Display Backlight for PanelView 600 (Series C)

English Section

This instruction sheet describes how to replace the backlight in the following

PanelView terminal:

Terminal

PanelView 600 (Series C)

This publication excludes PanelView 600 Touch only.

TIP

Kit Contents

• Replacement backlight (quantity 2)

• Bezel screws (quantity 6)

• Display mounting plate screws (quantity 4)

The backlight uses Cold Cathode Fluorescent Lamp (CCFL) tubes to illuminate the

display.

• Disconnect all power from the PanelView terminal before

ATTENTION

• Do not touch any of the exposed electronic components

• Installer must use proper Anti-ESD equipment.

Backlight Catalog Number

2711-NL5

replacing the backlight. Failure to disconnect power may

result in electrical shock and/or damage to the terminal.

to prevent damage from electrostatic discharge (ESD).

Publication 2711-IN040A-MU-P - October 2003

Installation Instructions

Table of Contents

Do you have a question about the C Series and is the answer not in the manual?

Page 1 Installation Instructions Display Backlight for PanelView 600 (Series C) English Section This instruction sheet describes how to replace the backlight in the following PanelView terminal: Terminal Backlight Catalog Number PanelView 600 (Series C) 2711-NL5 This publication excludes PanelView 600 Touch only. Kit Contents •...
Page 2 Display Backlight for PanelView 600 (Series C) To Remove the Backlight 1. Turn off the power to the PanelView terminal. 2. Lay terminal on front. Remove six bezel screws from the shroud. Bezel Screws Bezel Screws 3. Turn terminal over and rest on back cover. 4.
Page 3 Display Backlight for PanelView 600 (Series C) 5. Disconnect cables to backlights. 6. Unscrew 4 display mounting plate screws. 7. Turn display to side, remove backlights by pressing tab and gently pulling straight out on wires. Display Mounting Screws 8. Properly dispose of old tubes. Publication 2711-IN040A-MU-P - October 2003...
Page 4 Display Backlight for PanelView 600 (Series C) To Install the Backlight 1. Install new backlights. Ensure backlights click into place. 2. Place display mounting plate over standoffs and install four display mounting plate screws. (Replacement screws are provided.) Torque to 6 to 8 in-lb (0.68 to 0.90 Nm).
