Technical Specifications

ReachNXT 100-8t
General Specifications
Performance
• 5.6 Gbps switch fabric bandwidth
• 4.1 Mpps frame forwarding rate (based on
64-byte packets)
• 2,048 byte maximum packet size
Optional AC Power Adapter
• Input: 100-240V, 50/60Hz, Max 0.5A
• Output: 12V, 1.25A
Ports
• 8 ports 10/100BASE-T with autospeed and
auto-polarity
• 1-port 10/100/1000BASE-T with autospeed
and auto-polarity (PoE input)
• 1-port 1000BASE-X SFP (shared PHY with 1
10/100/1000BASE-T port)
• Per-port status LED including management
status

Physical Specifications

Dimensions
• Height: 1.34 inches/34 mm
• Width: 8.7 inches/220 mm
• Depth: 5.9 inches/150 mm
• Weight: 1.1 lbs/0.5 kg
• Kensington lock hole

Operating Specifications

Temperature
• Operating Temperature Range: 0° C to 40° C
(32° F to 104° F)
• Operating Humidity: 10% to 93% relative
humidity, non-condensing
Storage & Transportation Conditions (Packaged)
• Transportation Temperature: -40° C to 70° C
(- 40° F to 158° F)
• Storage and Transportation Humidity: 60% to
95% RH, non-condensing
Power & Acoustic Sound
• Noise: None (Fanless)
• Power Consumption
– 6.9W for 12V – AC power adapter
– 8.2W for 48V – DC PoE
• AC Power Adapter
– Nominal Input Ratings: 100 – 240V, 50/60Hz
– Nominal Input Current: 0.5A
– Nominal Output Ratings: 12V
– Nominal Output Current: 1.25A
Regulatory/Safety Standards
North American Safety of ITE
• UL 60950-1:2003 1st Ed., Listed Device (U.S.)
• CSA 22.2#60950-1-03 1st Ed.(Canada)
• Complies with FCC 21CFR 1040.10 (U.S. Laser
Safety)
• CDRH Letter of Approval (U.S. FDA Approval)
European Safety of ITE
• EN 60950-1+A11:2001 TUV-R GS Mark by
German Notified Body
• EN 60825-1+A2:2001 (Lasers Safety)
• 2006/95/EC Low Voltage Directive
International Safety of ITE
• CB Report & Certificate per IEC 60950-
1:2001+All Country Deviations
• AS/NZS 60950-1 (Australia/New Zealand)
© 2009 Extreme Networks, Inc. All rights reserved.
Management LED Description
Blinking Amber Firmware upgrade in progress
Blinking Green Diagnostics in progress
Solid Amber Diagnostics failed
Solid Green ReachNXT is initialized and connected to an ExtremeXOS switch
Off ReachNXT is not connected to an ExtremeXOS switch
Power LED Description
Green AC power
Amber Power over Ethernet
Off No power
Port LED Description
Steady Green Link OK
Port is transmitting
Blinking Green
Off Link is not present
EMI/EMC Standards
• North America EMC for ITE
• FCC CFR 47 part 15 Class B (U.S.A.)
• ICES-003 Class B (Canada)
• European EMC standards
• EN 55022 2006 Class B
• EN 55024 A2:2003 Class B
• EN61000-3-2 8-2006 (Harmonics)
• EN61000-3-3 1995+A2:2005 (Flicker)
• 93/68/EEC EMC Directive
International EMC Certifications
• CISPR 22:2006 Ed 5.2 Class B (International
Emissions)
• CISPR 24:2003 (International Immunity)
• IEC/EN 61000-4-2:2001 Electrostatic Discharge,
8kV Contact, 15kV Air, Criteria A
• IEC/EN 61000-4-3:2006 Radiated Immunity
10V/m, 30 to 2GHz Criteria A
• IEC/EN 61000-4-4 Transient Burst, 1kV, I/O
Criteria A
• IEC/EN 61000-4-5 Surge, 2kV L-L, 2kV L-G, Level
3, Criteria A (power supply only)
• IEC/EN 61000-4-6 Conducted Immunity, 0.15 –
80MHz, 10V/m unmod. RMS, Criteria A
• IEC/EN 61000-4-11 Power Dips & Interruptions,
>30%, 25 periods, Criteria C (power supply only)
Country Specific
• VCCI Class B (Japan Emissions)
• ACMA (C-Tick) via CISPR22:2006 (Australia &
New Zealand)
• BSMI, CNS 13438:1997 Class B (Taiwan)
• KCC Mark, KN22, KN24 (Korea) Class B
• ANATEL, (Brazil) Certificate of Homologation in
accordance with General Requirements
Resolution 242 Nov. 2000 for Category 3
equipment, Resolution 442 Nov. 2006 (EMC)
and Resolution 238 Nov. 2000 (Safety)
Telecom Standards
• ETSI EN 300 386:2001 (EMC Telecommunica-
tions)
• ETSI EN 300 019 (Environmental for Telecommu-
nications)
• IEEE 802.3 Media Access Standards
• IEEE 802.3ab 1000BASE-T
• IEEE 802.3af PoE/PD
• IEEE 802.3z 1000BASE-X
• IEEE 802.1ab – Link Layer Discovery Protocol
(LLDP)
Extreme Networks Data Sheet
Environmental Standards
• EN/ETSI 300 019-2-1 v2.1.2 (2000-09)
–Storage, Class 1.2
• EN/ETSI 300 019-2-2 v2.1.2 (1999-09) – Public
Transportation, Class 2.3
• EN/ETSI 300 019-2-3 v2.1.2 (2003-04) – Sta-
tionary Use, Class 3.1e
• EN/ETSI 300 753 (1997-10) – Acoustic Noise
ASTM D3580 Random Vibration Unpackaged
1.5G
Warranty
• Ltd. Lifetime with express Advanced
Hardware Replacement (for products
shipped from Extreme Networks on
or after June 29, 2009)
• For warranty details,
visit www.extremenetworks.com/go/warranty
ReachNXT 100-8t—Page 4
