Specifications - Terex Genie Z-34/22 IC Operator's Manual

Seventh Edition • First Printing

Specifications

Z-34/22 2WD Industrial and RT
Height, working maximum
Height, platform maximum
Height, stowed maximum
Horizontal reach, maximum
Width
Length, stowed
Maximum load capacity
Maximum wind speed
Wheelbase
Turning radius (outside)
Turning radius (inside)
Ground clearance
Turntable rotation
Turntable tailswing
Platform leveling
Platform rotation
Controls
Platform dimensions
(length x width)
Power source Kubota D1105 Diesel
Fuel capacity
AC outlet in platform
Hydraulic pressure, maximum
(boom functions)
System voltage
Part No. 1297940GT
40 ft 6 in 12.5 m
34 ft 6 in 10.5 m
6 ft 7 in 2 m
22 ft 3 in 6.8 m
5 ft 8 in 1.7 m
18 ft 6 in 5.6 m
500 lbs 227 kg
28 mph 12.5 m/s
6 ft 2 in 1.9 m
13 ft 1 in 4 m
5 ft 9 in 1.8 m
6 in 15 cm
355°
0 in 0 cm
self-leveling
180°
12V DC Proportional
56 in x 30 in
1.4 m x 76 cm
26 hp
GM .998L G/LPG 29.6 hp
9.3 gallons 35.2 liters
Standard
3200 psi 221 bar
12V
Z
Tire size (foam filled only)
Highest root mean square value of weighted acceleration
to which the whole body is subjected does not exceed
2
0.5 m/s .
Weight
(Machine weights vary with option configurations. See
serial label for specific machine weight.)
Drive speed, maximum
Boom stowed
Boom raised or extended
Maximum slope rating, stowed position, 2WD
Platform downhill
Platform uphill
Side slope
Note: Slope rating is subject to ground conditions with
one person in the platform and adequate traction.
Additional platform weight may reduce slope rating.
Ambient operating temperature
Airborne noise emissions
Sound pressure level at ground workstation
Sound pressure level at platform workstation
Guaranteed sound power level
Floor loading information
Tire load maximum
Tire contact pressure
(per tire)
Occupied floor pressure
Note: Floor loading information is approximate and does
not incorporate different option configurations. It should
be used only with adequate safety factors.
Continuous improvement of our products is a Genie
policy. Product specifications are subject to change
without notice or obligation.
®
-34/22 IC
Operator's Manual
Specifications
10-16.5 NHS
3.0 mph 4.8 km/h
40 ft/9 sec 12.2 m/9 sec
0.7 mph 1.0 km/h
40 ft/40 sec 12.2 m/40 sec
37%
20%
25%
-20° F to 120° F
-29° C to 49° C
81 dBA
80 dBA
105 dBA
5300 lbs 2404 kg
100 psi 7.03 kg/cm
689 kPa
221 psf 10.58 kP
1079 kg/m
20°
11°
14°
2
a
2
51
