- Page 1 Instructions for Use Simplex drain/overflow, flat version for standard bathtubs and for bathtubs with drain hole Ø52 Model Year built (from) 6168.46 07/2019...
-
Page 2: Table Of Contents
Table of contents Table of contents About these instructions for use 1.1 Target groups 1.2 Labelling of notes 1.3 About this translated version Product information 2.1 Intended use 2.1.1 Areas of use 2.2 Product description 2.2.1 Overview 2.2.2 Technical data Handling 3.1 Assembly information 3.1.1... -
Page 3: About These Instructions For Use
This restriction does not extend to possible operating instructions. The installation of Viega products must take place in accordance with the general rules of engineering and the Viega instructions for use. -
Page 4: About This Translated Version
About these instructions for use About this translated version This instruction for use contains important information about the choice of product or system, assembly and commissioning as well as intended use and, if required, maintenance measures. The information about the products, their properties and application technology are based on the current standards in Europe (e.g. -
Page 5: Product Information
Product information Product information Intended use 2.1.1 Areas of use NOTICE! Risk of damage due to unsuitable liquids To avoid damaging the drain, only introduce the following liquids: Typical household wastewater with temperatures up to 95 °C The pH value must be higher than 4 but lower than 10. The Simplex drain/overflow is a combined drain and overflow with odour trap for bathtubs with a 52 mm drain hole. -
Page 6: Product Description
Product information Product description 2.2.1 Overview Fig. 1: Component overview valve cone fixing screw valve top Sealing Sealing drain unit with odour trap Union nut with seal Bowden cable Flexible overflow pipe 10 overflow unit 11 profile seal 12 fixing flange 13 rotatable rosette Simplex drain/overflow, flat version... -
Page 7: Technical Data
Product information 2.2.2 Technical data Drainage capacity (at an accumu‐ 0.92 l/s lation height of 300 mm) Overflow capacity (at an accumu‐ 0.63 l/s lation height of 60 mm) Diameter of bathtub drain hole 52 mm Length of Bowden cable 725 mm Length / height 755 mm... -
Page 8: Handling
Handling Handling Assembly information 3.1.1 Mounting conditions The following requirements exist for the mounting of the drain / over‐ flow: The bathtub is installed. The drainage line is installed all the way to the bathtub. The underside of the bathtub is accessible. 3.1.2 Installation dimensions Fig. -
Page 9: Required Tools And Materials
Handling 3.1.3 Required tools and materials Tool The following tools are required for mounting: socket spanner (size 14) fine-toothed saw flat-blade screwdriver Material No additional material is required for the complete mounting of the product. Assembly 3.2.1 Mounting overflow Proceed as follows to the mounting of the overflow: ▶... -
Page 10: Connecting The Wastewater System
Fit the valve top in the drain hole. ▶ Place the fixing screw in the drain unit and tighten with a socket spanner (size 14) or a Viega mounting aid. ▶ Push the union nut, sliding ring and seal onto the bottom end of the overflow pipe. - Page 11 Viega Technology GmbH & Co. KG service-technik@viega.de viega.com INT • 2020-02 • VPN190429...
