CREE LIGHTING KBL Series Installation Instructions Manual

IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions should
always be followed including the following:
READ AND FOLLOW ALL SAFETY
INSTRUCTIONS
1. DANGER- Risk of shock- Disconnect power before installation.
DANGER - RISQUE DE CHOC - COUPER L'ALIMENTATION AVANT
L'INSTALLATION
2. This luminaire must be installed in accordance with the NEC or your
local electrical code. If you are not familiar with these codes and
requirements, consult a qualified electrician.
Ce produit doit être installé conformément à NEC ou votre code
électrique local. Si vous n'êtes pas familier avec ces codes et ces
exigences, veuillez contacter un électricien qualifié.
3. To reduce the risk of electric shock, disconnect both standard and
emergency power supplies and converter connector of the emergency
driver before servicing.
Pour réduire le risque de décharge électrique, vous devez déconnecter
à la fois le disjoncteur divisionnaire ou les fusibles et les alimentations
d'urgence avant l'entretien.
4. Do not use outdoors.
Ne pas utiliser à l'extérieur.
5. Do not let power supply cords touch hot surfaces.
Ne laissez pas les cordons d'alimentation toucher les surfaces chaudes.
6. Do not mount near gas or electric heaters.
Ne montez PAS près des appareils de chauffage de gaz ou électriques.
7. Equipment should be mounted in locations and heights where it will not
readily be subjected to tampering by unauthorized personnel.
L'équipement doit être monté dans des endroits et à des hauteurs où il
ne sera pas soumis à des altérations par des personnes non autorisées.
8. The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.
L'utilisation d'accessoires non recommandés par le fabricant peut causer une situation dangereuse.
9. Suitable for damp location.
Convient aux emplacements humides.
10. Maximum ambient operating temperature: 18L = 50°C and 24L, 25L, and 30L= 40°C.
Température ambiante maximale de fonctionnement: 18L = 50°C and 24L, 25L, and 30L= 40°C.
11. MIN 90°C SUPPLY CONDUCTORS
LES FILS D'ALIMENTATION 90°C MIN.
12. Check to make sure that all input power connections have been properly made and the module is grounded to avoid potential electrical shock.
13. This equipment should be installed and operated with a minimum distance 20cm between the radiator and your body.
L'équipement doit etre installe d'une facon qu'une distance minimum de 20cm soit maintenue entre l'emetteur et toute partie du corps.
14. Check to make sure that all input power connections have been properly made and the module is grounded to avoid potential electrical shock.
15. DO NOT lift luminaire by the power cord or any of the cables connected to the LED heatsink and LED driver.
16. All electrical connections for the sensor have been made at the factory.
17. The sensor is designed for mounting heights between 8 ft. to 40 ft. (2.4 m to 12.2 m). The handheld remote unit has a range of up to 40ft (12.2 m).
18. When mounting heights are above 30ft. (9.1 m), the sensor generally only detects large objects such as forklift trucks.
19. When the sensor lens assembly is removed the exposed sensor body is sensitive to electrostatic discharge. Take the necessary steps to avoid
possible damage to the sensor.
20. Use Class 1 Wiring methods ONLY
21. DO NOT lift luminaire by the cord.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
NOTES:
• For each mounting application below, when mounting to surface
ensure that the mounting surface and customer supplied
hardware is capable of supporting the weight of the luminaire.
• The center of mounting is NOT the same as the center of
luminaire.
• Images used in this installation sheet are for illustration purpose,
there are different configurations of the luminaire.
1 of 8
Wireless Highbay LED Luminaire with Emergency Driver
Universal Hook and Cord or Pendant Mount with Sensor
KBL EB
WIRELESS
KBL EB
WIRELESS
WITH NETWORK
SENSOR
Maximum Mounting Height in Feet
Lumen output With prismatic diffuser
18L-30L
KBL Series
INSTALLATION INSTRUCTIONS
INSTRUCTIONS D'INSTALLATION
With prismatic diffuser
and conic lens
44 33
LPN00814X0001A0_D
