AXP1620
Installation and Use
6806800E23E
March 2011
Arrow.com.
Downloaded from

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AXP1620 and is the answer not in the manual?

Questions and answers

Related Manuals for Emerson AXP1620

Summary of Contents for Emerson AXP1620

  • Page 1 AXP1620 Installation and Use 6806800E23E March 2011 Arrow.com. Downloaded from...
  • Page 2 Emerson reserves the right to revise this document and to make changes from time to time in the content hereof without obligation of Emerson to notify any person of such revision or changes.

  • Page 3: Table Of Contents

    AXP1620 Shelf Description ........
  • Page 4 AXP1620 Shelf Installation ........
  • Page 5 7.4.3 Master-Only I2C Bus ..........123 AXP1620 Installation and Use (6806800E23E) Arrow.com.
  • Page 6 Related Documentation ............135 A.1 Emerson Network Power - Embedded Computing Documents ..... . 135 A.2 Related Specifications .
  • Page 7 Interhub Slot and Shelf Manager Connectivity ......129 AXP1620 Installation and Use (6806800E23E) Arrow.com.
  • Page 8 List of Figures AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from...
  • Page 9 AXP1620 Shelf Power Requirements ........
  • Page 10 List of Tables AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from...

  • Page 11: About This Manual

    American National Standards Institute Address Resolution Protocol ARTM AdvancedTCA Rear Transition Module ATCA Advanced Telecommunications Computing Architecture American Wire Gauge Basic Blade Services Carrier Grade Linux Clock Generator Module AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 12 Intelligent Platform Management Interface Light Emitting Diode Mezzanine Management Controller National Academy of Engineering NEBS Network Equipment Building System National Electric Code Original Equipment Manufacturer Out-of-band AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 13 Typical notation for hexadecimal numbers (digits 0 through F), e.g. used for addresses and offsets 0b0000 Same for binary numbers (digits are 0 and 1) Generic use of a letter Generic use of numbers AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 14 Indicates a hazardous situation which, if not avoided, may result in minor or moderate injury Indicates a property damage message No danger encountered. Pay attention to important information AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 15 > Contact Us > Online Form In "Area of Interest" select "Technical Documentation". Be sure to include the title, part number, and revision of the manual and tell us how you used it. AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com.
  • Page 16 About this Manual AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from...

  • Page 17: Safety Notes

    Emerson intends to provide all necessary information to install and handle the product in this manual. Because of the complexity of this product and its various uses, we do not guarantee that the given information is complete.
  • Page 18 An AXP1620 that is shipped as a spare, replacement chassis, or an unconfigured system will not have filler panels installed. It is the responsibility of the customer to ensure that all open slots are filled with payload blades, rear transition modules (RTMs), or approved filler panels in order to be compliant with the safety/EMC regulatory markings.
  • Page 19 The system is heavy and if you carry it on your own you can hurt your back. To prevent injury, keep your back straight and have two people lift the system or use additional lifting equipment. AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com.
  • Page 20 High leakage current can cause injuries. Therefore, it is essential that you create an earth connection before connecting the PEM to a telecommuncation network. System Damage Wrong jumper settings can make the shelf in-operable. Therefore, never change the settings of the jumpers. AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 21 LED is permanently ON. Blade Malfunctioning Incorrect blade installation and removal can result in blade malfunctioning. Make sure that the blade is connected to the system backplane through all assembled AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com.
  • Page 22 To guarantee proper airflow through the system, the air filter has to be replaced at least every six months. Emerson recommends to replace the air filter every 90 days. Filter replacement frequency depends on the environment the system is subjected to.
  • Page 23 (and vice versa). To avoid damage or injuries, always check that there is no more voltage on the line that has been disconnected before continuing your work. AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com.
  • Page 24 Be careful with the used tools in order to prevent a short circuit. PEM Damage Applying reversal power causes damage to the electrolytic capacitors of the filter. Therefore, only switch on the breakers if no red light is visible. AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 25 Fans become exposed when the fan tray is pulled. Keep clear of the fans as long as they are rotating. When the fan is removed, extreme care should be taken while handling the fan itself. The centrifugal forces will make the unit difficult to handle. AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com.
  • Page 26 Personal Injury The cabling should follow existing cable paths using existing or similar cable fastenings. Never change the system's cabling as delivered by Emerson. Check proper function of the system after cabling extensions. To avoid injuries always ensure that cables are securely installed so that nobody can trip over them.
  • Page 27 Always dispose of old batteries according to your country's legislation. Environment Environmental Always dispose of used blades, system components and RTMs according to your country’s legislation and manufacturer’s instructions. AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 28 Safety Notes AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Downloaded from Downloaded from Downloaded from...

