Contents Introduction Inspection Safety Notes Notes on Use Measurement Flow Chart and Reference Guide viii Chapter 1 Product Outline 1.1 Name and Functions of Parts 1.2 Interval and Maximum Recording Time 1.3 Measurement Value Recording Modes 1.4 Leak Current Measurement 1.5 Load current measurement Chapter 2 Set Up 2.1 Replacing the Battery...
Page 5
Before using the product, make sure that the insulation on the sensor cables is undamaged and that no bare conductors are improperly exposed. Using the product in such conditions could cause an electric shock, so contact your dealer or Hioki representative for repair. ______________________________________________________________...
_____________________________________________________________________ Safety Notes This instrument is designed to conform to IEC 61010 Safety Standards, and has been thoroughly tested for DANGER safety prior to shipment. However, mishandling during use could result in injury or death, as well as damage to the instrument. Be certain that you understand the instructions and precautions in the manual before use.
Page 7
_____________________________________________________________________ The following symbols in this manual indicate the relative importance of cautions and warnings. Indicates that incorrect operation presents an extreme hazard that could result in serious injury or death to DANGER the user. Indicates that incorrect operation presents a significant hazard that could result in serious injury or WARNING death to the user.
Page 8
_____________________________________________________________________ Measurement categories (Overvoltage categories) To ensure safe operation of measurement product, IEC 61010 establishes safety standards for various electrical environments, categorized as CAT I to CAT IV, and called measurement categories. These are defined as follows. CAT I Secondary electrical circuits connected to an AC electrical outlet through a transformer or similar device.
_____________________________________________________________________ Notes on Use Follow these precautions to ensure safe operation and to obtain the full benefits of the various functions. This product cannot be used on following voltage lines. If the voltage exceeds, there will be a short-circuit DANGER accident or electrocution accident will result.
Page 10
_____________________________________________________________________ For model 9658 When conductors being measured carry in excess of DANGER the safe voltage level (SELV-E) and not more than 150 V, to prevent short circuits and electric shock while the clamp core jaw is open, make sure that conductors to be measured are insulated with material conforming to (1) Measurement Category III, (2) Pollution Degree 2, and (3) Basic Insulation Requirements for Working...
Page 11
_____________________________________________________________________ To avoid electric shock when measuring live lines, wear CAUTION appropriate protective gear, such as insulated rubber gloves, boots and a safety helmet. This product is designed for indoor use, and operates reliably from 0 to 50 . Do not store or use the product where it could be exposed to direct sunlight, high temperature or humidity, or condensation.
Measurement Flow Chart and Reference Guide Is there sufficient Replace batteries battery charge remaining See 2.1. to operate 3638-20? Set current time when using 3638-20 for the Setting current time first time or replacing batteries. See 2.3. Connecting sensor See 2.4. Setting 3638-20...
_____________________________________________________________________ Chapter 1 Product Outline 3638-20 LEAK LOGGER with clamp on leak sensor records 1 or 2 channels of data at leakage current value. It measures and records AC RMS current values of up to 1 Arms at fixed intervals.
_____________________________________________________________________ 1.1 Name and Functions of Parts 1. LCD Displays measurement value and settings. 2. Optical data transfer Enables optical data transfer to ports COMMUNICATION BASE. 3. INTERVAL button Calls up interval setting display to set interval, recording mode and measurement channels. 4.
1.2 Interval and Maximum Recording Time Interval and maximum recording time (when power save function is valid) are as follows. When 3638-20 LEAK LOGGER is used in 2 channels, maximum recordable data is 16000 per unit. INTVL Maximum Recording Time...
Page 16
_____________________________________________________________________ When 3638-20 LEAK LOGGER is used in 1 channel, maximum recordable data is 32000 per unit. INTVL Maximum Recording Time 8 h 53 min 20 s 17 h 46 min 40 s 1 day 20 h 26 min 40 s...
