Allen-Bradley C Series Installation Instructions Manual

Installation Instructions
POINT I/O RTD and Isolated
Thermocouple Input Modules
Catalog Numbers 1734-IR2, 1734-IR2K, 1734-IR2E, 1734-IT2I,
1734-IT2IK, Series C
Catalog numbers with the suffix 'K' are conformal coated and their specifications are the
same as non-conformal coated catalogs.

Table of Contents

Topic
Important User Information
Environment and Enclosure
Prevent Electrostatic Discharge
North American Hazardous Location Approval
European Hazardous Location Approval
Before You Begin
Install the Mounting Base
Install the Module
Install the Removable Terminal Block
Remove a Mounting Base
Wire the Module
Communicate with the Module
Interpret Status Indicators
Specifications
Page
2
3
3
4
5
7
9
10
12
14
15
17
18
20