  • Page 29: Sicherheitshinweise

    Installieren Sie keine Ersatzteile oder führen Sie keine unerlaubten Veränderungen am System durch, sonst verfällt die Garantie. Wenden Sie sich für Wartung oder Reparatur bitte an die für Sie zuständige Geschäftsstelle von Emerson. So stellen Sie sicher, dass alle sicherheitsrelevanten Aspekte beachtet werden.
  • Page 30 Einbau und anderem als in diesem Handbuch beschriebenen Betrieb können Störungen im Hochfrequenzbereich auftreten. Ein AXP1620, das als Ersatzteil, Austauschchassis oder unkonfiguriertes System ausgeliefert wird, enthält keine Platzhalter-Boards. Es liegt in der Kundenverantwortung sicherzustellen, dass alle leeren Steckplätze mit Boards, RTMs oder zugelassenen Platzhalter-Boards belegt sind, um die Sicherheits- und EMC-Vorschriften zu erfüllen.
  • Page 31 Ihrer Anlage. Stellen Sie sicher, dass Sie einen angemessenen Erdungsleiter gemäß der Auslegung des Zugangsleitungsschutzes verwenden. Bauen Sie das System sicher ein. Stellen Sie sicher, dass Kabel und Leitungen nicht im Weg sind. Stellen Sie sicher, dass der Systemaufbau anwenderfreundlich ist. AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 32 Während des Transportes und Zusammenbaus des Systems können sich Teile, wie zum Beispiel Schrauben, Blenden, Stecker oder Lüfter lösen oder beschädigt werden. Nehmen Sie das System nicht in Betrieb, wenn Teile beschädigt sind. Dies könnte zu AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com.
  • Page 33 Wird das RTM ausgebaut, während die Payload des dazugehörigen AdvancedTCA Boards noch nicht heruntergefahren ist, kann dies zu Beschädigungen am Board oder RTM führen. Fahren Sie deshalb die Payload des AdvancedTCA Blades immer herunter, bevor Sie das AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com.
  • Page 34 Beschädigung des Systems Durch hohe Luftfeuchtigkeit können Kurzschlüsse entstehen. Betreiben Sie das System nur innerhalb der angegebenen Grenzwerte für die relative Luftfeuchtigkeit und Temperatur. Stellen Sie vor dem Einschalten des Stroms sicher, AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com.
  • Page 35 Systemteilen führen. Um einen reibungslosen Luftstrom durch das System zu gewährleisten, sollten Sie den Luftfilter spätestens alle sechs Monate austauschen. Emerson empfiehlt, die Lüfter alle 90 Tage auszutauschen. Wie häufig Sie die Filter austauschen müssen, hängt von der Umgebung ab, in der das System betrieben wird. Da die Verhältnisse in Vermittlungsstellen sehr unterschiedlich sein können, sollten Sie die Luftfilter nach der...
  • Page 36 Gegenständen in der Nähe der PEMs. Kurzschluß und Gefahr durch Stromschlag Um einen elektrischen Schlag zu vermeiden, überzeugen Sie sich, dass vor dem Austausch des PEMs die Stromzufuhr unterbrochen ist und während des Austausches unterbrochen bleibt. AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 37 Handhabung erschweren können. Verkabelung/Kabelführung Verletzungsgefahr Verändern Sie nie die von Emerson ausgelieferte Verkabelung des Systems. Stellen Sie sicher, dass die Verkabelung schon existierenden Kabelführungen folgt und bestehende oder ähnliche Befestigungen verwendet. Überprüfen Sie nach der Erweiterung der Verkabelung, ob das System ordnungsgemäß arbeitet.
  • Page 38 Entsorgen sie alte Batterien entsprechend der in Ihrem Land gültigen Richtlinien. Umweltschutz Umweltschutz Entsorgen Sie alte Blades, RTMs und Systeme gemäß der in Ihrem Land gültigen Gesetzgebung und den Empfehlungen des Herstellers. AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 39: Platform Architecture

    Platform Architecture Description The versatile, highly available AXP1620 is designed as an open standard platform on which to run applications in the Telecom Central Office environments. The AXP1620 combines existing PICMG standards featuring high speed serial data fabrics. These standards serve to streamline the architecture by eliminating the overhead of bridging, increasing payload, and eliminating the need for system and nonsystem slot blades.