_____________________________________________________________________ 1.3 Measurement Value Recording Modes Effective value calculation To calculate effective value, measurement signal is sampled every 334 µs and operation is carried out from data with maximum 135 points to seek effective value. Maximum 135 points partitioned at complete cycle 334 µs Recording To record measurement value, calculate effective value per...
_____________________________________________________________________ 1.4 Leak Current Measurement Clamp the sensor on the conductor, so that the conductor passes through the center of the clamp core. For measurement of grounded leads, clamp the sensor on one lead only (see a). For overall measurements, clamp the sensor on the entire circuit path (see b).
Page 19
_____________________________________________________________________ If a strong current (on the order of 100 A) is flowing in an NOTE adjacent circuit, accurate measurement may not be possible. Perform the measurement at a sufficient distance from other current-carrying conductors. Do not input a current which exceeds the maximum continuous input rating.
_____________________________________________________________________ 1.5 Load current measurement Be sure to clamp only one lead of the conductor. Clamp so that the conductor is in the center of the sensor aperture. The frequency of special waveforms such as at the secondary NOTE side of an inverter can not be indicated correctly. When the current to be measured is unknown, begin measurement with the 1000 mA range selected.
_____________________________________________________________________ Chapter 2 Set Up 2.1 Replacing the Battery To avoid electric shock when replacing the batteries, first disconnect the connection cables from the object WARNING to be measured. During battery replacement, use caution not to put any foreign materials such as a metal object into the unit to avoid damage to the unit.
Page 22
_____________________________________________________________________ Installing new batteries ensures about one month of recording (when interval is set at 1 sec) and about 10 days of recording (when interval is set at 0.2 sec). (reference value with power save setting set to valid and at 20 ) Remaining battery power indicator ( ) indicates remaining battery life reducing incrementally from right.
_____________________________________________________________________ 2.2 Power Save Function Display window is automatically turned off in approximately 15 seconds after last key entry. (Sleep) However, while recording, REC/AV/ mark shows each conditions. Sleeping..Press any button to turn display on to display measurement value or to set settings. Note when interval setting display is on, sleep does not engage with no button press.
The 3638-20 measurement range is set at 100 mA, do not exceed 100 mArms. To avoid damaging the unit, do not use any other sensors except 9657/9658 CLAMP ON LEAK SENSOR as sensor connector.
Page 25
_____________________________________________________________________ Connecting clamp on leak sensor 3638-20 LEAK LOGGER enables 2 channels of data measurement when connected with 9657/9658 CLAMP ON LEAK SENSOR. 9657/9658 CLAMP ON LEAK SENSOR 9658 9657 Carefully read 9657/9658 CLAMP ON LEAK SENSOR NOTE instruction manuals before use.
Page 26
_____________________________________________________________________ Connecting 9632 CONNECTION CABLE Connecting 9632 CONNECTION CABLE to alarm output terminal.When connecting connection cable, securely insert connection cable to unit as designated by triangle mark ▲ on connection terminal. Improper connection results in failure to output accurate signal. 9632 CONNECTION CABLE 9632 CONNECTION CABLE White: Signal...
12. Comments Valid 13. Minimum/Maximum value Valid display ・When PC, COMMUNICATION BASE and 3638-20 are NOTE connected, separate range can be set in each channel. Once settings are set, range setting with manual operation sets common range. ・Alarm and comment setting are available when personal computer is connected to both logger and COMMUNICATION BASE.
Page 28
_____________________________________________________________________ 1. Start recording Start manual recording by pressing logger REC/STOP button for 1 second or initiate by prescheduled start set using COMMUNICATION BASE. When time scheduled start is engaged, clock icon appears in display. When batteries are weak, recording does not start.
Page 29
Select and set in accordance with measurement current. When manually operated, common settings apply to channel 1 and channel 2. When 3638-20 measurement range is set at 100 mA, do not exceed 100 mArms. When PC, COMMUNICATION BASE and 3638-20 are NOTE connected, separate range can be set in each channel.
