Hardware Overview

If your system includes any of the following hardware, refer to the documentation delivered
with the hardware for additional information:
u
Monitor, keyboard, and concentrator
u
Single-channel RAID controller
u
Dual-channel LVDS SCSI adapter
u
Fibre Channel host bus adapter
u
Network adapter
u
Zip, Jaz, or tape drive
u
AC power distribution box
u
Uninterruptible power supply
The following figure shows the major parts and assemblies inside the system.
Chassis Fan/
Mounting
Plate
Power Supply
Input/Output Panel
Peripheral
Device Bay
Expansion Slots
Face Panel
Disk Drive Bay
Disk Drive Bay
Fans
