Summary of Contents for Allen-Bradley C Series

Page 1: Table Of Contents
Installation Instructions POINT I/O RTD and Isolated Thermocouple Input Modules Catalog numbers 1734-IR2, 1734-IR2E, 1734-IT2I, Series C Table of Contents Topic Page Important User Information Environment and Enclosure Preventing Electrostatic Discharge North American Hazardous Location Approval European Hazardous Location Approval About the Module Install the Mounting Base Install the Module...
Page 2: Important User Information
2 POINT I/O RTD and Isolated Thermocouple Input Modules Important User Information Solid-state equipment has operational characteristics differing from those of electromechanical equipment. Safety Guidelines for the Application, Installation, and Maintenance of Solid-State Controls (Publication SGI-1.1 available from your local Rockwell Automation Sales Office or online at http://www.rockwellautomation.com/literature/) describes some important differences between solid-state equipment and hard-wired electromechanical devices.
Page 3: Environment And Enclosure
POINT I/O RTD and Isolated Thermocouple Input Modules Environment and Enclosure ATTENTION: This equipment is intended for use in a Pollution Degree 2 industrial environment, in overvoltage Category II applications (as defined in IEC publication 60664-1), and at altitudes of up to 2000 m (6562 ft) without derating. This equipment is considered Group 1, Class A industrial equipment according to IEC/CISPR 11.
Page 4: North American Hazardous Location Approval
4 POINT I/O RTD and Isolated Thermocouple Input Modules ATTENTION: This product is grounded through the DIN rail to chassis ground. Use zinc-plated yellow-chromate steel DIN rail to assure proper grounding. The use of other DIN rail materials (for example, aluminum, plastic) that can corrode, oxidize, or are poor conductors can result in improper or intermittent grounding.
Page 5: European Hazardous Location Approval
POINT I/O RTD and Isolated Thermocouple Input Modules European Hazardous Location Approval The following applies when the product bears the Ex Marking This equipment is intended for use in potentially explosive atmospheres as defined by European Union Directive 94/9/EC. DEMKO certifies that this equipment has been found to comply with the Essential Health and Safety Requirements relating to the design and construction of Category 3 equipment intended for use in Zone 2 potentially explosive atmospheres, given in Annex II to this Directive.
Page 6: About The Module
6 POINT I/O RTD and Isolated Thermocouple Input Modules About the Module You can use these Series C modules with the following: • 1734-ACNR ControlNet adapters with RSLogix 5000 software, version 11 or later • 1734-ADN, 1734-ADNX, 1734-PDN DeviceNet adapters or with any 1734D POINTBlock I/O module •...
Page 7 POINT I/O RTD and Isolated Thermocouple Input Modules Description Description Module locking mechanism 1734-TB or 1734-TBS mounting base Slide-in writable label Interlocking side pieces Insertable I/O module Mechanical keying (orange) Removable terminal block (RTB) handle DIN rail locking screw (orange) Removable terminal block with screw Module wiring diagram (1734-RTB) or spring clamp (1734-RTBS)
Page 8: Install The Mounting Base
8 POINT I/O RTD and Isolated Thermocouple Input Modules Install the Mounting Base To install the mounting base on the DIN rail, proceed as follows: 1. Position the mounting base vertically above the installed units (adapter, power supply, or existing module). Slide the mounting base until the interlocking side pieces engage the adjacent module or adapter.
Page 9: Install The Module
POINT I/O RTD and Isolated Thermocouple Input Modules ATTENTION: When you insert or remove the module while backplane power is on, an electrical arc can occur. This could cause an explosion in hazardous location installations. Be sure that power is removed or the area is nonhazardous before proceeding. Repeated electrical arcing causes excessive wear to contacts on both the module and its mating connector.
Page 10: Install The Removable Terminal Block
10 POINT I/O RTD and Isolated Thermocouple Input Modules 1. Using a bladed screwdriver, rotate the keyswitch on the mounting base clockwise until the number required for the type of module being installed aligns with the notch in the base. 2.
Page 11 POINT I/O RTD and Isolated Thermocouple Input Modules 3. If an I/O module is installed, snap the RTB handle into place on the module. Insert the module straight down into the mounting base. Hook the RTB end into the mounting base end and rotate until it locks into place.