  • Page 40: Network Descriptions

    SAM. Each of the hub slots support a total of 16 base channels. The hub slots require connectors P23 and P24. The base node slots require only connector P23. AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com.

  • Page 41: Fabric Interface

    The fabric interface supports point-to-point connections between AdvancedTCA blades. In the AXP1620, these fabric connections are configured in a dual star topology that runs back to the hub slots. The AXP1620 system has one, two, or four channel slots. These channels are aggregated at the hub slots into the dual-star topology.

  • Page 42: Update Channel Interface

    The SAM connects to all slots in the shelf and monitors and reports on the content of the AXP1620. The SAM collects environmental data from sensors within the shelf and can assist high availability software to determine when a failover is necessary due to hardware removal or environmental changes, such as an over-temp condition.

  • Page 43: Backplane And Component Connectivity

    Operating Systems The AXP1620 comes installed with the following software: Wind River PNE-LE Enhanced Basic Blade Services (BBS) For more information, contact your Emerson sales representative for other software products for your configuration. AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com.

  • Page 44: Remote Management And Maintenance

    Remote Management and Maintenance Remote Management and Maintenance The AXP1620 supports remote critical management and maintenance procedures. This eliminates the need for on-site maintenance personnel to handle routine maintenance tasks. A standard Telnet connection for remote access to networked functionality provides the ability to:...

  • Page 45: Axp1620 Shelf Description

    AXP1620 Shelf Description Overview The AXP1620 Shelf supports 16 AdvancedTCA blade slots, of which 14 are I/O node slots that can be populated with task CPU processor blades, network processor blades, or any other blade designed for a specific application, and two slots for the system controller and switching blades.

  • Page 46: Figure 2-1 Front Shelf View

    AXP1620 Shelf Description Platform Features The following figure shows the location of each of the components in the AXP1620. Figure 2-1 Front Shelf View Alarm Display Panel ACT B COMM A COMM B ACT B ACT B COMM A COMM B...

  • Page 47: Enclosure

    FTM-2 FTM-1 FTM-1 Enclosure The AXP1620 shelf consists of a formed 13U sheet metal card cage with structure and support for the backplane, PEMs, FTMs, SAMs, and 16 card slots. Figure 2-1 on page 46 provides a front view of the shelf.

  • Page 48: Power Consumption

    PEMs, and all FTMs running at full speed. Shelf Ground Configuration The AXP1620 shelf was tested in the default configuration of logic ground and shelf ground connected and does not connect -48VDC Return with Shelf Ground. The Centellis 4620 platform has been tested in the default configuration and complies with safety and regulatory standards.

  • Page 49: E-Keying

    PEM B 2.6.2 E-Keying The AXP1620 supports the shelf management infrastructure with a process called E-Keying. E- Keying replaces the mechanical connector keying method used in earlier backplane designs. E-Keying prevents damage to blades, prevents misoperation, and verifies fabric compatibility.

  • Page 50: Shelf Fru Information

    The SEEPROMs are located on the Alarm Display Panel (ADP); the FRU information for the PEM is contained in FRU 0. This information is accessed by using the standard IPMI FRU commands over the IPMC. Refer to the AXP1620 Subsystem IPMI Programmer’s Reference listed in Appendix A, Related Documentation.

  • Page 51: Table 2-4 Slot Hardware Addressing For J10

    Open Open Open Open Table 2-5 Fan Tray Module Hardware Addressing Physical Site Slot Address Type Fan 1 Open Fan 2 Open AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 52: Zone Locations On A Blade

    ATCA Blade Backplane Hub A Hub B Zone 1 HA[7:0], LOGIC_GND, SHELF_GND, Metallic, Ring PEM A SAM A PEM B SAM B AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 53: Fan Tray Modules (Ftms)

    SAM B Fan Tray Modules (FTMs) The AXP1620 supports 2 fan trays in a push/pull configuration. Each fan tray contains 6 dual counter rotating fans. The lower fan tray is accessible from the front of the chassis and contains the replaceable air filter. The upper fan tray is located in the rear of the chassis.

