  • Page 1 Upright Bike Assembly Instruction ME-710 Parts List Warranty Ordering Parts Model ME-710 Retain This Manual for Reference 100715 OWNER'S MANUAL ® IMPEX INC. 14777 DON JULIAN RD., CITY OF INDUSTRY, CA 91746 Tel: (800) 999-8899 Fax: (626) 961-9966 www.impex-fitness.com info@impex-fitness.com...

  • Page 2: Table Of Contents

    Thank you for selecting the MARCY Magnetic Upright Bike ME-710 by ® IMPEX INC. For your safety and benefit, read this manual carefully before using the machine. As a manufacturer, we are committed to provide you complete customer satisfaction. If you have any questions, or find there are missing or damaged parts, we guarantee you complete satisfaction through direct assistance from our factory.

  • Page 3: Important Safety Notices

    OVER THE AGE OF 35 OR PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. READ ALL INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. IMPEX INC. ASSUMES NO RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT. SAVE THESE INSTRUCTIONS.
  • Page 4 WARNING LABEL PLACEMENT The Warning Label shown here has been placed on the Rear Stabilizer. If the label is missing or illegible, please call customer service at 1-800-999-8899 for replacement. Apply the label in location shown.

  • Page 5: Hardware Pack

    HARDWARE PACK No. Description Identifier Q’ty Ø 5/8” Washer M8 x 2 ½” Carriage Bolt Ø 7/8” Curved Washer M8 Acorn Nut M8 x 5/8” Allen Bolt Ø 1” Flat Washer T-shaped Lock Knob #6 Allen Wrench Crossing Wrench Above hardware are all you need to assemble this machine. Before you start to assemble, please check the hardware pack to make sure they are included.
  • Page 6 PRE-ASSEMBLY CHECK LIST PART NO. DESCRIPTION Q’TY Main Frame Front Stabilizer Rear Stabilizer Front Post Handlebar Computer Seat Post Seat Left Pedal Right Pedal User Manual...

  • Page 7: Assembly Instructions

    ASSEMBLY INSTRUCTION NOTE: It is strongly recommended that two or more people assemble this machine to avoid possible injury. STEP 1 (See Diagram1) A.) Do not tighten Nuts and Bolts until instructed to do so. B.) Attach the Front Stabilizer (#2) to the Main Frame (#1). Secure it with two M8 x 2 ½” Carriage Bolts (#15), two 7/8”...
  • Page 8 STEP 2 (See Diagram 2) A.) Note: In order to hold the Front Post (#4) while connecting the cables and wires, extra help may be needed. B.) Attach the Front Post (#4) to the Main Frame (#1). Connect the Middle Computer Wire (#21) from the bottom of Front Post to the Lower Computer Wire (#22) from the main Fame.
  • Page 9 STEP 3 (See Diagram 3) A.) Attach the Handle (#5) to the Front Post (#4). Secure it with one Bracket (#30), one M8 x ¾” Allen Bolt (#31), one T-shaped Lock Knob (#26), and two Ø 5/8” Washers (#12). B.) Connect Upper Computer Wire (#28) to the Middle Computer Wire (#21). C.) Remove the two M5 x 3/8”...
  • Page 10 STEP 4 (See Diagram 4) A.) Remove the three Ø 5/8” Washers (#12), three Ø 3/8” Lock Washers (#13), and three M8 Aircraft Nuts (#14) from the Seat (#8). B.) Attach the Seat to the Seat Post (#7). Secure it with three Ø 5/8” Washers (#12), three Ø...
  • Page 11 STEP 5 (See Diagram 5) A.) Thread the Left Pedal (#9) counterclockwise into the Crank (#25). B.) Thread the Right Pedal (#10) clockwise into the Crank on the other side. DIAGRAM 5...

  • Page 12: Exploded Diagram

    EXPLODED DIAGRAM...

  • Page 13: Parts List

    PARTS LIST KEY NO. DESCRIPTION QUANTITY Main Frame Front Stabilizer Rear Stabilizer Front Post Handle Computer Seat Post Seat Left Pedal Right Pedal Lock Knob Ø 5/8” Washer Ø 3/8” Lock Washer M8 Aircraft Nut M8 x 2 ½” Carriage Bolt Ø...

  • Page 14: Computer

    COMPUTER AUTO START / STOP When exercise starts, the monitor will automatically turn on and display the progress. When exercise stops, the monitor will automatically turn off after 8 minutes to save energy. Press “MODE” key, will automatically scan Time, Speed, Distance, Calories, and ODO for every 4 seconds.
  • Page 15 EXERCISE INSTRUCTIONS Using your MAGNETIC BIKE will provide you with several benefits, it will improve your physical fitness, tone muscle and in conjunction with calorie controlled diet help you lose weight. 1. The Warm Up Phase This stage helps get the blood flowing around the body and the muscles working properly.
  • Page 16 3. The Cool Down Phase This stage is to let your Cardio-vascular System and muscles wind down. This is a repeat of the warm up exercise e.g. reduce your tempo, continue for approximately 5 minutes. The stretching exercises should now be repeated, again remembering not to force or jerk your muscles into the stretch.

  • Page 17: Warranty

    IMPEX. IMPEX is not responsible or liable for indirect, special or consequential damages arising out of or in connection with the use or performance of the product or other damages with respect to any economic loss, loss of property, loss of revenues or profits, loss of enjoyments or use, costs of removal, installation or other consequential damages or whatsoever natures.
