Specifications

Item
Dimensions
Maintenance clearance
AC line voltage (US)
AC line voltage
(International)
Recommended room
temperature
Recommended room humidity
Heat dissipation

System Configuration Summary

The following table summarizes the main features of the system.
Feature
Processors
Bus Speed
Memory Modules
Memory Style
Memory Type
Memory Speed
Memory Size
Memory Expansion
Networking
SCSI
EIDE
Mouse
Keyboard
Specifications
25.8 x 7.9 x 20.2 inches (65.4 x 20.0 x 50.8 cm)
36 inches (91.4 cm) front and back
90 - 132 VAC, 47 - 63 Hz, 1 phase, 15A/125 V receptacle
180 - 264 VAC, 47 - 63 Hz, 1 phase, 15A/250 V receptacle
50° to 80° F (10° to 26° C)
20% to 80% (non-condensing)
2,662.14 BTU/hr
Description
Two 450 MHz Intel Pentium II with external 512 KB cache
100 MHz
Four banks of dual inline memory modules (DIMMs), one DIMM per
bank
168 pin SDRAM DIMM, 10 ns, 3.3V, registered, 72 bit (non-ECC)
168 pin SDRAM DIMM, 10 ns, 3.3V, unbuffered, 72 bit (ECC)
SDRAM (Synchronous Dynamic Random Access Memory)
100 MHz
128 MB minimum, 1 GB maximum
128 or 256 MB increments
3COM 3C905 10/100 Mbit PCI network adapter (optional)
G-NIC II Gigabit network adapter (optional)
Symbios dual-channel LVDS (optional), two internal and two external
channels
Primary EIDE connector for EIDE CD-ROM drive
Primary EIDE connector for one additional EIDE peripheral device
Secondary EIDE connector not used
Logitech wheel mouse
PS/2 style, standard Windows 95/98 compatible (optional)
