  • Page 1 APAA00001 User Manual Issue Draft A Date 2015-06-12 HUAWEI TECHNOLOGIES CO., LTD.
  • Page 2 Notice The purchased products, services and features are stipulated by the contract made between Huawei and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information, and recommendations in this document are provided "AS IS"...

  • Page 3: About This Document

    APAA00001 User Manual About This Document About This Document Overview This document describes APAA00001, typical usage, software installation and operation, and method for using, operating, and maintaining APAA00001. Intended Audience This document is intended for:  Technical support engineers ...

  • Page 4: Table Of Contents

    4.3.1 Battery Fault ................................19 4.3.2 PAA Power-On/Off Failure ............................19 5 FCC Statements ........................... 21 5.1 Warning Statement FCC § 15.21 ..........................21 5.2 Statement FCC § 15.19 ............................... 21 Draft A (2015-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 5 5.3 FCC Radiation Exposure Statement: .......................... 21 5.4 IC RSS warning ................................21 A Appendix ............................. 23 A.1 Acronyms and Abbreviations ............................. 23 A.2 Alarm Codes ................................25 Draft A (2015-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 6: Introduction To Paa

    RS485/OOK signals so that ALDs can be controlled by using an app. APAA00001 can be used to control all types of Huawei ALDs. If the PAA is to be used with the ALDs supplied by peer vendors, you are advised to perform joint commissioning to confirm their compatibility with each other.

  • Page 7: Appearance Description

    204 mm x 88 mm x 30 mm x W x D) Material PC+ABS (30%) 1.3 Appearance Description 1.3.1 Appearance Figure 1-1 shows the appearance and dimensions of APAA00001. Draft A (2015-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 8 APAA00001 User Manual 1 Introduction to PAA Figure 1-1 Appearance and dimensions of APAA00001 Figure 1-2 APAA00001 appearance (1) AISG connection port (2) Strap hole (3) OOK connection port Draft A (2015-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 9 (4) Power supply indicator (5) Communication indicator (6) Alarm indicator (7) Power button (8) Mini USB port (9) 12 V DC adapter port Table 1-2 Ports on APAA00001 Port Description AISG connection Connects the PAA to an ALD using an AISG cable. port Strap hole Used to fasten straps so that the PAA can be carried easily.

  • Page 10: Accessory List

    APAA00001 User Manual 1 Introduction to PAA 1.3.2 Accessory List Table 1-4 lists the accessories of APAA00001. Table 1-4 Accessories of APAA00001 Accessory Quantity 12 V DC adapter 1 PCS AC power cable 1 PCS AISG 1-to-2 cable 1 PCS...
  • Page 11 Cable: complies with the UL2464 standard. Figure 1-4 AISG 1-to-2 cable N(M)-DIN(M) Adapter Figure 1-5 N(M)-DIN(M) adapter N(M)-DIN(F) Adapter Figure 1-6 N(M)-DIN(F) adapter RF Cable Figure 1-7 RF cable Draft A (2015-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 12 China standard Power is as shown in figure 1-8, According to the different delivery area, the cable will be different. Figure 1-8 AC power cable Strap Figure 1-9 Strap Draft A (2015-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 13: App Installation Guidelines

    PAA app after the scanning is successful.( Some browsers may have use restrictions can not download, can replace try different browsers). Figure 2-1 QR code of the PAA app Draft A (2015-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 14: App Download From The Website

    Visit the following URL using the web browser of your smartphone and download the PAA app: http://w3m-beta.huawei.com/m/Service/ClientDownloadServlet?osType=3&appId=258&flag The installation method is the same as that used when the QR code is scanned. Draft A (2015-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 15: Networking Guideline

    3.2.1 ALD Control over the AISG Port The AISG output port on the PAA is connected to the AISG input port on the ALD using an AISG cable, as shown in Figure 3-1. Draft A (2015-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 16: Ald Control Over The Ook Port

    3.2.2 ALD Control over the OOK Port The OOK port on the PAA is connected to the RF port on the ALD, as shown in Figure 3-2. Draft A (2015-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 17: Procedure

    The bluetooth device name of the PAA consists of PAA and the last eight characters of the bar code labeled on the back of the PAA. The bluetooth password is Draft A (2015-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 18 In actual application, the PAA app GUI may slightly vary with app versions. For details, see the online help of the app. Figure 3-5 Opening the online help of the PAA app Draft A (2015-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 19 APAA00001 User Manual 3 Networking Guideline Obtain the online help from the menu Draft A (2015-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 20: System Maintenance

    In this case, contact Huawei technical support to replace the battery.  The rechargeable battery inside the PAA is provided by the battery supplier specified by Huawei. If the battery needs to be replaced, contact Huawei technical support. Draft A (2015-06-12) Huawei Proprietary and Confidential...

  • Page 21: Paa Shell

    Background A hardware fault alarm is reported when the flash memory or I C bus inside the PAA is faulty. Table 4-1 describes the hardware fault alarm. Draft A (2015-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 22: Aisg/Ook Overcurrent Alarm Handling

    If the PAA communicates properly with the smartphone and the alarm is cleared after the restart, no further actions are required.  If the alarm persists, the PAA has been damaged. In this case, replace the PAA with a new one or contact Huawei technical support. ----End 4.2.2 AISG/OOK Overcurrent Alarm Handling Background...
  • Page 23 If the alarm is cleared, no further actions are required.  If the alarm persists, replace the PAA. If the alarm is cleared after the replacement, no further actions are required. If the alarm persists, contact Huawei technical support. ----End Draft A (2015-06-12) Huawei Proprietary and Confidential Copyright ©...

  • Page 24: Battery Not In Position Alarm Handling

    Procedure Contact Huawei technical support so that the PAA can be disassembled or returned to Huawei for maintenance. 4.3 Troubleshooting 4.3.1 Battery Fault  The battery may fail if any of the following conditions exists: The battery is fully recharged within 1 hour.
  • Page 25 4 System Maintenance  If the power button does not work for multiple times when the PAA is used, the button or the button spring may be faulty. In this case, contact Huawei technical support to replace the PAA. Draft A (2015-06-12) Huawei Proprietary and Confidential Copyright ©...

  • Page 26: Fcc Statements

    (1) this device may not cause interference, and (2) this device must accept any interference,including interference that may cause undesired operation of the device. Draft A (2015-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 27 This equipment complies with IC RF radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Draft A (2015-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 28: Aappendix

    AAppendix Appendix A.1 Acronyms and Abbreviations acrylonitrile-butadiene-styrene alternating current AISG Antenna Interface Standards Group antenna line device central processing unit direct current gigabit gigahertz graphical user interface Draft A (2015-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 29 User Manual AAppendix inter-integrated circuit International Electrotechnical Commission on-off-keying portable AISG adapter personal computer quick response code remote control unit radio frequency uniform resource locator Universal Serial Bus Draft A (2015-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 30: Alarm Codes

    0x30 Alarm code AISG/OOK Over An AISG/OOK overcurrent Current alarm is reported. 0x32 Alarm code Battery Not In Position A battery not in position alarm is reported. Draft A (2015-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
