- Page 1 XA200P SERIES UPS’s XA206P – XA210P – XA215P XA220P – XA230P 6-10-15-20-30 kVA 3 Phase Input – 1 Phase Output USER MANUAL...
-
Page 3: Table Of Contents
CONTENTS GENERAL DESRCIPTION ..................1 1.1 Introduction ......................1 1.1.1 Cautions for service personal ..............1 1.1.2 Battery cautions..................1 1.2 XA200P UPS block diagram ................1 1.3 Technical Specifications ..................4 FRONT PANEL ......................5 2.1 Introduction ....................... 5 2.2 Front Panel Menu Descriptions ................ - Page 4 VI. MAINTENANCE ......................22 6.1 Scheduled Maintenance ..................22 6.2 Daily checks ...................... 22 6.3 Weekly checks ....................22 6.4 Annual maintenance ..................23 6.5 UPS Storage and transportation ................ 23 VII. FAULTS AND TROUBLESHOOTING ..............24 7.1 General procedure for fault checking and troubleshooting ........24 VIII.
- Page 5 IMPORTANT SYMBOLS Symbols used in a UPS are classified as SAFETY and OPERATING categories as shown below. SAFETY SYMBOLS HIGH VOLTAGE. WEIGHT. ISOLATED LEAD – ACID BATTERY. Pb H OPERATING SYMBOLS READ INSTRUCTION MANUAL. ATTENTION, FOLLOW INSTRUCTIONS BELOW.
-
Page 7: General Desrciption
ı. GENERAL DESRCIPTION Introduction Messages displayed on the front panel are subject to change depending on the developments in UPSs. But the Axx codes in front of the alarm messages are always the same. To be informed by the latest develop- ments in software. - Page 8 Switches : Battery circuit breaker & fuse : ON – OFF and By Pass switch & fuse F3-F4-F5 : Rectifier input switch – Input switch & fuse : Maintenance By Pass switch. : Output switch. • F1 – Battery circuit breaker & fuse Located at the input side of the device.
- Page 9 Emergency Stop Switch I/P RS232 Communication Socket (DB9 Female) ( RS232 / SNMP ) Communication Select Switch (optionmal) Maintenance ByPass Switch Battery Fuse ON - OFF Switch F3-F4-F5 Input Switch Output Fuse Figure 1-3 Fuse and Switch Locations...
-
Page 10: Technical Specifications
1.3 Technical Specifications MODEL Output kVA Output kW 10,5 Output Power Factor Parallel Operation Up to 4 UPS’s (optional) Battery charging temperature compensation Optional Serial Communication RS232 (optional SNMP, RS485 or MODBUS) INPUT Input voltage 220/380 or 230/400Vac 3 Phase, N ±... -
Page 11: Front Panel
II. FRONT PANEL WARNING! The messages in this section are applicable for equipments having software version Y11P. If the version changes, the messages and functions will change as well. 2.1 Introduction The front panel of UPS, consisting of a 2 lines alphanumeric display, 2 status lamps, plus 4 function keys, allows the complete monitoring of the UPS status. -
Page 12: Main Menu
SAMPLE menu selection : If you want to go to MEASURES menu use UP and DOWN keys and find MEASURES MENU,press ENTER key,now you can move on MEASURES menu subitems by UP and DOWN keys. At the end of sub menus ENTER (EXIT) message is available and while reading this message, if you press ENTER key you can go back to MAIN menu. -
Page 13: Measures Menu Items
Submenu item Function The purpose of this submenu to check dry contact connections. Normally to check line failure contact you must turn off mains power. This is not neces- sary with this utility. 3 options are available. SIMULATION OFF simulation mode is off SIM:LINE FAILURE if you press ENTER key for 3 seconds the line failure 5 SIMULATION OFF lamp on interface board is turned on. -
Page 14: User Options Menu Items
2.2.5 USER OPTIONS Menu items From this menu the user selects some important parameters and apply them. Submenu item Function 4 Operating modes can be selected using up and down buttons. ONLINE: normal operating mode. PARALLEL: Symmetric parallel operation mode of 2 UPS’s. 1 MODE: ONLINE HOT STANDBY: 1 UPS is master and 1 UPS is redundant operating mode. -
Page 15: Time Menu Items
2.2.6 TIME Menu items You can see date and time of RTC (real time clock) on UPS. And you can adjust date and time. Submenu item Function TIME : 23 :15 time DATE : 11-10-2007 date SET HOURS: 11 (+) and (-) adjust hours (0-23) SET MINS : 38 (+) and (-) adjust minutes (0-59) SET DAY : 21... -
Page 16: Status Messages
STATUS Messages This message group simply shows the UPS STATUS at the upper line of LCD PANEL. RECTIFIER START ! UPS started the rectifier ENTER START : Press ENTER to start the UPS. INVERTER START ! UPS started the inverter. MAINT SWITCH ON ! Maintenance bypass switch is on STATUS NORMAL ! -
Page 17: Fault Messages And Quick Troubleshooting
2.5 Fault messages and quick troubleshooting All alarms contained in Y11P version are listed in the following table. ALARM POSSIBLE CAUSE A1 BYPASS FAILURE Bypass system failure. Bypass elements may be broken. A2 INVERTER FAILURE Inverter digital start system is failed. Call the service. Overtemperature in UPS repeated 3 times in 30 min. - Page 18 ALARM POSSIBLE CAUSE UPS input phases sequence is not correct A21 ROTATE PHASE 1) Turn off the UPS and rotate phase sequence 2) Turn on UPS again Output OFF alarm A22 OUTPUT OFF - Output switch may be off. - A fault may be in the output. Check the output components. In parallel operation the slave device tries to operate as the same mode as the master device, If the modes are different this message will appear.
