standard iSTS B1 will contribute a maximum of 5mA to earth leakage (transiently & during switching between sources), this will itself not cause any tripping of the RCDs. The iSTS B1 has backfeed contactors to ensure that there is no or negligible earth leakage currents if a supply source is removed. -
Page 9: Installation
3. Confirm that the load is receiving power. Check that LEDs on the mimic are correctly representing the supply status and load. NOTE: Only the On Supply 1 LED or On Supply 2 LED should be red, not both. iSTS B1 – User Manual Page 7... -
Page 10: Display Screens
(Single phase units will only show L1) 2 Frequency Shows the frequency of the input supplies 3 Sync This is the difference between the frequencies of Supply 1 and 2 in degrees iSTS B1 – User Manual Page 8... - Page 11 IP Allocation can be set to Static and entered manually, or set to Dynamic (DHCP) where the device will be assigned an IP address automatically. Refer to the Web Interface section for instructions on accessing advance settings. iSTS B1 – User Manual Page 9...
-
Page 12: Remote Contacts
If connecting to this we recommend using a 20 way ribbon cable (length suitable for application) and a ribbon cable terminal break-out connector (not supplied) similar to that shown below The relays can switch up to 50V Remote contacts are wet contacts and do not require external voltage to be applied. iSTS B1 – User Manual Page 10... -
Page 13: Confirm Operation
Once the unit is in maintenance bypass mode on either Supply 1 or 2, the power module can be removed. To remove the module, make sure the bypass cradle is secure then use the tabs on the sides of the module to pull it out from the cradle. iSTS B1 – User Manual Page 11... - Page 14 The Supply 1 and 2 OK LEDs on the mimic will be green to indicate that both supplies are active in the STS. 3. Finally operate the bypass switch, returning it to the middle position. 4. The unit will now be normal operation mode. iSTS B1 – User Manual Page 12...
-
Page 15: Operational Parameters
Use navigation buttons on the unit and move to the Settings menu, enter the passcode 1 2 3 to access TCP/IP settings. Setting IP Allocation to Static allows for manual input of IP address, subnet and gateway. COMMUNICATION SETTINGS iSTS B1 – User Manual Page 13... -
Page 16: Connecting To A Pc
5 to 10 seconds and reconnect the cable, this in turn should re-register the device on the network. iSTS B1 – User Manual Page 14... - Page 17 • Setting the preferred supply • Setting the name and location information • Adjusting the time and date • Setting the IP address NOTE: You must press update for the information to be saved on the device iSTS B1 – User Manual Page 15...
-
Page 18: Control Panel
The default settings is set to DHCP mode “On”, when this is set to “Off” then the other options become available to change. From here you can change the IP, Mask and the Gateway. After pressing update these details will be saved on the unit. iSTS B1 – User Manual Page 16... -
Page 19: Email
This is where the email notification will be sent. It can be the same as the above email. Email List In this section you can select which event types should trigger an email notification to be sent. EMAIL SCREEN iSTS B1 – User Manual Page 17... -
Page 20: Advanced Settings
These settings should only be changed under the certain operating conditions and it is advised that you consult with us before doing so, as wrong settings can make the system unstable and damage equipment. iSTS B1 – User Manual Page 18... -
Page 21: Input Steady State Settings
(except manually) will occur without a break. Once the displacement between the two phases is more than this value, a break is inserted as defined by “Phase error detection break”. iSTS B1 – User Manual Page 19... -
Page 22: Input Transient Settings
NOTE: Adjustment may be required to the Transient values if the source supply voltages are distorted or above or below nominal. Setting too close a limit to the actual operating Steady State voltage may cause erratic Static Transfer Switch operation. iSTS B1 – User Manual Page 20... -
Page 23: Output Settings
150% for 10 seconds OR 200% for 1 second will not affect the critical load and no switching occurs. It is intended as a warning that the STS is overloaded. Failure to reduce the load will cause semiconductor failures. iSTS B1 – User Manual Page 21... -
Page 24: Fault Diagnosis
PREF 1/2/OFF Preferred Source Set 1, 2 or none User - Manual Switch Only Contact Static Power – Locks to safe SCR SC SCR on S1 or S2 short circuit detected on Supply 1 or 2 source Contact Static Power – Locks to safe... -
Page 25: Recommended Maintenance Schedule
▪ Units with fans need their fans changed every 3-5 years. This may need to be sooner if the environment is bad. Contact Static Power for help with troubleshooting and parts replacement. NOTE: The user should not undertake repair procedures or gain access to the internal of the equipment. -
Page 26: Specifications
Cooling Passive Humidity 5 – 90% non-condensing IP rating IP31 Compliance Regulatory AS/NZ3100, IEC 62310-1,2,3, 60950, 61000-6-1,2,3,4, CE Approval, RCM, UL Capable, RoHS Standard warranty 24 months off site repair or replacement policy iSTS B1 – User Manual Page 24... - Page 27 STATIC POWER Pty Ltd Post to: Manufactured at: Contact us: ABN 42 101 765 913 Box 2003 5 Candlebark Court +61 3 9437 0494 Research Delivery centre Research, VIC 3095 support@staticpower.com.au Research, VIC 3095 - Australia Australia www.staticpower.com.au iSTS – User Manual...
