WVR8200, WVR8300 User Manual

Table 5: Instrument options

Option
Video 2SDI
3G
CPS
3D
Audio AD
DPE
62
Instrument
model Description
WVR8200, Adds support for second SDI board in
WVR8300 Slot 2 of the instrument rear panel. With
this option, this instrument can monitor
up to four SDI inputs. This option is not
compatible with Option CPS.
WVR8200, Adds support for 3G-SDI signal formats.
WVR8300
WVR8200, Adds support for Composite Analog Video
WVR8300 Monitoring; 2 composite Analog inputs;
passive loop-through.
WVR8200, Adds Stereoscopic 3-D Video Monitoring
WVR8300 Capabilities (including Simultaneous Input
Monitoring (SIM) of dual SDI inputs and
synchronized left eye and right eye signals
monitoring (SyncVu™)).
WVR8200, Adds Analog Audio Monitoring (2 sets
WVR8300 of 6 channel Analog Audio inputs and 8
channels of Analog Audio outputs); 16
channels Embedded and AES/EBU Digital
Audio support (8 channels at a time).
WVR8200, Adds Option AD capabilities (Analog and
WVR8300 Digital Audio, Embedded or External AES),
plus support for decoding and monitoring
Dolby E, Dolby D, and Dolby Digital Plus
Audio (Audio cable available separately).
(See Table 3.)
WVR8200,
Analog Audio Breakout Cable, 6 feet, male
WVR8300 62-pin connector to 8 XLR male output
connectors and 12 XLR female input
connectors.
Getting Started
7