Page 12: Wire The Module
12 POINT I/O RTD and Isolated Thermocouple Input Modules Wire the Module To wire the module, refer to the diagrams and tables. WARNING: If you connect or disconnect wiring while the field-side power is on, an electrical arc can occur. This could cause an explosion in hazardous location installations.
Page 13 POINT I/O RTD and Isolated Thermocouple Input Modules POINT I/O RTD Input Module Wiring – 1734-IR2, 1734-IR2E In O/A In 1/A In O/B In 1/B Ω Two-wire Three-wire resistor RET 0 RET 1 Shield Shield In = Input channel, When using two-wire RTDs, Ω...
Page 14 14 POINT I/O RTD and Isolated Thermocouple Input Modules 1734-IT2I Isolated Thermocouple Input Module Wiring – 1734-IT2I Module Module status Status Network Network status Status NODE: Thermocouple Input Status of input 0 0+ = Input channel 0 high 0- = Input channel 0 low Status of input 1 1+ = Input channel 1 high 1- = Input channel 1 low...
Page 15: Communicate With The Module
POINT I/O RTD and Isolated Thermocouple Input Modules Communicate with the Module POINT I/O modules send (produce) and receive (consume) I/O data (messages). You map this data into the processor’s memory. The 1734-IR2 and 1734-IR2E modules produce 6 bytes of input data (scanner Rx) and fault status data.
Page 16: Interpret Status Indicators
16 POINT I/O RTD and Isolated Thermocouple Input Modules Interpret Status Indicators Refer to the following diagram and table for information on how to interpret the status indicators. POINT I/O RTD and Isolated Thermocouple Input Modules 1734-IR2, 1734-IT2I 1734-IR2E Module status Module status Module Status...
Page 17 POINT I/O RTD and Isolated Thermocouple Input Modules Indicator Status for Modules Status Description Module status No power applied to device. Green Device operating normally. Flashing green Device needs commissioning due to missing, incomplete, or incorrect configuration. Flashing red Recoverable fault. Unrecoverable fault occurred.
Page 18: Specifications
18 POINT I/O RTD and Isolated Thermocouple Input Modules Specifications POINT I/O RTD Input Modules – 1734-IR2, 1734-IR2E Attribute 1734-IR2 1734-IR2E Number of inputs 2 single-ended, non-isolated Resolution 16 bits 16 bits 9.5 mΩ/cnt 2.4 mΩ/cnt 0.03 °C/cnt (Pt385 @ 25 °C) 0.006 °C/cnt (Pt385 @ 25 °C) [0.05 °F/cnt (Pt385 @ 77 °F)] [0.0114 °F/cnt (Pt385 @ 77 °F)]...
Page 19 POINT I/O RTD and Isolated Thermocouple Input Modules POINT I/O RTD Input Modules – 1734-IR2, 1734-IR2E Attribute 1734-IR2 1734-IR2E Common mode rejection ratio 120 dB Normal mode rejection ratio 100 dB Notch filter -3 dB settable at the following: 13.1 Hz @ Notch = 50 Hz 15.7 Hz @ Notch = 60 Hz 26.2 Hz @ Notch = 100 Hz 31.4 Hz @ Notch = 120 Hz...
Page 20 20 POINT I/O RTD and Isolated Thermocouple Input Modules POINT I/O Isolated Thermocouple Input Module – 1734-IT2I Attribute Value Input voltage ±75 mV Absolute accuracy 0.1% Full Scale @ 25 °C (77 °F) Accuracy drift with temp. 30 ppm/°C Input impedance 100 KΩ...
Page 21 POINT I/O RTD and Isolated Thermocouple Input Modules General Specifications Attribute Value Terminal base screw torque 0.8 Nm (7 lb-in.) Indicators 1 green/red – module status indicator, logic side 1 green/red – network status indicator, logic side 2 green/red – input status indicators, logic side Module location 1734-IT2I –...
Page 22 22 POINT I/O RTD and Isolated Thermocouple Input Modules Environmental Specifications Attribute Value Temperature, operating IEC 60068-2-1 (Test Ad, Operating Cold), IEC 60068-2-2 (Test Bd, Operating Dry Heat), IEC 60068-2-14 (Test Nb, Operating Thermal Shock): -20…55 °C (-4…131 °F) Temperature, storage IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating Cold), IEC 60068-2-2 (Test Bb, Unpackaged Nonoperating Dry Heat), IEC 60068-2-14 (Test Na, Unpackaged Nonoperating Thermal Shock):...
Page 23 POINT I/O RTD and Isolated Thermocouple Input Modules Certifications Certification (when Value product is marked) c-UL-us UL Listed Industrial Control Equipment, certified for US and Canada. See UL File E65584. UL Listed for Class I, Division 2 Group A,B,C,D Hazardous Locations, certified for U.S.
Page 24 RA-DU002, available at http://www.rockwellautomation.com/literature/. Allen-Bradley, Rockwell Automation, ArmorBlock, and TechConnect are trademarks of Rockwell Automation, Inc. Trademarks not belonging to Rockwell Automation are property of their respective companies. Publication 1734-IN011I-EN-E - June 2015 Supersedes Publication 1734-IN011H-EN-E - February 2014 Copyright ©...

This manual is also suitable for:

Point i/o 1734-ir2 Point i/o 1734-ir2e Point i/o 1734-it2i