  • Page 54: Figure 2-6 Lower Fan Tray Module, Front View

    AXP1620 Shelf Description Fan Tray Modules (FTMs) Figure 2-6 Lower Fan Tray Module, Front View Figure 2-7 Upper Front FTM, Front View AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 55: Power Entry Modules (Pems)

    IPMB_A IPMB_B Backplane IPMC_PWR Power Entry Module -48v -48v_RTN -48v +12V 8 ATCA 8 ATCA SAM A SAM B Slots Slots AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 56: Figure 2-9 Pem View With Detail

    Blink: Deactivation requested Glow Steady: no service Hot Swap (HS) Blue Off: PEM is not ready to be removed Blink: Deactivation requested Glow Steady: PEM is ready to remove AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 57: Stationary Boards

    It is possible to use this product with other components that produce a system not in compliance with system guidelines. Since Emerson cannot anticipate what equipment may be used with this enclosure or how it may be used, the responsibility for designing a system that conforms overall to the safety requirements, EMI/RFI emission limits, and other applicable standards rests entirely with the system integrator and installer.

  • Page 58: Weee Compliance

    To dispose of equipment marked with the WEEE symbol, Emerson has contracted with certified companies that can reprocess this equipment per European Union requirements. Please visit the Emerson web site or contact your Emerson representative to find out who to contact and how to dispose of the equipment.

  • Page 59: Figure 2-10 Declaration Of Conformity

    'LUHFWLYH DQG /RZ 9ROWDJH 'LUHFWLYH (PHUVRQ 1HWZRUN 3RZHU KDV DQ LQWHUQDO SURGXFWLRQ FRQWURO V\VWHP WKDW HQVXUHV FRPSOLDQFH EHWZHHQ WKH PDQXIDFWXUHG SURGXFWV DQG WKH WHFKQLFDO GRFXPHQWDWLRQ -RH )LQOD\VRQ 0DQDJHU 7HVW (QJLQHHULQJ ,VVXH GDWH $XJ   AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 60 AXP1620 Shelf Description WEEE Compliance AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 61: Site Preparation

    Then proceed to mount or service the system. Do not tilt the system forward or backward when removing it from the system package as the FRU ejector handles at the bottom could be damaged. AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com.

  • Page 62: Site And Installation Planning

    Planning basic site and installation requirements you have to consider the following issues: 1. Is adequate power for the AXP1620 system available? 2. Can the system be positioned in a way that -48 to -60V DC power source is easy to reach? 3.

  • Page 63: Requirements

    Some of the climatic values may exceed the specification of some system components (for example, hard disks). As Emerson cannot guarantee the functionality of third party products that are handled or operated out of their specifications, the environmental conditions may be limited to the specifications of these components.

  • Page 64: Table 3-2 Critical Temperature Limits

    The ambient temperature around the shelf and the air inlet temperature must not exceed 55°C (131°F). The AXP1620 system regulates the fan speed based on the temperature sensors present in the system. The fan speed is adjusted to the lowest speed which still keeps the evaluated temperature readings below or at their respective "upper non-...

  • Page 65: Power Requirements

    125A Operating voltage range -40.0 to -72VDC When installing additional blades or modules, make sure that the power consumption of all installed modules does not exceed the system's maximum power dissipation. AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 66: Dimensions And Weight

    To ensure the system is properly grounded, each of the system's parts contact the EMI gasket. The system contains gaskets at the shelf and module level. The shelf is also fitted with ESD contacts. Please take care for proper ESD protection of the operator. AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com.

  • Page 67: Airflow Requirements

    600mm Deep Cabinet 3.2.6 Airflow Requirements The AXP1620 provides fault tolerant cooling to front-mounted AdvancedTCA blades and to rear transition modules based on one front and one rear maintainable intelligent fan trays with six fans per tray. AXP1620 Installation and Use (6806800E23E) Arrow.com.

  • Page 68: Figure 3-2 Shelf Airflow

    The distance to other equipment must be sufficient to avoid an overheating of the system. If you install the system into a closed frame, ensure that the air inlet and outlet are kept free. AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com.

  • Page 69: Acoustic Noise Control

    Ensure that enough space is available Determine the needed power Plan the cable management Ensure proper cooling Schedule the arrival of the system Consider consulting of Emerson services AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 70: Figure 3-4 Planning Checklist 2

    What floor? Path to the installation area clear? Freight elevator available? How many shelves must be installed? Enough space available? DC or AC available All required cables available? AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 71: Axp1620 Operations

    AXP1620 Operations Overview This chapter provides the basic operating procedures for the AXP1620. For software-specific information, or information regarding the operation of third-party or add-on components, please refer to the software or hardware product’s vendor documentation. You can refer to...

