Ambirad Vision Series Owner's Manual

Hl120v 60hz gas-fired, tubular, radiant, low-intensity infrared heater
Hide thumbs Also See for Vision Series:

Advertisement

Quick Links

Download this manual
Doc No 700105 (06-15), Page
INSTALLATION / OPERATION / MAINTENANCE
Applies to:
WARNING: Improper installation, adjustment,
alteration, service or maintenance can cause
property damage, injury or death. Read the
installation, operating and maintenance instructions
thoroughly
before
installing
Part # 700105
Model VPLUS HL120V 60Hz
Gas-Fired, Tubular, Radiant,
Low-Intensity Infrared Heater
Vision Range
VPLUS HL OWNERS MANUAL
or
servicing
this

Advertisement

loading
Need help?

Need help?

Do you have a question about the Vision Series and is the answer not in the manual?

Questions and answers

Related Manuals for Ambirad Vision Series

Summary of Contents for Ambirad Vision Series

  • Page 1 INSTALLATION / OPERATION / MAINTENANCE Model VPLUS HL120V 60Hz Applies to: Gas-Fired, Tubular, Radiant, Low-Intensity Infrared Heater Vision Range VPLUS HL OWNERS MANUAL WARNING: Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. Read the installation, operating and maintenance instructions thoroughly before...

  • Page 2: Installation Requirements

    Introduction. Welcome to the new range of powered HiLo and servicing is undertaken on radiant tube infra-red heaters. Local regulations may vary heaters specified in these instructions, due care and it is the installer’s responsibility to ensure and attention is required to ensure that working that such regulations are satisfied.
  • Page 3 accordance with Standard attachments to overhead steelwork etc. must Parking Structures, ANSI/NFPA 88A, or be purpose made to sound engineering practice the Standard for Repair Garages, ANSI/ or supplied by others. They must be adequately NFPA 88B, or the Canadian Natural Gas fixed and designed to carry the whole weight of the heater.
  • Page 4 ON VENTED HEATERS, THE HEATER SHOULD SLOPE DOWNWARDS AWAY FROM THE BURNER AND ON UNVENTED HEATERS SHOULD SLOPE DOWNWARDS TOWARDS BURNER BY APPROX. ½” FOR HORIZONTAL INSTALLATIONS AS SHOWN BELOW (DIAGRAMS EXAGGERATED FOR CLARITY) 1/2” ” VENTED UNVENTED Clearance to Combustibles. Minimum clearance to combustibles are shown in Table 1 below.
  • Page 5 Figure 2 Clearance to Combustibles (Standard indoor reflectors).. The minimum clearances to combustible materials are given in Table 1 These minimum distances MUST be adhered to at all times. Adequate clearance MUST be provided around air openings into the combustion chamber and there MUST be suitable clearance for accessibility and for combustion / ventilating air supplies.
  • Page 6 Figure 3. Correct orientation of Ball Valve Gas Connection and Supply WARNING: Before installation, check that the local distribution conditions, nature of gas and pressure, and adjustment of the appliance are compatible. Gas Flow The gas connection on the heater is ½” N.P.T internal thread.
  • Page 7 CONNECTOR MUST BE INSTALLED IN A “U” CONFIGURATION. FOR HEATERS UP TO 150,000 BTU/H, A 24” LONG CONNECTOR OF AT LEAST ½” ID MUST BE USED. FOR HEATERS ABOVE 150,000 BTU/H, A 36” LONG CONNECTOR OF AT LEAST ¾” NOMINAL ID MUST BE USED. Table 3 Gas Supply Pressures Gas Type Natural Gas...
  • Page 8 Figure 6a. Internal Burner Wiring Diagram. 24V Two stage Thermostat 24V AC Stat 120V AC Fan 120V AC KEY: Terminals Terminals Supply BL - BLUE BK - BLACK BR - BROWN GR - GREY G - GREEN K - PINK R - RED W - WHITE Y - YELLOW...
  • Page 9 The external two stage thermostat is connected 1.5.1 Multiple burner configurations (Master to the Master burner and powered via the inbuilt & Slave) via Optional Relay. transformer. The total burner load for the Master Refer to figure 6b and 6d. is 20VA.
  • Page 10 Figure 6d. Internal Slave Burner Wiring/External Schematic Diagram with Optional Relay. OPTIONAL RELAY WIRING COIL 24V AC RELAY 24V Two stage Thermostat Relay mini harness leads 24V AC Stat 120V AC Fan 120V AC KEY: Terminals Terminals Supply BL - BLUE BK - BLACK BR - BROWN GR - GREY...
  • Page 11 This protects building material from 1.6 Vent Requirements and Details degradation by the vent gasses. 1.6.1 Unvented units Vent joints should be sealed and secured according vent manufacturers Heaters may be installed unvented providing instructions. Should condensation occur the the governing building codes are met and vent should be shortened or insulated.
  • Page 12 Figure 7.a Vertical Venting. Approved Vent Cap Figure 7.b Horizontal Venting (plan view shown). Approved Vent Cap Note The vent terminal should be installed so as to be in the same atmospheric pressure zone as the combustion air inlet of the appliance. Note the vent terminal must NOT be installed below the fresh air Approved clearance thimble is required when the flue pipe...
  • Page 13 Technical Details - Table 5 No of Injectors ½” N.P.T Gas Connection 120 volt 1 phase 60Hz Electrical Supply 4” or 6” (101mm or 152mm) Vent size (in) 120 volt 1 phase 60Hz Unitary Fan Motor Details 1.8A MAX (models 40 - 150); 1.0A MAX (models 170 & 200) Current Rating Electronic Program Start up with Spark Ignition Ignition...

