Allen-Bradley 1734-AENTRK Installation Instructions Manual

Point i/o dual port ethernet/ip adapter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Installation Instructions
POINT I/O Dual Port EtherNet/IP
Adapter
Catalog numbers 1734-AENTR, 1734-AENTRK, Series C
Catalog numbers with the suffix 'K' are conformal coated and their specifications are the
same as non-conformal coated catalogs.

Table of Contents

Topic
Page
2
3
3
4
4
6
7
8
9
10
10
12
14
16
18
23

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1734-AENTRK and is the answer not in the manual?

Questions and answers

Related Manuals for Allen-Bradley 1734-AENTRK

Summary of Contents for Allen-Bradley 1734-AENTRK

  • Page 1: Table Of Contents

    Installation Instructions POINT I/O Dual Port EtherNet/IP Adapter Catalog numbers 1734-AENTR, 1734-AENTRK, Series C Catalog numbers with the suffix ‘K’ are conformal coated and their specifications are the same as non-conformal coated catalogs. Table of Contents Topic Page Important User Information...

  • Page 2: Important User Information

    2 POINT I/O Dual Port EtherNet/IP Adapter Important User Information Solid-state equipment has operational characteristics differing from those of electromechanical equipment. Safety Guidelines for the Application, Installation and Maintenance of Solid State Controls (Publication SGI-1.1 available from your local Rockwell Automation sales office or online at http://www.rockwellautomation.com/literature/) describes some important differences between solid-state equipment and hard-wired electromechanical devices.

  • Page 3: Environment And Enclosure

    POINT I/O Dual Port EtherNet/IP Adapter Environment and Enclosure ATTENTION: This equipment is intended for use in a Pollution Degree 2 industrial environment, in overvoltage Category II applications (as defined in EN/IEC 60664-1), at altitudes up to 2000 m (6562 ft) without derating. This equipment is not intended for use in residential environments and may not provide adequate protection to radio communication services in such environments.

  • Page 4: North American Hazardous Location Approval

    4 POINT I/O Dual Port EtherNet/IP Adapter North American Hazardous Location Approval The following information applies when Informations sur l’utilisation de cet équipement operating this equipment in hazardous en environnements dangereux: locations: Products marked "CL I, DIV 2, GP A, B, C, D" are suitable Les produits marqués "CL I, DIV 2, GP A, B, C, D"...
  • Page 5 POINT I/O Dual Port EtherNet/IP Adapter ATTENTION: If this equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment may be impaired. ATTENTION: Read this document and the documents listed in the Additional Resources section about installation, configuration, and operation of this equipment before you install, configure, operate, or maintain this product.

  • Page 6: About The Adapter

    6 POINT I/O Dual Port EtherNet/IP Adapter WARNING: Secure any external connections that mate to this equipment by using screws, sliding latches, threaded connectors, or other means provided with this product. WARNING: Do not disconnect equipment unless power has been removed or the area is known to be nonhazardous.

  • Page 7: Before You Begin

    Firmware Backward Compatibility The 1734-AENTR and 1734-AENTRK Add-on Profiles are compatible with RSLogix 5000® software version 17, or greater. If you use the 1734-AENTR or 1734-AENTRK adapter with a 1756-ENBT module, use the following required firmware versions for these bridge modules: •...

  • Page 8: Install The Adapter

    Position the adapter module vertically above an IEC standard (35 x 7.5 x 1 mm) top-hat DIN rail at a slight angle (DIN rail: Allen-Bradley part number 199-DR1; 46277-3; EN50022). Make sure that the DIN rail lock is in a horizontal position.

  • Page 9: Thumbwheel Settings

    POINT I/O Dual Port EtherNet/IP Adapter Press down firmly to install the adapter on a DIN rail, noting that the locking mechanism locks the adapter to the DIN rail. ATTENTION: Do not remove or replace an Adapter Module while power is applied.

  • Page 10: Set The Chassis Size

    10 POINT I/O Dual Port EtherNet/IP Adapter Set the Chassis Size The I/O adapters for EtherNet/IP require configuration of their chassis size before you can make any I/O connections. The factory default setting for the chassis size is one slot, which represents the adapter by itself.
  • Page 11 POINT I/O Dual Port EtherNet/IP Adapter Valid settings range from 001…254. When you use the thumbwheel to assign an address and set it to 001, the adapter gateway address is set to 0.0.0.0. and the subnet mask is 255.255.255.0. When you use the thumbwheel to assign an address and set it between 002...254, the adapter gateway address is set to 192.168.1.1.