Page 30
_____________________________________________________________________ 10. Recording mode setting With 3638-20 stand-alone, or connected together with COMMUNICATION BASE and PC, setting is available. Two recording mode options are maximum value recording and average value recording ( displayed). At factory shipment setting, average value recording is selected.
Page 31
Comment setting is available when personal computer is connected to both logger and COMMUNICATION BASE. 13. Maximum/Minimum value display 3638-20 stand-alone enables maximum/minimum value display settings. Maximum value or minimum value of recorded data is alternately displayed. ・Maximum value and minimum value are from data recorded in NOTE memory and may vary from each displayed value per second.
_____________________________________________________________________ 3.2 Manual Setting 3638-20 LEAK LOGGER stand-alone manual operation settings are shown below. (1) Interval setting Press button to switch measurement value INTERVAL display to interval setting display. ( appears.) INTVL Press button to designate interval. SELECT Press button to complete setting.
Page 33
_____________________________________________________________________ (4) Setting range Press button on monitor screen to select 100 100/1000 mA mA or 1000 mA. When measurement range is reselected, decimal point moves its position. When manual operation is conducted, common range settings apply to both channel 1 and channel 2. 100 mA range 1000 mA range (5) Starting and ending recording...
_____________________________________________________________________ 3.3 Setting by COMMUNICATION BASE 1. Press logger button lightly to display LCD. INTERVAL 2. When logger LCD shows mark or clock icon, press button for more than 1 second to stop REC/STOP recording. During recording or waiting time before recording start time, data transfer cannot be established with COMMUNICATION BASE.
Page 35
'3638-20' setting items to set settings. ・Comment, recording mode, measurement channel, measurement NOTE interval, range and alarm setting are only available in 3638-20 setting items. Personal computer, COMMUNICATION BASE and 3638-20 must be connected during setting. ・Common settings are available to be set in '3911-20, 3912-20' setting items.
_____________________________________________________________________ Chapter 4 Specifications Sensor types 9657/9658 CLAMP ON LEAK SENSOR Input AC voltage (AC25 mV/A) Maximum input AC35 mVrms, 50 mV peak value current Number of input 2 channels (1 or 2 channels settable) Measurement range 0 to 1000 mA Range structure 100.0 mA, 1000 mA Measurement method...
Page 38
_____________________________________________________________________ Recording start Manual start, Prescheduled start Recording stop Manual stop, Memory full Recording method One time, Endless Displaying Max/Min Displays maximum value and minimum value. value Alarm output Turns ON (open drain output) when value goes outside previously set upper limit or lower limit. Data backup Available (Data not erased by weak batteries or battery...
Service If the product seems to be malfunctioning, confirm that the batteries are not discharged, and that the sensor cables are not open circuited before contacting your dealer or Hioki representative. Error Messages The following error may be displayed on the LCD of the main instrument as shown below.
Page 40
_____________________________________________________________________ ______________________________________________________________ Maintenance and Service...
Page 43
HIOKI 3638-20 LEAK LOGGER Instruction Manual Publication date: June 2008 Revised edition 5 Edited and published by HIOKI E.E. CORPORATION Technical Support Section All inquiries to International Sales and Marketing Department 81 Koizumi, Ueda, Nagano, 386-1192, Japan TEL: +81-268-28-0562 / FAX: +81-268-28-0568 E-mail: os-com@hioki.co.jp...
Page 44
HEAD OFFICE 81 Koizumi, Ueda, Nagano 386-1192, Japan TEL +81-268-28-0562 / FAX +81-268-28-0568 E-mail: os-com@hioki.co.jp / URL http://www.hioki.com/ HIOKI USA CORPORATION 6 Corporate Drive, Cranbury, NJ 08512, USA TEL +1-609-409-9109 / FAX +1-609-409-9108 3638A981-05 08-06H Printed on recycled paper...
