AJAX -hub User Manual page 22

Tech Specs
Maximum number of connected devices
Maximum number of the groups
Maximum number of the Hub users
Maximum number of logical rooms
Power supply
Accumulator unit
Tamper protection
Frequency band
Effective radiated power
Modulation of the radiosignal
Radio signal range
Communication channels
Operating temperature range
Operating humidity
Overall dimensions
Weight
Certification
Warranty
Warranty for the "AJAX SYSTEMS MANUFACTURING" LIMITED
LIABILITY COMPANY products is valid for 2 years after the purchase and
does not apply to the pre-installed accumulator.
100
9
50
50
110 – 240 V AC, 50 / 60 Hz
Li-Ion 2 A⋅h (up to 15 hours of autonomous operation
inactive Ethernet connection)
Yes
868.0 – 868.6 MHz or 868.7 – 869.2 MHz depending
region of sale
8.20 dBm / 6.60 mW (limit 25 mW)
GFSK
Up to 2,000 m (any obstacles absent)
GSM 850/900/1800/1900 MHz GPRS, Ethernet
From -10°С to + 40°С
Up to 75%
163 х 163 х 36 mm
350 g
Security Grade 2, Environmental Class I SP2 (GSM-S
(LAN) DP3 in conformity with the requirements of EN
and EN 50136