-
Page 19: Parallel Operation
III. PARALLEL OPERATION 3.1 Introduction Up to four of XA200P UPS can be used in parallel mode, the purpose of parallel use:: • Redundancy • Power increment purpose. 3.1.1 Redundancy Even if UPS designs are perfect sometimes some failures are possible. Also the lifetime of batteries and some parts are limited. -
Page 20: Redundant Parallel Mode
3.2.1 Redundant Parallel Mode At this mode if one of the UPS’s fails the other UPSs continues to supply the load. Assume that UPS1 on figure 3-1 is failed, SB1 and SB2 static switches will turn off and the UPS 1 is isolated from load. - Page 21 NOTE : OUTPUT CONNECTIONS MUST BE OF EXACTLY THE SAME LENGTH. CAUTION : During operation do not turn off CB1, CB2, CB3 or CB4, first turn off the UPS output switch then turn off the CB1, CB2, CB3 or CB4. Figure 3-2 Parallel UPS Connection.
-
Page 22: Effects Of The Parallel Configuration On Xa200P Series Ups
3.5 Effects of the parallel configuration on XA200P series UPS If the parallel card is installed on a XA-200P series UPS some calibrations of the UPS will be changed. ( e.g.: output voltage and symmetry adjustment) Do not select ONLINE mode if the UPS is parallel configured, please select REDUNDANT MODE, in this case, if digital PARALLEL communication connector is not connected the UPS, it gives A28I PLUG IN DIG. -
Page 23: Ups Installation
IV. UPS INSTALLATION 4.1 Introduction WARNING!!! • Do not apply electrical power to the UPS equipment before the arrival of authorized service personnel. • The UPS equipment should be installed by a qualified service personnel. • The connection of the batteries and the maintenance should be done by the qualified service personnel. •... -
Page 24: Connecting The Ups Power Cables
4.4 Connecting The UPS Power Cables WARNING!!! A separate line should be used to supply the UPS AC input. Never use the same line to supply another electrical devices. Do not use any additional cable to increase the length of the UPS’s input cable. -
Page 25: Cable Connection Procedure
4.4.2 Cable connection procedure WARNING!!! All connections of the UPS must be done by a qualified service personal. After positioning the UPS, the cables must be connected as described below: 1. Verify all switches of the UPS in “0” position. 2. -
Page 26: Battery Installation
4.4.4 Battery Installation WARNING!!! Becareful while connecting batteries. ATTENTION!!! Remove the battery fuse before making the connection of the battery circuit breaker box dur- ing the battery installation. The batteries associated with the UPS equipment are usually contained in a purpose-built battery cabinet, which sits alongside the main UPS equipment. -
Page 27: Operating Instructions
V. OPERATING INSTRUCTIONS 5.1 First operating and Power ON : 1. Battery switch must be off. (“0” position) 2. MBS (Maintenance by-pass) switch must be in “0” position. 3. F3-F4-F5 switches must be in “1” position. 4. Turn F6 (Output) switch into “1” position. 5. -
Page 28: Maintenance
VI. MAINTENANCE WARNING!!! DO NOT OPEN the cover of the UPS because there is no part that can be maintained by the user. DO NOT TOUCH battery leads. There is high voltage even if the UPS is off. Therefore no one should open the cover of the UPS except the service personal. -
Page 29: Annual Maintenance
Annual maintenance To get reliable and efficient performance from the UPS, please call the qualified service personal once a year. 6.5 UPS Storage and transportation 1- Check the batteries charge by performing manual battery test before storage. If the charge is not enough then charge the batteries at least for 12 hours. -
Page 30: Faults And Troubleshooting
VII. FAULTS AND TROUBLESHOOTING 7.1 General procedure for fault checking and troubleshooting UPS contains complicated electronic control circuits. In order to locate any fault occurring circuits, an ad- vanced knowledge about the circuitry and its operation principles must be known. The aim of this section is to give the knowledge required at the first intervention. -
Page 31: Ups's Remote Control Connection
VIII. UPS’s REMOTE CONTROL CONNECTION Following external connections are available at XA200P series • Communication By serial port connection • Dry contact (interface board) connection 8.1 Using Serial Port A standart Serial communication port is installed to all XA200P series UPS, by using this port user can take all information about UPS. -
Page 32: Serial Port Connection Cable
8.2 Serial port connection cable RS485 cables connections are as follows: UPS Side Panel Side 9 Tx 2 Rx 7 Gnd 5 Gnd 6 Rx 3 Tx 8.3 Remote control/connection with a modem The UPS connects to a phone line using its RS232 port and a modem. The operator connects to the UPS by a computer containing TMON program and a modem. -
Page 33: Smart Modem (Sm) Configuration (Programming)
AT Command Description ATS0=1 Modem will auto-answer after one ring. AT&K0 Flow control disable in some modem models (Check for equivalents in other types) AT&D0 DTR signal usage. AT&Y0 Load 0 setting values at the modem start. Speed configu- Look for speed configuration table (Below) ration string AT&W0 Save the values in table as 0... -
Page 34: Modem Connection Cables
8.3.4 Modem connection cables A standard modem connection cable is used to connect SM to a PC. This cable is required if an external mo- dem is used, but instead if an internal modem is used then no need for this cable. The connection cable between the UPS and DM must as follows: MODEM UPS DB9 Pin... - Page 36 AGKK5594 12/2012...
