Model # FSS60428RST-BAR
USE AND CARE GUIDE
REDWOOD VALLEY 5-PIECE FIRE PIT SET - BARE
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1
8 -
5 5
H -
D
H -
A
M
P
O T
N
HAMPTONBAY.COM
THANK YOU
We appreciate the trust and con dence you have placed in Hampton Bay through the purchase of th
. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Advertisement
Related Manuals for HAMPTON BAY REDWOOD VALLEY FSS60428RST-BAR
Summary of Contents for HAMPTON BAY REDWOOD VALLEY FSS60428RST-BAR
- Page 1 HAMPTONBAY.COM THANK YOU We appreciate the trust and con dence you have placed in Hampton Bay through the purchase of th . We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
-
Page 2: Table Of Contents
Table of Contents Pre-Assembly................3 Table of Contents ............2 Planning Assembly..............3 Safety Information ..............2 Product Caution ..............2 Hardware Included..............3 Safety Warnings ..............2 Chair Package Contents............4 Warranty ..............2 Fire Pit Package Contents............5 What is Covered.............. -
Page 3: Pre-Assembly
Pre-Assembly PLANNING ASSEMBLY Read all instructions before assembly. To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard. NOTE: More than one person may be required to complete the assembly of this product. HARDWARE INCLUDED NOTE: Hardware not shown to actual size. -
Page 4: Chair Package Contents
Pre-Assembly (continued) CHAIR PACKAGE CONTENTS Part Description Quantity t f e r i a Chair seat Support tube... -
Page 5: Fire Pit Package Contents
Pre-Assembly (continued) FIRE PIT PACKAGE CONTENTS Part Description Quantity Cover Barbecue grate Log grate Poker e r i HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance. -
Page 6: Chair Assembly
Chair Assembly Attaching the support tube to the legs Place the left leg (H) on a soft place. Attach the support tube (E) to the left leg (H) using M8x28 combination hex bolts (DD). Repeat the above steps to attach the right leg (G) to the support tube (E). Do not tighten all the bolts at this step. - Page 7 Attaching the connection bars to the legs Attach the two connection bars (F) to the right and the left leg (G & H) using M6x25 combination bolts (BB). Do not tighten all the bolts at this step. NOTE: Loosely tighten a ll the bolts using the he wrench (FF). HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
- Page 8 Attaching the support tube to the chair seat Attach the support tube (E) to the chair seat (D) using M8x28 combination hex bolts (DD). NOTE: Loosely tighten a ll the bolts using the wrench (GG).
- Page 9 Chair Assembly (continued) Attaching the chair seat to the right arm Attach the back of the chair seat (D) to the back of the right arm (A) and secure by an M6x15 combination bolt (AA). Attach the front of the chair seat (D) to the front of the right arm (A) using an M6x30 combination bolt (CC). Do not tighten all the bolts at this step.
- Page 10 Chair Assembly (continued) Attaching the chair seat to the left arm Repeat step 4 to attach the chair seat (D) to the left arm (B). Do not fully tighten all the bolts at this step.
- Page 11 Chair Assembly (continued) Attaching the chair back to the arms Turn the chair right side up. Attach the chair back (C) to the right and the left arm (A & B) using M6x25 combination bolts (BB). Once all of the bolts are in place, fully tighten all the bolts using the hex wrench (FF) and the wrench (GG). HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
- Page 12 Chair Assembly (continued) Checking the chair Place the seat cushion (I) and the back cushion (J) to nish the assembly of the chair. Ensure all connections are secure before use.
-
Page 13: Fire Pit Assembly
Fire Pit Assembly Attaching the table legs to the table top Place the table top (K) upside down on a soft surface. Attach the table legs (L) to the table top (K) using M6x25 combination bolts (BB) and plastic washers (EE). Do not fully tighten all the bolts at this step. - Page 14 Fire Pit Assembly (continued) Attaching the leg connector to the table legs Attach the leg connector (M) to the legs (L) using M6x25 combination bolts (BB). Once all of the bolts are in place, fully tighten the bolts using the hex wrench (FF).
-
Page 15: Care And Cleaning
Fire Pit Assembly (continued) Tightening all bolts and adding the fire pit Once all bolts are in place, fully tighten all bolts. Turn the table right side up. Carefully place the fire bowl (S) in the table rim (K). Then place the following in order, from bottom to top: the log grate (Q), the barbecue grate (P) and the lid (O) or the cover (N). When not in use, store the poker (R) under the log grate (Q). - Page 16 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use.
