Unico UV-2802 User Manual page 24

Press 【F3】 to search the Abs/%T value of the scan. There are two
6
ways for you to search (Fig 49).
a) Peak to peak, press 【F1】 to set " peak height" and input value by
pressing the numeric keypad (Fig 50). Press 【∧】 to search the
peak from left to right and press【∨】to search from right to left.
The value of every peak found will be displayed on the screen one
at a time (Fig 51).
WL : 680.0nm %T:
200.0 Wavelength (nm)
Min X:300
Fig47
WL : 680.0nm %T:
300.0 Wavelength (nm)
F1:Setup F2:Mode F3:Search
Fig 48
WL : 680.0nm %T:
200.0 Wavelength (nm)
F1:Set Peak Height
Fig 49
23
12: 35: 27
D2
W
Cell #1
From:
200.0
To:
680.0
Step:
1.0nm
XScale
YScale
680.0
12: 35: 27
D2
W
Cell #1
From:
200.0
To:
680.0
Step:
1.0nm
XScale
YScale
500.0
12: 35: 27
D2
W
Cell #1
From:
200.0
To:
680.0
Step:
1.0nm
Point
Peak
680.0
