Chapter 1: Product Introduction
Hardware Installation
Note: The following instructions illustrate how to setup the NCi-311, but are also applicable for NCi-311-R
1. Position the placement sticker at the desired installation location on the
wall/ceiling.
2. Drill the two mounting holes in the placement sticker, and insert the
included screw anchors.
3. Secure the camera's base plate to the mounting holes.
4. Separate the top cover, then secure the camera to the base plate with
screws (align the arrow marked inside the camera to the direction of the
cable opening on the base plate).
5. Adjust the lens to the appropriate position then replace the top cover.
6. Secure the top cover tightly using the supplied M2 self-tapping screws.
7. To remove the cabling, please remove the top cover first (please refer to
the figure below).
Copyright © 2013 NEXCOM International Co., Ltd. All Rights Reserved.
4
NCi-311/NCi-311-R User Manual