  • Page 14: Usa And Canada

    Technical Details continued USA & CANADA Natural Gas 0- 2000 ft (0-610m) Size 201063-24 201063-57 201063-77 201063-67 201063-23 201063-26 201063-78 Burner Orifice Plate Part No. Flame Plate Part No. 201957 202132 Fan Part No. 202483 201654 L200301 201425 L200244 202133 201911 Fan Orifice Part No.
  • Page 15 2. Assembly Instructions. PLEASE READ this section prior to Please ensure that all packaging is assembly to familiarize yourself with the disposed of in a safe environmentally components and tools you require at the friendly way. various stages of assembly. Carefully open the packaging and check the contents against the For your own safety we recommend the parts and check list.

  • Page 16: Suspension Bracket

    2.2.2.2 Where a heater configuration requires more than three turbulator strips and has the exhaust heat exchanger tube adjacent to an “L” or “U” heat exchanger tube, refer to the diagram below for positions. Slide the connected sections into the tube(s). specific configurations detailed...
  • Page 17 Moving between the two screws, tighten each 2.2.3.2 Reflector Support Brackets one in turn ensuring that equal pressure is applied to both. Complete assembly by drilling Reflectors are positioned above the emitter and screwing self tapping retention zip screws. tube with a reflector support bracket part #L201008-SUB RADIANT TUBE...
  • Page 18 These overlapped reflectors are allowed to 2.2.5 Reflectors. ‘float’ within the support bracket by leaving a reflectors must positioned/ minimum of 1/8” gap of the fixing screws before attached to the brackets exactly as tightening the locknuts. detailed in the assembly drawings. These are known as ‘slip’...
  • Page 19 Note: high wind applications additional drill screws to secure end cap to the reflector 2.2.7 Bend(s) (where fitted) The heater can be installed with 1 or 2 90° bends or a 180° U bend. Slide the bend into the open end of the Connect Electrical supplies...
  • Page 20 2.2.8.1 Model 200 S50 fan orifice plate 2.2.10 Detailed Assembly Drawings This model has a different fan orifice plate (Part following pages show technical No.202254) to all other models in the range. It dimensional details of the range of heaters. is supplied with every burner as a loose item and should be discarded if not needed.
  • Page 21 Figure 8. Possible Heater Orientations Doc No 700105 (06-15), Page 21...
  • Page 22 Figure 9. Heater Assembly: Model Linear 40-S10. Doc No 700105 (06-15), Page 22...
  • Page 23 Figure 10. Heater Assembly: Model Linear 40-S20 and 60-S20. Doc No 700105 (06-15), Page 23...
  • Page 24 Figure 11. Heater Assembly: Model Linear 60-S30, 80-S30, 100-S30 and 125-S30. Doc No 700105 (06-15), Page 24...
  • Page 25 Figure 12. Heater Assembly: Model Linear 60-S40, 80-S40, 100-S40, 125-S40 and 150-S40. Doc No 700105 (06-15), Page 25...
  • Page 26 Figure 13. Heater Assembly: Model Linear 125-S50, 150-S50, 170-S50 and 200-S50 Doc No 700105 (06-15), Page 26...
  • Page 27 Figure 14. Heater Assembly: Model Linear 150-S60, 170-S60 and 200-S60. Doc No 700105 (06-15), Page 27...
  • Page 28 Figure 15. Heater Assembly: Model Linear 170-S70 and 200-S70. Doc No 700105 (06-15), Page 28...
  • Page 29 Figure 16. Heater Assembly: Model U tube 40-U20 and 60-U20 3' 3" Doc No 700105 (06-15), Page 29...
  • Page 30 Figure 17. Heater Assembly: Model U tube 60-U40, 80-U40, 100-U40, 125-U40 and 150-U40. 3' 3" Doc No 700105 (06-15), Page 30...
  • Page 31 Figure 18. Heater Assembly: Model U tube 150-U60, 170-U60 and 200-U60. 3' 3" Doc No 700105 (06-15), Page 31...

