EOM
T810
E n g i n e e r i n g
O p e r a t i o n &
™
Advanced
Series METAL Pumps
M a i n t e n a n c e
A d v a n c e y o u r p r o c e s s
WIL-11140-E-03
REPLACES WIL-11140-E-02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Wilden Advanced Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dover Wilden Advanced Series

Summary of Contents for Dover Wilden Advanced Series

  • Page 1 T810 E n g i n e e r i n g O p e r a t i o n & ™ Advanced Series METAL Pumps M a i n t e n a n c e A d v a n c e y o u r p r o c e s s WIL-11140-E-03 REPLACES WIL-11140-E-02...

  • Page 2: Table Of Contents

    T A B L E O F C O N T E N T S SECTION 1 CAUTIONS—READ FIRST! ..........1 SECTION 2 WILDEN PUMP DESIGNATION SYSTEM .

  • Page 3: Cautions-Read First

    S e c t i o n 1 C A U T I O N S — R E A D F I R S T ! CAUTION: Do not apply compressed air to the CAUTION: Pumps should be thoroughly fl ushed exhaust port —...

  • Page 4: Wilden Pump Designation System

    S e c t i o n 2 W I L D E N P U M P D E S I G N A T I O N S Y S T E M T810 ADVANCED™ LEGEND T810 / XXXXX / XXX / XX / XXX / XXXX METAL GASKETS...
  • Page 5 S e c t i o n 3 H O W I T W O R K S — P U M P The Wilden diaphragm pump is an air-operated, positive displacement, self-priming pump. These drawings show fl ow pattern through the pump upon its initial stroke.

  • Page 6: Dimensional Drawing

    S e c t i o n 4 D I M E N S I O N A L D R A W I N G T 810 A DVANC ED ™ M E TA L DIMENSIONS ITEM METRIC (mm) STANDARD (inch) 21.8 17.8...

  • Page 7: Rubber

    S e c t i o n 5 A P E R F O R M A N C E T810 ADVANCED™ METAL RUBBER-FITTED Height ......... 508 mm (20.0") Width ........554 mm (21.8") Depth ........386 mm (15.2") Est. Ship Weight ... Aluminum 40 kg (89 lbs) Cast Iron 60 kg (133 lbs) Air Inlet ........19 mm (3/4") Inlet ..........
  • Page 8 S e c t i o n 6 S U G G E S T E D I N S T A L L A T I O N Wilden pumps are designed to meet the performance they usually reduce pump performance. requirements of even the most demanding pumping ELEVATION: Selecting a site that is well within the pump’s applications.
  • Page 9 S U G G E S T E D I N S T A L L A T I O N NOTE: In the event of a power failure, the shut off valve AIR OPERATED PUMPS: To stop the pump from should be closed, if the restarting of the pump is not operating in an emergency situation, simply close the desirable once power is regained.
  • Page 10 S U G G E S T E D O P E R A T I O N & M A I N T E N A N C E OPERATION: The Turbo-Flo™ pump is is a non lube free The Pro-Flo ®...

  • Page 11: Disassembly / Reassembly

    S e c t i o n 7 P U M P D I S A S S E M B L Y T O O L S R E Q U I R E D : CAUTION: Before any maintenance or repair is attempted, the compressed air line to the pump should be disconnected and all air pressure allowed to bleed from the •...

  • Page 12: Using A 17 Mm Wrench, Remove The Fasteners That Connect The Remaining

    P U M P D I S A S S E M B L Y Step 4 Step 5 Step 6 Next, remove the inlet elbow from Using a 10 mm wrench, remove the Inspect manifold gasket, fl ap valve the liquid chamber.

  • Page 13: Genuine Wilden Parts For Reliable

    P U M P D I S A S S E M B L Y Step 10 Step 11 Step 12 Using a 17 mm wrench, remove the Using a 17 mm wrench, remove the Next, remove the discharge elbow fasteners that connect the discharge fasteners that connect the discharge from the liquid chamber.
  • Page 14 P U M P D I S A S S E M B L Y Step 16 Step 17 Step 18 Remove the discharge elbow and Using a 19 mm wrench, remove the Remove the liquid chamber to discharge T-section from the liquid fasteners that connect the liquid expose the diaphragm and outer chamber.
  • Page 15 P U M P D I S A S S E M B L Y Step 22 Step 23 Step 24 After loosening the outer piston Next, remove remaining Remove the inner piston from the from the main shaft, the diaphragm/ diaphragm/piston assembly, bumper diaphragm/piston assembly...
  • Page 16 P U M P D I S A S S E M B L Y Step 28 Step 29 Remove the center block adapter Next, remove the center block plate from the air chamber. adapter plate o-ring and inspect for nicks, gouges, chemical attack or abrasive wear.
  • Page 17 A I R V A L V E / C E N T E R S E C T I O N D I S A S S E M B L Y The air valve assembly consists of both the air valve body and piston and the center block.
  • Page 18 A I R V A L V E / C E N T E R S E C T I O N D I S A S S E M B L Y Small nicks can usually be dressed out and the piston returned to service.
  • Page 19 R E A S S E M B L Y H I N T S & T I P S ASSEMBLY: INSTALLATION Upon performing applicable maintenance to the air The following tools can be used to aid in the installation distribution system, the pump can now be reassembled.

  • Page 20: Wetted Path

    S e c t i o n 8 E X P L O D E D V I E W A N D P A R T S L I S T I N G T810 ADVANCED METAL W e t t e d P a t h E X P L O D E D V I E W DRAWING B DRAWING A...
  • Page 21 E X P L O D E D V I E W A N D P A R T S L I S T I N G T810 ADVANCED METAL W e t t e d P a t h P A R T S L I S T I N G T810/ T810/...

  • Page 22: Center Section Assembly

    E X P L O D E D V I E W A N D P A R T S L I S T I N G T810 ADVANCED METAL C e n t e r S e c t i o n A s s e m b l y E X P L O D E D V I E W DRAWING A ALL CIRCLED PART IDENTIFIERS ARE INCLUDED IN CONVERSION KIT (see section 9).
  • Page 23 E X P L O D E D V I E W A N D P A R T S L I S T I N G T810 ADVANCED METAL C e n t e r S e c t i o n A s s e m b l y P A R T S L I S T I N G T810/ T810/...

  • Page 24: Inlet Flap Assemblies

    E X P L O D E D V I E W A N D P A R T S L I S T I N G T810 ADVANCED METAL F l a p A s s e m b l i e s E X P L O D E D V I E W DRAWING B DRAWING C...
  • Page 25 E X P L O D E D V I E W A N D P A R T S L I S T I N G T810 ADVANCED METAL F l a p A s s e m b l i e s P A R T S L I S T I N G T810/ T810/...

  • Page 26: Elastomer Options & Conversion Kit

    S e c t i o n 9 E L A S T O M E R O P T I O N S & C O N V E R S I O N K I T T810 ADVANCED™ METAL ELASTOMER OPTIONS DIAPHRAGM, GASKET, PAD, FLAP VALVE...
  • Page 27 W A R R A N T Y Each and every product manufactured by Wilden Pump and Engineering, LLC is built to meet the highest standards of quality. Every pump is functionally tested to insure integrity of operation. Wilden Pump and Engineering, LLC warrants that pumps, accessories and parts manufactured or supplied by it to be free from defects in material and workmanship for a period of five (5) years from date of installation or six (6) years from date of manufacture, whichever comes first.
