INSTALLATION /
USER MANUAL
MONO BASIN MIXER WITH
POP-UP WASTE
Version 1, 1-9-19
KEEP FOR FUTURE REFERENCE
VECTA
Advertisement
Table of Contents
Related Manuals for VADO AXCES VECTA AX-VEC-100-CP
Summary of Contents for VADO AXCES VECTA AX-VEC-100-CP
- Page 1 KEEP FOR FUTURE REFERENCE VECTA This instruction booklet covers model: AX-VEC-100-CP INSTALLATION / USER MANUAL VADO Wedmore Road, Cheddar, Somerset, England BS27 3EB MONO BASIN MIXER WITH tel 01934 744466 fax 01934 744345 POP-UP WASTE www.vado.com sales@vado.com Version 1, 1-9-19...
- Page 2 Important - please read Contents of Packaging Please read these instructions carefully before starting installation and keep for future reference. Remove all packaging and check the product for missing parts or damage before starting installation. Any alterations made to this product and fittings may infringe water regulations and will invalidate the guarantee.
- Page 3 Dimensions Installation - Quick guide 148mm 175mm 1/2” 60mm...
- Page 4 Installation - Quick guide Installation Before installing your new mixer, flush through the pipe work to ensure removal of debris, turn off the water supply. Ensure the seal is in place in the bottom of the mixer body. Position the mixer on the basin. From the underside of the basin screw the two flexible pipes to the hot and cold connections in the mixer body, the hot...
- Page 5 Installation - Pop-up waste Operation Dissemble the pop-up waste and reassemble onto the basin. Control Insert the vertical control rod (with knob) down through the hole in the back of the mixer body and screw into the extension rod. Unscrew the ball joint retainer on the side of the pop-up waste body.
- Page 6 •The extended guarantee is only available if you have completed the Guarantee Registration Process. This can be done via the VADO website or via phone to our aftersales team. Registration must be completed within 6 months from date of purchase.
