Icom IC-M87 Service Manual page 25

[MAIN UNIT]
REF ORDER
NO. NO.
C231 4030006860 S.CER C1608 JB 1H 102K-T
C232 4030007130 S.CER C1608 CH 1H 101J-T
C233 4030011600 S.CER C1608 JB 1E 104K-T
C234 4030011600 S.CER C1608 JB 1E 104K-T
C235 4030011600 S.CER C1608 JB 1E 104K-T
C236 4030006900 S.CER C1608 JB 1H 103K-T
C237 4030010760 S.CER C1608 CH 1H 331J-T
C238 4030010760 S.CER C1608 CH 1H 331J-T
C239 4550007270 S.TAN F931A475MAABMA
C240 4030006860 S.CER C1608 JB 1H 102K-T
C241 4030011600 S.CER C1608 JB 1E 104K-T
C242 4030006860 S.CER C1608 JB 1H 102K-T
C243 4030006860 S.CER C1608 JB 1H 102K-T
C244 4030006860 S.CER C1608 JB 1H 102K-T
C245 4030006860 S.CER C1608 JB 1H 102K-T
C246 4030011340 S.CER C1608 CH 1H 471J-T
C247 4030006860 S.CER C1608 JB 1H 102K-T
C251 4030006900 S.CER C1608 JB 1H 103K-T
C252 4030006900 S.CER C1608 JB 1H 103K-T
C253 4030006900 S.CER C1608 JB 1H 103K-T
C261 4030008860 S.CER C1608 JB 1H 153K-T
C262 4030008900 S.CER C1608 JB 1H 333K-T
C263 4030008920 S.CER C1608 JB 1H 473K-T
C265 4030006860 S.CER C1608 JB 1H 102K-T
C266 4030007150 S.CER C1608 CH 1H 151J-T
C267 4030006880 S.CER C1608 JB 1H 472K-T
C268 4030008920 S.CER C1608 JB 1H 473K-T
C269 4030006900 S.CER C1608 JB 1H 103K-T
C270 4030017490 S.CER C1608 JB 1A 105K-T
C271 4550007200 S.TAN F930J476MBABMA
C272 4030017480 S.CER C1608 JB 1A 474K-T
C281 4030006900 S.CER C1608 JB 1H 103K-T
C282 4030006900 S.CER C1608 JB 1H 103K-T
C291 4030006900 S.CER C1608 JB 1H 103K-T
C292 4030009880 S.CER C1608 JB 1H 682K-T
C293 4030008900 S.CER C1608 JB 1H 333K-T
C294 4030009970 S.CER C1608 JB 1H 182K-T
C301 4030008880 S.CER C1608 JB 1H 223K-T
C302 4030006870 S.CER C1608 JB 1H 222K-T
C311 4030006860 S.CER C1608 JB 1H 102K-T
C312 4030008880 S.CER C1608 JB 1H 223K-T
C313 4030009490 S.CER C1608 JB 1H 821K-T
C314 4030009490 S.CER C1608 JB 1H 821K-T
C315 4030011600 S.CER C1608 JB 1E 104K-T
C316 4030008920 S.CER C1608 JB 1H 473K-T
C322 4030006900 S.CER C1608 JB 1H 103K-T
C323 4030006900 S.CER C1608 JB 1H 103K-T
C324 4030006900 S.CER C1608 JB 1H 103K-T
C325 4550007360 S.TAN F931A226MBABMA
C326 4550007270 S.TAN F931A475MAABMA
C327 4550007270 S.TAN F931A475MAABMA
C333 4030006860 S.CER C1608 JB 1H 102K-T
C341 4030006900 S.CER C1608 JB 1H 103K-T
C381 4030017490 S.CER C1608 JB 1A 105K-T
C382 4030017490 S.CER C1608 JB 1A 105K-T
C383 4030017490 S.CER C1608 JB 1A 105K-T
