Summary of Contents for Tescom XC Series
- Page 1 XC SERIES 1 kVA ON-LINE NINTERRUPTIBLE OWER UPPLIES USER MANUAL...
-
Page 3: Table Of Contents
CONTENTS INTRODUCTION 1.1 System Description ..............1 1.2 Technical Specifications ............2 1.3 Physical Specifications ............2 SETTING UP YOUR UPS 2.1 Unpacking ................3 2.2 Location Selection ..............3 2.3 Installation ................3 2.4 Start–up ................... 4 III. OPERATION PROCEDURE 3.1 Turn On Procedure .............. - Page 5 IMPORTANT NOTICES 1 . Read instructions carefully before operating the UPS 2 . All warnings in the manual should be adhered to. 3 . All operating instructions should be followed. 4 . The unit should be supplied by a grounded outlet. DO NOT operate the unit without ground source .
-
Page 6: Introduction
When incoming power is interrupted, the UPS protects the computers instantaneously without any transfer time. The XC Series has high nonlinear load capability (i.e. Crest Ratio 3:1) and this is suitable for powering special loads such as switching power supplies or highly capacitive inputs. -
Page 7: Technical Specifications
XC Series 1kVA User Manual 1.2 Technical Specifications XC-101 Output Power (pf 0.7) 1 kVA - 700W INPUT ± 20% Voltage 220 Vac or 230Vac 1 Ph+N 50 Hz. ±5 % Frequency Current Power Factor >=0,9 OUTPUT Voltage 220 Vac or 230Vac ±... -
Page 8: Unpacking
XC Series 1kVA User Manual II. SETTING UP THE UPS 2.1 Unpacking The UPS is packed and enclosed in a structural cardboard carton to protect it from danger. 1. Inspect for damage that may have occurred during the shipment If any damage is noted, call the shipper immediately and retain the shipping carton and the UPS. -
Page 9: Start-Up
XC Series 1kVA User Manual 2.4 Start-Up 1. Turn on the on-off switch on the rear panel to "1" . 2. The red LED indicator "BYPASS" should light on. 3. In a few seconds the cooling fan will start to operate, then the "BYPASS” indicator will be off and the green LED indicator "UPS"... -
Page 10: Operation Procedure
XC Series 1kVA User Manual III. OPERATION PROCEDURE 3.1 Turn On procedure 1 . Turn On the PK1 on-off switch on the rear panel to "I" position. 2 . Turn on the power switches on your critical load after the "UPS" indicator will light on. -
Page 11: Manuel Battery Test System
XC Series 1kVA User Manual Manual Battery Test System If you push the two buttons together on the front panel for 2 sec. , the UPS will start the battery test operation and the "BATT.CHK." will appear on the LCD panel . At the end of the test the system will turn to normal position. -
Page 12: Customer Service
XC Series 1kVA User Manual IV. CUSTOMER SERVICE WARNING There are no customer serviceable components inside. DO NOT open the cover or attempt to service the unit. High voltage may remain when the unit is shut down. Unauthorized service will void the warranty and could cause serious injury. -
Page 13: Lcd Display
XC Series 1kVA User Manual 4.2 LCD DISPLAY (2) DISPLAY (1) SOUND SELECT ON-OFF BUTTON STATUS Figure 2 Front Panel INDICATORS This panel shows the systems operation such as input and output Voltages,Frequency,load status etc. FIRST MESSAGE LINE LOAD : It shows the percentage of the load connected to the UPS output LINE : It shows the Line Voltage at the UPS input. -
Page 14: Error Codes
XC Series 1kVA User Manual PUSH BUTTONS 1. SOUND ON-OFF BUTTON : When you push this button it will disable the audible alarm on the UPS. If you want to enable the sound alarm again you have to push the DISPLAY SELECT button . -
Page 15: Limited Warranty
XC Series 1kVA User Manual V. LIMITED WARRANTY The UPS is warranted against all defects in workmanship and materials under normal use for a period of one (1) year from the date of shipment to the original user. The conditions of... - Page 16 XC Series 1kVA User Manual AGKK1482 10/2002...
