System Board Components

The following table lists the main components on the system board. See the System Board
Manual for more detailed information.
Component
Form Factor
System BIOS
Processors
Chipset
Combo Controller
PCI-to-ISA Bridge
EIDE Controller
Universal Serial Bus Ports
Video Display Controller
Description
Matrox G200 or Intense 3D Wildcat 4000
Creative Labs Sound Blaster 16 ISA sound card
Audio ports and MIDI/game port
SCSI: 4.3 GB 7,200 RPM (system disk drive)
SCSI: 4.3 or 9.1 GB 7,200 RPM (SCA); 4.3, 9.1, or 18.0 GB 10,000
RPM (SCA); all Ultra Wide SCSI II
32X EIDE
One AGP, four PCI, one PCI/ISA (shared), one ISA
One 3.5-inch x 1.6-inch internal bay for system disk drive
One 5.25-inch x 1.6-inch external bay for optional peripheral device
One 5.25-inch x 1.6-inch external bay for CD-ROM drive
One 3.5-inch x 1.0-inch external bay for floppy disk drive
Four slots for SCA SCSI JBOD or RAID disk drives
One PS/2 mouse port and one PS/2 keyboard port
One parallel (LPT) port, EPP- and ECP-compatible
Two serial (COM) ports
Two Universal Serial Bus (USB) ports
300 Watts, manual-ranging
Description
ATX
AMIBIOS
Intel Pentium II, 450 MHz, SEC (Single Edge Connector)
Intel 440 BX series
National PC87309 Super I/O
Intel 82371EB PCI/ISA/IDE Xcelerator (PIIX4E)
Intel 82371EB
Intel 82371EB
Intel 82443BX PCI/AGP
