- Page 1 XA-200P SERIES UPS’s XA-240P XA-245P 40 – 45 kVA 3 Phase Input – 1 Phase Output USER MANUAL...
-
Page 3: Table Of Contents
3.3 Parallel Operation Mode Fault Codes ..............16 3.4 Parallel System Accessories ................16 3.5 Effects of the parallel configuration on XA-200P series UPS ......18 3.6 Taking off the parallel devices from a UPS ............18 IV. UPS INSTALLATION ....................19 4.1 Introduction ...................... - Page 4 VI. MAINTENANCE ...................... 24 6.1 Scheduled Maintenance ..................24 6.2 Daily checks ...................... 24 6.3 Weekly checks ....................24 6.4 Annual maintenance ..................25 6.5 UPS Storage and transportation ................ 25 VII. FAULTS AND TROUBLESHOOTING ..............26 7.1 General procedure for fault checking and troubleshooting ......... 26 VIII.
-
Page 5: Safety
SAFETY This manual contains important instructions for XA-200 series UPS that should be followed during installation and maintenance. IMPORTANT NOTICES 1. Read instructions carefully before operating the UPS 2. All warnings in the manual should be adhered to. 3. All operating instructions should be followed. 4. -
Page 6: General Desrciption
I. GENERAL DESRCIPTION Thank you for selecting this uninterruptible power supply (UPS). To choose the XA-200 series as your equip- ment protector was a wise investment. It includes many features to protect your critical equipments. The XA-200 series UPS system is connected between mains and critical loads, such as computer systems, telecommunication systems, computerized instruments etc. -
Page 7: Xa-200P Ups Block Diagram
transfer back to the inverter automatically when the overload condition has been cleared. If the inverter fails internally, the unit switches to bypass within a few milliseconds. XA-200P UPS block diagram S3 (MBS) Maintenance Bypass Static Transfer Switch On-Off Micro switch 1 Phase 3 Phase Output... - Page 8 Switches : (Rectifier) input power switch : Static by-pass & On-Off switch : Maintenance by-pass power switch : UPS Output switch : Battery circuit breaker (optional) • S1 – (Rectifier) input switch These switches connect the line input to the input of the rectifier/charger. All power supplies in the equipment connected to this switch.
- Page 9 Emergency Stop Switch I/P RS232 Communication Socket (DB9 Female) ( RS232 / SNMP ) Communication Select Switch (optionmal) Static By-pass & On-Off Switch Output Switch Input Switch Maintenance By-pass Switch Figure 1.2 Fuse and Switch Locations...
-
Page 10: Technical Specifications
1.3 Technical Specifications MODEL XA-240P XA-245P Output kVA Output kW 31,5 Output Power Factor Parallel Operation Up to 4 UPS’s (optional) Battery charging temperature compensation Optional Serial Communication RS232 (optional SNMP, RS485 or MODBUS) INPUT Input voltage 220/380 Vac 3 Phase, N ±... -
Page 11: Front Panel
II. FRONT PANEL WARNING! The messages in this section are applicable for equipments having software version Y11P. If the version changes, the messages and functions will change as well. 2.1 Introduction The front panel of UPS, consisting of a 2 lines alphanumeric display, 2 status lamps, plus 4 function keys, allows the complete monitoring of the UPS status. -
Page 12: Main Menu
SAMPLE menu selection: If you want to go to MEASURES menu use UP and DOWN keys and find MEASURES MENU ,press ENTER key ,now you can move on MEASURES menu subitems by UP and DOWN keys. At the end of sub menus ENTER (EXIT) message is available and while reading this message, if you press ENTER key you can go back to MAIN menu. -
Page 13: Measures Menu Items
Submenu item Function The purpose of this submenu to check dry contact connections. Normally to check line failure contact you must turn off mains power. This is not neces- sary with this utility. 3 options are available. SIMULATION OFF simulation mode is off SIM:LINE FAILURE if you press ENTER key for 3 seconds the line failure 5 SIMULATION OFF lamp on interface board is turned on. -
Page 14: User Options Menu Items
2.2.5 USER OPTIONS Menu items From this menu the users selects some important parameters and apply them. Submenu item Function 4 Operating modes can be selected using up and down buttons. ONLINE: normal operating mode. PARALLEL: Symmetric parallel operation mode of 2 UPS’s. 1 MODE: ONLINE HOT STANDBY: 1 UPS is master and 1 UPS is redundant operating mode. -
Page 15: Time Menu Items
2.2.6 TIME Menu items You can see date and time of RTC (real time clock) on UPS. And you can adjust date and time. Submenu item Function TIME : 23 :15 time DATE : 11-10-2001 date SET HOURS: 11 (+) and (-) adjust hours (0-23) SET MINS : 38 (+) and (-) adjust minutes (0-59) SET DAY : 21... -
Page 16: Status Messages
S1 (inverter input) switch and turn on again. SHUTDOWN MESSAGES : XA-200P series UPS’s can operate interactive with operating system, you can send commands to UPS from operating system by using some softwares .UPS takes this commands and produces some messages these... -
Page 17: Fault Messages And Quick Troubleshooting
2.5 Fault messages and quick troubleshooting All alarms contained in Y11P version are listed in the following table. ALARM POSSIBLE CAUSE A1 BYPASS FAILURE Bypass system failure. Bypass elements may be broken. A2 INVERTER FAILURE Inverter digital start system is failed. Call the service. Overtemperature in UPS repeated 3 times in 30 min. - Page 18 ALARM POSSIBLE CAUSE UPS input phases sequence is not correct A21 ROTATE PHASE 1) Turn off the UPS and rotate phase sequence 2) Turn on UPS again Output OFF alarm A22 OUTPUT OFF - Output switch may be off. - A fault may be in the output. Check the output components. In parallel operation the slave device tries to operate as the same mode as the master device, If the modes are different this message will appear.