  • Page 12: Replace The Adapter

    12 POINT I/O Dual Port EtherNet/IP Adapter Replace the Adapter Use these procedures to install a replacement adapter to an existing system. Disconnect the Ethernet connector(s) from the adapter. WARNING: If you connect or disconnect the communications cable with power applied to this module or any device on the network, an electrical arc can occur.
  • Page 13 POINT I/O Dual Port EtherNet/IP Adapter Slide the safety end cap up to remove it, which exposes the backplane and power connections. Position the replacement adapter vertically above the DIN rail, making certain the DIN rail lock is in the horizontal position. Slide the adapter down, allowing the interlocking side pieces to engage the adjacent module.

  • Page 14: Wire The Adapter

    14 POINT I/O Dual Port EtherNet/IP Adapter Wire the Adapter 1734-AENTR POINT I O Module Status Network Activity Network Status Point Bus Status Link 1 Activity/ System Status Power Field Power Ethernet RJ-45 connectors Chas Gnd Link 2 Activity/ Status 44848 NC = No Connection Chas GND = Chassis Ground...
  • Page 15 POINT I/O Dual Port EtherNet/IP Adapter WARNING: When used in a Class I, Division 2, hazardous location, this equipment must be mounted in a suitable enclosure with proper wiring method that complies with the governing electrical codes. WARNING: If you connect or disconnect wiring while the field-side power is on, an electrical arc can occur.

  • Page 16: Interpret Status Indicators

    16 POINT I/O Dual Port EtherNet/IP Adapter Interpret Status Indicators Refer to the following diagram and table for information on how to interpret the status indicators. POINT I/O Dual Port EtherNet/IP Adapter, Series C 1734-AENTR POINT I O Module status Module Status Network activity...
  • Page 17 POINT I/O Dual Port EtherNet/IP Adapter Indicator Status for Modules Indicator Status Description Network No link established with Port 1 or Port 2. activity Flashing green Transmit or receive activity present on Port 1 and/or Port 2 @ 100 Mb. Transmit or receive activity present on Port 1 and/or Port 2.

  • Page 18: Specifications

    (for digital, analog, and specialty modules) connections • 31 direct connections • 1734-AENTR, 1734-AENTRK backplane current output = 0.8 A. • Actual number of modules can vary • Add up current requirements of modules you want to use to make sure they do not exceed the amperage limit of 0.8 A for...
  • Page 19 POINT I/O Dual Port EtherNet/IP Adapter General Specifications Attribute Value Indicators 3 red/green status indicators on CPU: – Module status – Network status (Ports 1 and 2 combined) – POINTBus status 1 green/yellow status indicator on CPU: – Network activity (Ports 1 and 2 combined) 2 green/yellow status indicators on base: –...
  • Page 20 20 POINT I/O Dual Port EtherNet/IP Adapter Use this Conductor Category information for planning conductor routing. Refer to Industrial Automation Wiring and Grounding Guidelines, publication 1770-IN041. Use this Conductor Category information for planning conductor routing as described in the appropriate System Level Installation Manual.
  • Page 21 POINT I/O Dual Port EtherNet/IP Adapter Environmental Specifications Attribute Value Temperature, operating IEC 60068-2-1 (Test Ad, Operating Cold), IEC 60068-2-2 (Test Bd, Operating Dry Heat), IEC 60068-2-14 (Test Nb, Operating Thermal Shock): -20...55 °C (-4...131 °F) Temperature, surrounding air, max 55 °C (131 °F) Temperature, nonoperating IEC60068-2-1 (Test Ab, Unpackaged Nonoperating Cold)
  • Page 22 22 POINT I/O Dual Port EtherNet/IP Adapter Certifications Certification (when Value product is marked) c-UL-us UL Listed Industrial Control Equipment, certified for US and Canada. See UL File E65584. UL Listed for Class I, Division 2 Group A,B,C,D Hazardous Locations, certified for U.S.

  • Page 23: Additional Resources

    If you would like a manual, you can: • download a free electronic version from the internet: http://www.rockwellautomation.com/literature/ • purchase a printed manual by contacting your local Allen-Bradley distributor or Rockwell Automation representative. Publication 1734-IN041F-EN-P - May 2019...
  • Page 24 Rockwell Automation maintains current product environmental information on its website at http://www.rockwellautomation.com/rockwellautomation/about-us/sustainability-ethics/product-environmental-compliance.page. Allen-Bradley, ArmorPOINT, ControlLogix, POINT Guard I/O, POINT I/O, POINTBus, Rockwell Automation, Rockwell Software, RSLogix 5000, and TechConnect are trademarks of Rockwell Automation, Inc. CIP and EtherNet/IP are trademarks of ODVA, Inc.