  • Page 72: Recommended Power-Off Procedures

    2. Turn each circuit breaker on the front of PEM A and PEM B to the OFF position. Step 2 removes the input power from the slots in the AXP1620 shelf only. It does not remove power to the PEMs. To remove power to these components, refer to the next step.

  • Page 73: Description

    4.5.1 Description The AXP1620 has PICMG 3.0 compliant, dual PEMs and is rated for nominal -48VDC to -60VDC. The PEMs plug directly into the midplane and deliver power to the backplane. Each input is rated for 80 amps. The two 80 amp feeds each power eight AdvancedTCA slots and the upper and lower FTMs.

  • Page 74: Fan Tray Modules

    PEMs, backplane, FTMs, and SAMs. Fan Tray Modules This section discusses the operation of the Fan Tray Modules (FTMs) of the AXP1620. 4.6.1 Description The FTMs are loaded with AdvancedTCA IPMC firmware. The fans are controlled as a group through the IPMI-based interfaces (IPMB) to the SAM.

  • Page 75: Cooling Budget

    Visually inspect filters for tears or rips. Do not reinstall a torn filter as it will be ineffective in trapping particulates and will interrupt air flow distribution. To maintain safety certification, use only Emerson approved fan filters. You can order replacement fan filters (part number RAF1620) by contacting your Emerson sales representative.

  • Page 76: Cleaning The Air Filter

    AXP1620 Operations Cleaning the Air Filter Cleaning the Air Filter To ensure the AXP1620 shelf operates properly, routine filter maintenance is required as discussed in Air Filter Maintenance. Maintenance includes cleaning, replacing, and properly storing the air filters. Filter cleaning frequency depends on the environment the system is subjected to. The shelf filter requires routine cleaning to ensure effective filtration and airflow.
  • Page 77 - 90°F) yields an acceptable environment. Covering the filters with dark plastic keeps the foam dry and protects it from ultraviolet light. Purchase enough to keep adequate inventory for no more than a few months, filters could degrade under long term storage conditions. AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com.
  • Page 78 AXP1620 Operations Storing the Filter AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 79: Axp1620 Shelf Installation

    AXP1620 Shelf Installation Overview This chapter discusses mounting and installation options for the AXP1620 shelf. The topics covered are: Installation Prerequisites Installing the Shelf DC Power Cable Connecting the Cables to the PEM Grounding the Shelf Shelf Ground Configuration Powering Up the System...

  • Page 80: Installation Prerequisites

    This section describes the prerequisites required for installation. 5.3.1 Equipment You Will Need You will need the following to install the AXP1620 16-slot shelf into an approved EIA 23" or 600mm x 600mm ETSI frame: Torque wrench Nut driver with 7/16mm socket...

  • Page 81: Figure 5-1 Rack Mounting Dimensions

    Rear Door 25mm Thick Door, 2X 13U Shelf Side View to Door Air Inlet 75mm 42mm 550mm Inside, Door to Door 600mm Deep Cabinet AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 82: Mounting Options And Stabilization

    5.3.3 Mounting Options and Stabilization The AXP1620 is designed to be mounted in an equipment rack while maintaining conformance to the NEBS 24" deep lineup and the ETSI 600mm deep lineup standards for telecommunication equipment. For increased stability, we recommend that the rack is securely mounted to the floor, or if using stabilizing devices make sure they are installed and extended.

  • Page 83: Electrostatic Discharge (Esd) And Safety Procedures

    There are three ESD bonding points, two on the front and one on the back of the shelf. Installing the Shelf The AXP1620 can be mounted in a 23" EIA or 600mm ETSI frame using front mounting brackets. Using rear mounting brackets is recommended for all frame types when installed in a Central Office Environment.

  • Page 84: 23" Eia Rack/Cabinet

    The shelf mounts directly from the integrated flange on the front of the shelf. Locate the standard mounting hole and slot locations on the front integrated mounting flanges on the AXP1620 shelf. Fasten the mounting brackets to the back side of the front chassis flanges using M6 screws x 12mm at each of the 5 locations.

  • Page 85: Grounding The Shelf

    As a compliant AdvancedTCA shelf, the AXP1620 allows system integrator at their own discretion to remove the mechanism which connects Logic Ground to Shelf Ground and install the mechanism that connects -48VDC Return to Shelf Ground.

