DriveRack Studio
Introduction
Drive your Studio to a whole new level of performance with the DriveRack ® Studio Complete
INTRODUCTION
Equalization & Loudspeaker Control System. The DriveRack Studio from dbx Professional
Products represents a complete integration of the key elements that help ensure optimal loud-
speaker system management in Studio-specific applications.
While the DriveRack was originally designed as an equalization and loudspeaker control sys-
tem for PA applications, we found that it can also provide a host of essential functions in home,
project and professional studio applications. In addition to the obvious equalization and com-
pression functionality, the DriveRack Studio can help you tune your room, switch between up
to three pairs of studio monitors, and (if you don't have the luxury of multiple pairs of moni-
tors) provide you with several different "Studio Monitor Emulation" templates. These templates
allow you to hear your mixes as you would through everything from a small 5" speaker though
traditional midfield monitors and beyond!

0.1 Defining the DriveRack Studio

The dbx DriveRack Studio is the most effective way to manage all aspects of Loudspeaker man-
agement for Studio applications. The DriveRack Studio essentially becomes the only device that
you will need for optimizing the playback monitoring in any studio. The following are just
some of the features of the DriveRack Studio.
DriveRack Studio features:
• Dual 28-band Graphic EQ
• Classic dbx ® Compressor
• 120A Sub-harmonic Synthesizer
• 2x3, 2x4, 2x5, 2x6 Crossover Configurations
• Stereo Multi-band Parametric EQ
• Stereo Output Limiters
• Pink Noise Generator
• Auto-EQ with 28-Band RTA
• JBL ® Speaker and Crown ® Power Amp Tunings with Setup Wizard
• 24 User Programs / 24 Factory Programs
• 2 Channel XLR Input and 6 Channel XLR Output
• Front panel RTA-M XLR input with phantom power
• 24-Bit ADC/24-Bit DAC, >110 dB Dynamic Range
• TypeIV ® Conversion System
• Full Graphic LCD Display
®