C384 4030011600 S.CER C1608 JB 1E 104K-T
C385 4030011600 S.CER C1608 JB 1E 104K-T
C386 4030017490 S.CER C1608 JB 1A 105K-T
C387 4030017490 S.CER C1608 JB 1A 105K-T
C388 4030006900 S.CER C1608 JB 1H 103K-T
C389 4030006900 S.CER C1608 JB 1H 103K-T
C391 4030011600 S.CER C1608 JB 1E 104K-T
C392 4030007060 S.CER C1608 CH 1H 270J-T
C393 4030007060 S.CER C1608 CH 1H 270J-T
C394 4030007140 S.CER C1608 CH 1H 121J-T
C395 4030011600 S.CER C1608 JB 1E 104K-T
C396 4030017490 S.CER C1608 JB 1A 105K-T
C397 4030017490 S.CER C1608 JB 1A 105K-T
C398 4030007020 S.CER C1608 CH 1H 120J-T
J281 6510023541 CNR B2B-PH-K-S(LF)
J351 6510023520 S.CNR 54104-3692
F281 5210000951 S.FUS 0430001NR
W91 7030003860 S.RES ERJ3GE JPW V
W92 7030003860 S.RES ERJ3GE JPW V
W101 7030003860 S.RES ERJ3GE JPW V
W102 7030003860 S.RES ERJ3GE JPW V
W201 7030003860 S.RES ERJ3GE JPW V
W202 7030003860 S.RES ERJ3GE JPW V
EP2 6910012350 S.BEA MMZ1608Y 102BT
EP3 6910012350 S.BEA MMZ1608Y 102BT
EP101 6910013370 S.BEA BLM18BB221SN1D
EP111 6910014690 S.BEA MPZ1608S221A-T
DESCRIPTION M.
LOCATION
T 15.5/8.2
T 20.1/10.9
B
B 9.8/13.7
B
B 11.1/10.5
T
T 11.5/13.1
T 11.5/9.3
B 12.4/9.3
B 12.4/13.8
T 17.4/14.9
T 17.5/12.3
T 20.7/13.6
B 22.7/14.1
B 16.2/16.7
T
B
B 12.3/19.3
B 12.3/25.1
T 24.9/24.7
T 22.1/23.3
T 21.3/25.3
T 14.9/29.3
T 20.3/31.2
T 24.9/32.5
T 14.4/31.7
T 13.6/24.7
T 15.9/32.5
B 40.7/40.4
T
T 22.1/20.4
B
T
T 26.9/16.3
T 28.9/19.7
T 27.6/23.8
T 31.6/26.2
T 28.6/28.5
B 25.4/17.4
B 28.9/24.3
B 23.5/24.3
B 19.8/18.1
B
B 21.8/19.9
T 51.3/41.6
T
T
B 58.9/39.4
T 60.8/39.5
B 25.3/41.1
B 46.5/41.9
B 12.3/22.3
B 11.8/29.2
B 10.1/39.7
B
B
B 9.2/41.3
B 10.4/29.4
B 8.4/30.6
B
B
B 26.3/39.3
T 21.7/35.1
T
T
T 13.6/33.8
T 13.1/31.5
T 15.1/27.5
T
T 7.4/28.1
T 78.8/24.6
B 51.4/19.3
B 51.4/22.1
B 53.2/29.3
B 52.7/32.1
B 45.8/8.9
B 42.9/8.9
B 28.6/39.3
B 28.8/37.3
T 69.7/23.2
T 71.3/20.3
[VR UNIT]
H/V REF ORDER
NO. NO.
R801 7210003130
9.8/8.5
C801 4030006900
7.9/16 C802 4030006860
13.5/12
W801 8900011900
W802 8900012031
[CONNECTOR UNIT]
REF ORDER
17.4/11 NO. NO.
5.3/17
J851 6910015031
[CHASSIS UNIT]
REF ORDER
NO. NO.
J41 6910014700
20/16.1
70.5/31
SP1 2510001092
32.2/17
W1 7120000470
W2 7120000470
W3 7120000470
W41 8900011881
28.4/21
56/41
58/41.6
11.9/41
5/37.3
4.3/34
4.3/30
21.1/37
13/38.2
23.8/37
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