  • Page 86: Dc Power Cable

    L'entretien de cet équipement doit être effectué par du personnel de service qualifié. Wire Signal Earth Ground PE GND (Primary Earth Ground) Input power -48VDC nominal to -60VDC Return -48VDC RETURN AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 87: Power Cable Termination

    Heat shrink should be placed as close to the hole as possible (0.15") apart. The heat shrink tube should be cut approximately at a 30° angle. AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com.

  • Page 88: Connecting The Cables To The Pem

    If the DC potential is 3.0VDC or less, then power is not present. 5. Attach the DC power cables (input and return) to the dual lug bolts on each PEM. AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com.

  • Page 89: Powering Up The System

    9600, data bits 8, parity None, stop bits 1, flow control None. The system is shipped with a default password of mot. Custom cables are required for these connectors. Refer to RS-232 Serial Interface on page 123 for pin assignments. AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 90: Upgrading Firmware

    5.12.1 FTM IPMC Firmware Upgrade There is a single IPMC firmware image common to the two FTMs in the AXP1620. The FTM IPMCs are assigned IPMB addresses 0x56 and 0x58. Different upgrade image variants are generated as part of the release, but only one file is required for the normal field upgrade process.

  • Page 91: 5.12.1.1 Ftm Upgrade Sample Output

    Hot Swap State: M4 (Active), Previous: M3 (Activation In Process), Last State Change Cause: Normal State Change (0.0) Device ID: 0x00, Revision: 0, Firmware: 0.00 (ver 0.0.0), IPMI ver 0.0 Manufacturer ID: 000000, Product ID: 0000, Auxiliary Rev: 00000000 AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com.

  • Page 92: Pem Ipmc Firmware Upgrade

    5.12.2 PEM IPMC Firmware Upgrade There is a single IPMC firmware image common to the two PEMs in the AXP1620. The PEM IPMCs are assigned IPMB addresses 0x66 and 0x68. The file containing the firmware image is pem1620.img. As upgrades are released, Emerson will supply the current version of this file.

  • Page 93: Shelf Manager Firmware Upgrade

    SAM1500 FPGA. The SAM1500 FPGA will be programmed automatically (if necessary) by the process. As upgrades are released, Emerson will supply the current version of these files. Shelf Manager Upgrade Steps The upgrade process involves the following steps.

  • Page 94: 5.12.3.1 Establishing Network Connectivity To The Sam

    # setenv ip1addr W.X.Y.Z (substituting your address) # ifconfig eth1 W.X.Y.Z 3. If your file server (for Emerson files) is on a different subnet, : # route add default gw W.X.Y.Z (you will need to do this each time you reboot) If you use the Uboot environment variable gatewayip, the route is set automatically at reboot (setenv gatewayip W.X.Y.X)

  • Page 95: 5.12.3.2 Update Shm Firmware On The Sam

    Shelf Manager Firmware Upgrade AXP1620 Shelf Installation 5. Ping the file server containing the Emerson files. You should get a response if the Ethernet cable is connected. 6. Set the environment variable that keeps the front panel Ethernet interface enabled following a reboot.
  • Page 96 AXP1620 Shelf Installation Shelf Manager Firmware Upgrade AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 97: Fru Installation

    If you are going to install an RTM and an AdvancedTCA blade, you have to regard the following sequence: First install the RTM, then install the matching AdvancedTCA blade. Otherwise the blades and RTMs will be damaged. AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com.

  • Page 98: Module Installation And Removal

    3. Wait until the blue LED on the front blade is ON. This indicates that the front blade’s payload is powered down. AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com.
  • Page 99 Continue to gently push the RTM until the RTM connectors engage. 8. Squeeze the lever and the latch together and hook the lower and the upper handle into the shelf rail recesses. AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com.
  • Page 100 12.Wait until the blue LEDs of both the front blade and the RTM are OFF. A switched OFF blue LED indicates that the payload of the respective blade or RTM has been powered up and is active. 13.Plug interface cable into face plate connectors, if applicable. AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com.
  • Page 101 Continue to gently push the RTM until the RTM connectors engage. 6. Squeeze the lever and the latch together and hook the lower and the upper handle into the shelf rail recesses. AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com.
  • Page 102 12.Wait until the blue LEDs on both the front blade and the RTM are OFF. Switched off blue LEDs indicate that the payload of the respective blade or RTM has become active. 13.Plug interface cable into face plate connectors, if applicable. AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com.

  • Page 103: Removing The Rtm

    Before removing the RTM from a powered system, power down the slot by opening the lower handle of the front blade and wait until the blue LED is permanently ON. AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com.

