- Page 1 Quick Start Guide PT3500-P2P-TK & PT3700-P2P-TK P2P Interview System with 2 x Teleprompters, Hard Cases, and HDMI Connection Cables What’s Included 2 x Teleprompters 2 x SKB Rolling Hard Case 2 x 25 ft HDMI Cables www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com...
- Page 2 Assembly Step 1 Place teleprompter base assembly on a flat surface. Step 2 You can position the glass at any angle you want, but the preferable angle is 45°. because we’re filmmakers too www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com...
- Page 3 Step 3 Slide the Camera Mount Assembly onto the 15mm Rods The tripod mount has 3 sets of holes that allows you to mount the plate either towards the front or rear to help balance the teleprompter better. For larger cameras it is better to have the plate toward the rear, and for smaller cameras towards the front.
- Page 4 Step 4 Attach camera to camera mount and slide to best position. Make sure all thumbscrews are secure. DSLR Camcorder If you require the camera to be positioned higher, you can replace the 200mm raiser bars in place of the pre-installed 130mm Rods Use the included 5/32 Hex Key to remove and attach the raiser rods.
- Page 5 Step 5 Attach hood to glass frame using the integrated magnets. You can attach the optional side flaps. because we’re filmmakers too www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com...
- Page 6 To make your teleprompter more portable, we packed it in a reusable, high-quality foam. The shape and size of the foam was designed to fit into Ikan’s PT-CASE which is included in this Travel Kit. ** DO NOT THROW AWAY FOAM CASE ** because we’re filmmakers too...
-
Page 7: Monitor Ports
Monitor Ports Monitor Menu Settings Video Config Contrast (White Level) Brightness (Black Level) Tint (Chroma Hue) Chroma (Chroma Saturation) Sharpness (Detail) RGB Setup – Manually configure RGB Return System Config Menu Duration – Set duration of how long menu stays on screen Video Ratio –... -
Page 8: Specifications
Specifications PT3500-P2P-TK PT3700-P2P-TK 15” Teleprompter System Travel Kits 17” Teleprompter System Travel Kits Aspect Ratio Aspect Ratio Brightness 350 cd/m2 Brightness 350 cd/m2 Build Material Aluminum / Steel Build Material Aluminum / Steel Contrast Ratio 1000:1 Contrast Ratio 1000:1 Input Signal... -
Page 9: Learn More
Damage caused by abuse or misuse, dismantling, or changes to the product not made by the company. • Damage caused by natural disaster, abnormal voltage, and environmental factors, etc. ©2018 ikan Corporation. All rights reserved because we’re filmmakers too because we’re filmmakers too www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com...
