5.2 - Monitor Matrix Switcher
Hardware
Connect the outputs from the mixer to the inputs of the DriveRack Studio.
1.
2. Connect the outputs of the DriveRack Studio and run to the selected speaker amplifier.
3. Make sure that the mixer and power amps are turned off prior to powering up the
DriveRack Studio.
Software
1. Once the desired program has been chosen, press the DATA wheel to load the program.
Left
Right
Left
Right
Left
Right
Left
Right
Monitor 1
Monitor 2
Monitor 3
®
DriveRack Studio User Manual
31