  • Page 104: Node Blade Installation And Removal

    When plugging the blade in or removing it, do not press on the face plate but use the handles. 6.2.2.1 Installing the Node Blade To install the blade into an AdvancedTCA shelf, proceed as follows. AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 105 Continue to gently push the blade until the blade connectors engage. 4. Squeeze the lever and the latch together and hook the lower and the upper handle into the shelf rail recesses. AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com.
  • Page 106 7. Connect cables to the face plate, if applicable. After the blade has been inserted, you have to ensure that a boot image is either present on the ATCA-F120 or on the blade’s hard disk. AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com.

  • Page 107: Removing The Node Blade

    Data Loss Removing the blade with the blue LED still blinking causes data loss. Wait until the blue LED is permanently illuminated, before removing the blade. 3. Remove face plate cables, if applicable. AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com.

  • Page 108: Installing And Removing The Shelf Management Alarm Module

    Before touching the blade or electronic components, make sure that you are working in an ESD-safe environment. 6.2.3.1 Non-Powered System This section describes the installation procedure for the SAM in non-powered systems. AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 109: Powered System

    3. Insert the module into the shelf by placing the top and bottom edges of the board in the card guides of the shelf. Ensure that the guiding module of shelf and board are aligned properly. The alignment pin facilitates the insertion and prevents bent pins. AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com.

  • Page 110: Unused Slots

    There are filler blades sized for the front and for the RTM slots. An unused slot can not contain a front filler when an AdvancedTCA RTM is installed. When fillers are used, both the front and RTM filler must be in place. Filler blades are available from Emerson. AXP1620 Installation and Use (6806800E23E) Arrow.com.

  • Page 111: Installing Power Entry Modules

    FRU Installation Installing Power Entry Modules The AXP1620 shelf supports two Power Entry Modules (PEMs). Since the shelf is equipped with a redundant power distribution system, the removal of a single PEM does not interrupt system operation. PEMs are accessible from the rear of the shelf. Each PEM has EMI gaskets on all sides of the module that provide EMI shielding.
  • Page 112 The terminal block cover is attached to the terminal block by two tabs with slots in the cover that insert into embossments in the terminal block wall. To remove the cover, press the upper wall of the terminal block AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com.

  • Page 113: Upper And Lower Fan Tray Modules

    Please read the following caution before replacing any of the FTMs. Fans may continue to rotate after power is removed. Be careful to keep fingers away from the bottom of the FTM enclosure. AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com.

  • Page 114: Removing The Upper Ftm

    FTM until the ejector handles engage; fully close the handles. The FTM is connected when the assembly is firmly seated in the upper backplane connector and the hot swap handle moves to the closed position. AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com.

  • Page 115: Removing The Lower Ftm

    FTM until the ejector handles engage; fully close the handles. The FTM is connected when the assembly is firmly seated in the upper backplane connector and the hot swap handle moves to the closed position. AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com.

  • Page 116: Replacing The Fan Filter

    Visually inspect filters for tears or rips. Do not reinstall a torn filter as it will be ineffective in trapping particulates and will interrupt air flow distribution. To maintain safety certification, use only Emerson approved fan filters. You can order replacement fan filters (part number RAF1620) by contacting your Emerson sales representative. For detailed information on filter...

  • Page 117: Figure 6-4 Position Of The Fan Filter

    Position of the Fan Filter Velcro 5. Lower the vane assembly and rotate the filter bracket into place. 6. Reinstall the lower FTM using the procedure described in Installing the Lower FTM. AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 118 FRU Installation Replacing the Fan Filter AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 119: Shelf Management Alarm Module

    Management Mezzanine Module (ShMM) which installs on the carrier blade. Two SAMs are installed into two dedicated shelf manager slots located at the bottom-rear of the AXP1620 16-Slot Shelf. The SAM is hot swappable and the connectors are accessible through the face plate.

  • Page 120: Features

    Control of chassis cooling management (fan levels) For additional information on the above operations and the Command Line Interface, refer to the AXP1440/AXP1620 Subsystem IPMI Programmer’s Reference guide and the Pigeon Point Shelf Manager External Interface Reference, Release 2.5.3, respectively.

