Specifications
O-Box WM Deluxe Set (C1243-0002)
Only
Side flags (set of 2)
Dimensions (width at widest point) . . . . . . . . . . . . . . . . . . . . . 115 x 172 mm (4.5 x 6.7 in.)
Side flag brackets (set of 2)
Dimensions (HWD) . . . . . . . . . . . . . . . . . . . . . . . . 105 x 57 x 36 mm (4.1 x 2.2 x 1.4 in.)
Bellows ring (Donut)
Dimensions (width at widest point) . . . . . . . . . . . . . . . . . . . . . 115 x 172 mm (4.5 x 6.7 in.)
Maximum lens diameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ø114 mm (Ø4.4 in.)
Reduction ring
Maximum lens diameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ø110 mm (Ø4.3 in.)
Universal rings (set of 2)
(150 - 80 mm)
Outer diameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ø150 mm (Ø5.9 in.)
Minimum lens diameter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ø80 mm (Ø3.1 in.)
(114 - 55 mm - threaded)
Outer diameter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ø114 mm (Ø4.4 in.)
Minimum lens diameter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ø55 mm (Ø1.9 in.)
Specifications are subject to change without notice
