Getting Started
8
Table 5: Instrument options (cont.)
Option
Measurement EYE
and Analysis
PHY
PROD
DAT
Instrument
model Description
WVR8200 Adds Eye Pattern Display and Jitter
Measurement Package (includes 3G-SDI,
HD-SDI, and SD-SDI Eye pattern display;
automated measurements of jitter and
cable parameters); Option 3G required for
3G-SDI support.
WVR8300 Adds Physical Layer Measurement
Package (includes 3G-SDI, HD-SDI, and
SD-SDI Eye pattern and jitter waveform
displays; automated measurements of
Eye pattern parameters, jitter, and cable
parameters; color bar and pathological
signal generation); Option 3G required for
3G-SDI support.
WVR8200, Adds Advanced Gamut Monitoring Package
WVR8300
(Spearhead Display and Luma Qualified
Vector Display).
WVR8200 Adds data analysis capabilities. Allows for
logic-level view of video and embedded
audio data stream and ANC data extraction.