  • Page 121: Sam Diagram And Face Plate Layout

    One link to the redundant SAM – One link to the face plate One Ethernet link, failover management status signals, and one IPMB branch or segment to the other SAM AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 122: Functional Description

    C-based hardware monitoring/control and GPIO expander devices. 7.4.1 IPMB Connectivity The IPMB is a dual radial topology. Each IPMC in the shelf connects to both SAMs for a redundant IPMB. AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 123: Serial Interface

    EEPROM devices. Additional I C devices connected to the bus on the SAM are used for the following functions: System hardware monitoring and control GPIO extension, for various purposes AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 124: Shelf Fru Seeprom

    Shelf FRU SEEPROM The SAM provides access to the SEEPROMS on the Alarm Display Panel (ADP) through the master-only I C. Information stored on the ADP contains Emerson OEM records that enable the SAM to self-configure for the AXP1620 shelf. 7.4.5 SAM LEDs The SAM provides the LEDs listed in the following table.

  • Page 125: Sam/Adp Status Leds

    SAM. Detailed information on sensors can be found in the AXP1620 Subsystem IPMI Programmer’s Reference. 7.5.1 Hardware Monitoring and Control The hardware monitoring and control functions implemented by the AXP1620 are provided by the on-board I C-based devices. 7.5.1.1 Voltage Sensors On-board sensors provide the following power supply voltages.

  • Page 126: Table 7-7 Cooling Budget

    Using the above algorithm, at 40°C ambient, the cooling algorithm adjusts the fan speeds to maintain a deltaT rise in temperature at 15°C. Table 7-7 Cooling Budget Ambient Temperature Temperature Rise 25°C Delta T = 20° C AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 127: Redundancy Control

    Both ShMM-1500Rs monitor each other, and either can trigger a switchover if necessary. The ShMM-1500R provides a number of hardware redundancy signals on the CN1 connector. The HRI is implemented using the FPGA device. AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com.

  • Page 128: Hardware Redundancy Interface

    ShMM-1500R. Figure 7-3 SAM HRI Interconnection F_ShMM_STATUS 0 ShMM-1500R A ShMM-1500R B F_ShMM_STATUS 1 PRES# ShMM-1500R A buffer ShMM-1500R B buffer AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 129: Hri Protocol

    The backplane has cross-connects between each hub slot and other SAM. Figure 7-4 Interhub Slot and Shelf Manager Connectivity ATCA-F120 ATCA-F120 Hub Slot 1 Hub Slot 2 SAM A SAM B Front Panel Front Panel AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 130: Switchover Signals

    LED blinks and all of the alarm relays are deactivated. This button does not clear alarms. Refer to Figure 7-2 on page 122 for the location of the alarm cutoff push button switch. AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 131: Telco Alarm Leds

    The interface is composed of three components: Injector/Ejector handle switch Presence signal indicating that the SAM is fully seated in its backplane connector HS LED to indicate safe to remove state AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com.

  • Page 132: Power

    Fri Jun 6 14:51:44 2008 Image Type: PowerPC Linux Firmware (uncompressed) Data Size: 212992 Bytes = 208.00 kB = 0.20 MB Load Address: 0xF0000000 Entry Point: 0x00000000 AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 133 From the sample output, it is possible to see the compilation dates of the U-Boot, RFS, and Kernel images for both the active and nonactive firmware banks. Compilation times will never be identical for all three images, but should be relatively close to each other. AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com.
  • Page 134 Shelf Management Alarm Module imls Utility AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 135: Related Documentation

    The publications listed below are referenced in this manual. You can obtain electronic copies of Emerson Network Power - Embedded Computing publications by contacting your local Emerson Sales Office. For released products, you can also visit out Web site for the latest copies of our product documentation.
  • Page 136 PICMG 3.0 AdvancedTCA Serial Interconnect Specification R2.0 PICMG 3.0, R2.0 PICMG 3.1 AdvancedTCA Ethernet/Fibre Channel, Revision 1.0 PICMG 3.1 R1.0 January 22, 2003 PICMG 3.0 ECN 3.0-1.0-001 January 21, 2004 ECN 3.0, 1.0-001 AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 137 Closed frame Filler blade command line interface Filter configuring the I2C bus AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 138 Blue power supply voltage LEDs power to FTM behavior power-off, emergency face plate, SAM power-on face plate, SAM1500 Preparing the site AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 139 Shelf manager shelf, description Shipment Zone 1 description ShM/ATCA-M100 Zone 2 description ShMC, see shelf management controller Zone 3 description Site preparation slot addressing, PEM AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 140 AXP1620 Installation and Use (6806800E23E) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

Table of Contents
