Quick Links

Instruction Manual
4812325557EN
Operation and Maintenance
Pneumatic Tire Roller
CP2700
Diesel Engine
Cummins QSB 4.5 – Tier III
Cummins QSF 3.8 - Tier IV
Serial number
100005x2xxB005423
It is reserved the right to make any changes
Printed in Brazil
