Precaution!
The Powder Coating paint process has become the most
common widely used application in the outdoor furniture
category. Unfortunately powder coating is extremely
sensitive to Humidity and Moisture. A simple process to
protect your furniture, especially flat surfaces is to apply a
simple coat of good quality car wax prior to using. If this
process is done every few months it will protect your
furniture for years to come.
ANS Z83.26-2014 • CSA 2.37-2014 Gas-Fired Outdoor Infrared Patio Heaters
ATTACH YOUR RECEIPT HERE
Serial Number
Questions, problems, missing parts? For small parts please call 1-888-775-1330, 8 a.m. - 4
p.m., MST, Monday - Friday. For damaged product, you may have to return to the retailer.
Purchase Date
1
OWNER'S MANUAL
OUTDOOR FIRE PIT TABLE
MOD EL # F-1201-FPT
DANGER
WARNING:
WARNING
AZPH-ABEST
For Outdoor Use Only
WH17/01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Premium Series and is the answer not in the manual?

Questions and answers

Related Manuals for Hiland Premium Series

Summary of Contents for Hiland Premium Series

  • Page 1 OWNER’S MANUAL OUTDOOR FIRE PIT TABLE MOD EL # F-1201-FPT AZPH-ABEST DANGER WARNING: For Outdoor Use Only Precaution! The Powder Coating paint process has become the most WARNING common widely used application in the outdoor furniture category. Unfortunately powder coating is extremely sensitive to Humidity and Moisture.