  • Page 32: Start Up Instructions

    3. Start Up Instructions. These appliances should be commissioned by a qualified mechanical contractor. Tools Required. The following tools and equipment are advisable Suitable alternative tools may be used. to complete the tasks laid out in this manual. Large Adjustable Small Flat Leather Phillips...
  • Page 33 The high fire gas pressure should be set first followed by the low fire gas pressure. Re-check the high fire and re-adjust if necessary. To enable post purge ensure that the setting of any time switch and thermostat are such that the heating system will be required to turn off.
  • Page 34 Commissioning chart Check installation has Ensure gas and electricity Disconnect gas hose from been carried out to these supplies are isolated. burner instructions. Remove burner from tube and inspect burner head. (See servicing instructions) Reconnect gas hose. Open control housing and Replace burner on tube Open manual valve.

  • Page 35: Servicing Instructions

    4. Servicing Instructions. These appliances should be serviced annually by a competent person to ensure safe and efficient operation. In mildly dusty or polluted conditions more frequent servicing may be required. Servicing work should be carried out by a qualified mechanical contractor. to complete the tasks laid out in this manual.
  • Page 36 4.3 Burner Removal Step 1: Isolate power and gas supplies. Step 2: Disconnect the external power/control connections. Step 6: Remove the burner and position the burner in a safe area to prevent the burner or components attached to the burner from falling to the ground.
  • Page 37 Step 3: The gas injector can be inspected and replaced if contaminated or blocked. When replacing the gas injector ensure approved thread sealant is used. Step 4: Reconnect ignition leads and silicone tube to test nipple. Refit gasket and support casting.
  • Page 38 continued reliability. Detach the electrode 4.7 Radiant Tube Servicing assembly from the burner head by removing the two screws as shown and separating the Step 1: Brush any dust from the exterior of the igniter assembly lead connectors. tubes. Step 4: Refit the electrode assembly and Inspect the fan and burner tubes Step 2: ensure the connections are secure to prevent...

  • Page 39: Troubleshooting Guide

    5. Troubleshooting Guide. START Ensure gas & electricity supplies are enabled. Turn any external timer to call for heat (if fitted). CHECK: - Does the Power On Is there power to the 1. Transformer light illuminate? burner? 2. Integrity of wiring connections. 3.
  • Page 40 To aid in the troubleshooting process the UT controller has an LED flash code diagnostic sequence: Steady Off No control Power Steady On Power Applied, Control OK Combustion Pressure Switch Open With Blower On 1 Flash Combustion Pressure Switch Closed With Blower Off 2 Flashes Lockout From The Three Ignition Trials 3 Flashes...

  • Page 41: Replacing Parts

    6. Replacing Parts. Turn off gas and any electrical supplies to 6.2 Air Pressure Switch Replacement the heater before starting repair work. Step 1: Disconnect the two silicone tubes from the pressure switch. 6.1 Burner Controller Replacement Step 1: Remove the four screws securing the bottom access door.
  • Page 42 Step 5: Fit the new air pressure switch ensuring the tubes are connected as shown below. Step 5: Remove the four screws (circled) securing the gas valve inlet plate to the burner housing and remove plate. Step 6: Re-connect wiring. Step 7: Test product for correct operation, close access door.
  • Page 43 Notes: Doc No 700105 (06-15), Page 43...
  • Page 44 Website www.ambirad.com/us For the Distributor Nearest please call AmbiRad is a registered trademark of Nortek Global HVAC. Because of continuous product 1-888-330-4878 innovation, AmbiRad reserves the right to change product specification without due notice. Doc No 700105 (06-15), Page 44...
