PT3500-HB-TK
15" High Bright Beam Splitter Teleprompter & Hard Case
What's Included
1 x Teleprompter Base Assembly w/ Glass
1 x PT-CASE Rolling Hard Case
1 x Camera Mount Assembly
1 x Hood
1 x High Bright LCD Monitor w Power Supply
2 x 200mm Riser Rods
1 x PrompterPro 4 Software
1 x 5/32 Hex Key
2 x DRS-01
4 x Cork Strips
