- Page 1 4-SHELF BOLTLESS SHELVING UNITS MODEL NO: CSR4550BO Part No: 6600726 ASSEMBLY INSTRUCTIONS GC0516...
- Page 2 INTRODUCTION Thank you for purchasing this CLARKE Shelving Unit. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service.
- Page 3 INVENTORY Description Quantity Post Long Beam Short Beam Support Beam Shelf Metal Foot Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
- Page 4 ASSEMBLY ADVICE 1. Assemble on a strong, level surface. Avoid assembly on a domestic carpet. 2. Use a cloth or softwood block to protect the surface finish of the product when using a mallet. Strike the flat surface of each beam to prevent damage to the beam.
- Page 5 2. Use the short beams (C) to connect the front and rear posts together. • The edge with the wider flange should be installed uppermost to support the shelf. 3. Repeat this again to create the other end assembly, making sure that the corresponding beams are at the same height.
- Page 6 8. Lay the shelf panels (E) into position. • Always assemble the top shelf at the highest possible position. 9. We recommend that the racking be secured to an adjacent wall using typical wall insert plugs and screws (not supplied) aligned with the assembly slots in the posts.
- Page 7 SPECIFICATION Model Dimensions Weight Load per (W x D x H) (Empty) shelf (evenly distributed) CSR4550 Unit 1800 x 500 x 2000 mm 46 kg 550 kg GUARANTEE This product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase.
