Service and Repair Manual
Z
-60 DC
®
Z
-60 FE
®
Serial Number Range
from Z60H-2548
from Z60M-1000
This manual includes:
Repair procedures
Fault Codes
Electrical and
Hydraulic Schematics
For detailed maintenance
procedures, refer to the
appropriate Maintenance
Manual for your machine.
Original Instructions
Part No. 1307785GT
Rev B
August 2022
