FLUE OUTLET
Max. flue length
Case Rear Up to 2.5M
Top LHS Up to 2.5M
Top RHS Up to 2.5M
Top Rear Up to 2.5M
Fit the flue connecting sleeve on to the fan, see diagram 8.12.
Fit the fan to the flue ducting, Holding it up in position fit the flue
collector, see diagram 8.13.
Secure the fan to the flue collector with the securing screw and
retaining lip, see diagram 8.14.
Fit the electrical connections and air pressure tubes to the fan.
Refit the combustion chamber panel.
Make the outer wall weatherproof. A Flue Collar Kit Part No.
443286 is available.
FLUE
CONNECTING
SLEEVE
FAN
Push
to fit
FLUE
CONNECTING
SLEEVE
8 Mounting the boiler
RESTRICTOR TABLE
Restrictor Plate
FLUE
DUCTING
Diagram 8.11
FAN
Diagram 8.12
Max. flue length
G N/A
C 2.5 to 3.5M
C 2.5 to 3.5M
C 2.5 to 3.5M
FLUE
DUCTING
FLUE
CONNECTING
SLEEVE
FAN
(Push up
to fit)
FLUE
COLLECTOR
FLUE
DUCTING
AIR
PRESSURE
TUBE (2)
FLUE
CONNECTING
SLEEVE
19
Restrictor Plate
N/A
Non
D
D
RETAINING
LIP
Diagram 8.13
ELECTRICAL
CLEAR
CONNECTIONS
FAN RETAINING
LIP
SECURING
SCREW
Diagram 8.14
RED