-
Page 19: Parallel Operation
UPS to the system. 3.2 Parallel Operation Mode NOTE: Parallel control board and some accessories are not installed in a standard XA-200P series UPS, but parallel operation option is available for these models. User can select parallel operation mode as an option according to purpose. If parallel control board is installed in your UPS, you can select operation mode from SETTINGS MENU. -
Page 20: Redundant Parallel Mode
In parallel system SLAVE UPS is not synchronized to MASTER UPS 3.4 Parallel System Accessories At standard XA-200P series there is no installed parallel components but they can install. For parallel opera- tion the following parts are necessary: • Parallel control board •... - Page 21 Neutral Ground AC INPUT DISTRIBUTION BOARD AC INPUT AC INPUT Battery Battery UPS 1 UPS 2 Input Input AC OUTPUT ANALOG / DIGITAL CABLES AC OUTPUT DISTRIBUTION BOARD LOAD NOTE : OUTPUT CONNECTIONS MUST BE OF EXACTLY THE SAME LENGTH. CAUTION : During operation do not turn off CB1 or CB2 , first turn off the UPS output switch then turn off the CB1 or CB2.
-
Page 22: Effects Of The Parallel Configuration On Xa-200P Series Ups
3.5 Effects of the parallel configuration on XA-200P series UPS If the parallel card is installed on a XA-200P series UPS some calibrations of the UPS will be changed. ( e.g.: output voltage and symmetry adjustment) Do not select ONLINE mode if the UPS is parallel configured, please select REDUNDANT MODE, in this case, if digital PARALLEL communication connector is not connected the UPS, it gives A28I PLUG IN DIG. -
Page 23: Ups Installation
IV. UPS INSTALLATION 4.1 Introduction WARNING!!! • Do not apply electrical power to the UPS equipment before the arrival of authorized service personnel. • The UPS equipment should be installed by a qualified service personnel. • The connection of the batteries and the maintenance should be done by the qualified service personnel. •... -
Page 24: Connecting The Ups Power Cables
4.4 Connecting The UPS Power Cables WARNING!!! A separate line should be used to supply the UPS AC input. Never use the same line to supply another electrical devices. Do not use any additional cable to increase the length of the UPS’s input cable. -
Page 25: Cable Connection Procedure
4.4.2 Cable connection procedure WARNING!!! All connections of the UPS must be done by a qualified service personal. After positioning the UPS, the cables must be connected as described below: 1. Verify all switches of the UPS in “0” position. 2. -
Page 26: Battery Installation
4.4.3 Battery Installation WARNING!!! Becareful while connecting batteries. ATTENTION!!! Remove the battery fuse before making the connection of the battery circuit breaker box dur- ing the battery installation. The batteries associated with the UPS equipment are usually contained in a purpose-built battery cabinet, which sits alongside the main UPS equipment. -
Page 27: Operating Instructions
V. OPERATING INSTRUCTIONS 5.1 First operating and Power ON : 1. Battery switch must be off. (“0” position) 2. MBS (Maintenance by-pass) switch must be in “0” position. 3. S1 switches must be in “1” position. 4. Turn S4 (Output) switch into “1” position. 5. -
Page 28: Maintenance
VI. MAINTENANCE WARNING!!! DO NOT OPEN the cover of the UPS because there is no part that can be maintained by the user. DO NOT TOUCH battery leads. There is high voltage even if the UPS is off. Therefore no one should open the cover of the UPS except the service personal. -
Page 29: Annual Maintenance
6.4 Annual maintenance To get reliable and efficient performance from the UPS, please call the qualified service personal once a year. 6.5 UPS Storage and transportation 1- Check the batteries charge by performing manual battery test before storage. If the charge is not enough then charge the batteries at least for 12 hours. -
Page 30: Faults And Troubleshooting
VII. FAULTS AND TROUBLESHOOTING 7.1 General procedure for fault checking and troubleshooting UPS contains complicated electronic control circuits. In order to locate any fault occurring circuits, an ad- vanced knowledge about the circuitry and its operation principles must be known. The aim of this section is to give the knowledge required at the first intervention. -
Page 31: Ups's Remote Control Connection
8.1 Using Serial Port A standart Serial communication port is installed to all XA-200P series UPS, by using this port user can take all information about UPS. All measured parameters, alarms can monitor by this port. This port is interactive and some commands for UPS is available these commands are listed below. -
Page 32: Hardware Configuration
8.3.1 Hardware Configuration All needs for modem connection is as follows: • PC with modem • WINDOWS 98 • Available UPS control software • DUMP modem which is connected to UPS The UPS, has AT command set to switch the DUMP modem into auto – answer mode. To perform this pro- cess go to COMMAND MENU and then goto ENTER:MODEM INIT subitem and press enter button for 3 sec- onds after installing the hardware. -
Page 33: Smart Modem (Sm) Configuration (Programming)
The configuration flow in Hyperteminal will be as follows: ATS0=1 <enter> OK answer from the modem AT&K0 <enter> OK answer from the modem AT&D0 <enter> OK answer from the modem AT&Y0 <enter> OK answer from the modem AT&N3 <enter> (US ROBOTICS ICIN) OK answer from the modem AT&W0 <enter>... - Page 35 AGKK9602 02/2014...
