NOTE If the system uses the optional Mylex RAID controller, the jumper connectors JP2 and JP3
must not have any jumpers installed.
9. If the old disk drive bay has a SAF-TE card (as described in the next section), remove it
from the old disk drive bay and install it in the same location on the new disk drive bay.
10. Insert the new disk drive bay partially into the chassis.
11. Reconnect the SCSI cable and power connectors in the same positions as the old disk
drive bay.
12. Insert the new disk drive bay the rest of the way into the chassis, and secure it with the
screws removed earlier.
13. Insert the disk drives into the slots in the disk drive bay. The drives should be installed in
the same slots from which they were removed.
14. Replace the front panel and cover.
15. Restart the system and ensure the LED for each drive lights and remains steady green. If
not, refer to the System Setup for status LED information.

SAF-TE Card

The SCSI Activity Fault-Tolerant Enclosure (SAF-TE) card is an option used only on systems
with RAID configurations. If your system has a RAID configuration with a SAF-TE card, use
the following procedure to replace the SAF-TE card.
To move or replace the SAF-TE card:
1. Remove the disk drive bay as described previously in "Disk Drive Bay." The SAF-TE
card is located in the middle of the SCSI backplane on the back of the disk drive bay.

SAF-TE Card
