Summary of Contents for ITT Industries Flygt 3067
- Page 1 Installation, Care and Maintenance 3067 892397/08...
-
Page 2: Table Of Contents
CONTENTS Safety Operation __________________________________ 2 ______________________________ 11 Data plate interpretation Care and maintenance ________________ 3 _________________ 12 Product description Oil change ____________________ 4 _____________________________ 13 General design of a Flygt pump Available motors _________ 5 ______________________ 14 Installation Hydraulic ends ____________________ ______________________________ 6 Electrical connections Dimensions and weights ____________... -
Page 3: Data Plate Interpretation
DATA PLATE INTERPRETATION General data plate Serial number Product code + Number Curve code / Propeller code Country of origin Product number Additional information Phase; Type of current; Frequency Rated voltage Thermal protection Thermal class Made in Germany Rated shaft power International standard Degree of protection Rated current... -
Page 4: Product Description
PRODUCT DESCRIPTION Introduction General technical data Thank you for buying a submersible Flygt pump. In Liquid temperature: max. 40°C (104°F). The pump this Installation, Care and Maintenance manual you can be operated at full load only if at least half the will find general information on how to install and stator housing is submerged. -
Page 5: General Design Of A Flygt Pump
GENERAL DESIGN OF A FLYGT PUMP Design The pump is a submersible, electric motor-driven The motor can be run continuously or intermittently product. with a maximum of 15 evenly spaced starts per hour. Flygt motors are tested in accordance with IEC 34-1. 1. -
Page 6: Installation
INSTALLATION Handling equipment Safety precautions Lifting equipment is required for handling the pump. In order to minimize the risk of accidents in connection with the service and installation work, the following rules should be followed: 11. Never work alone. Use a lifting harness, safety —... -
Page 7: Electrical Connections
ELECTRICAL CONNECTIONS — Before starting work on the All electrical work shall be carried out under the super- pump, make sure that the pump vision of an authorized electrician. is isolated from the power supply Local codes and regulations shall be complied with. and cannot be energized. - Page 8 ELECTRICAL CONNECTIONS Monitoring equipment Remember that the starting current in direct on-line starting can be up to six times higher than the rated The FLS sensor consists of a small float switch for current. Make sure that the fuses or circuit breakers sensing water in the stator housing.
-
Page 9: Cable Chart
CABLE CHART T1 T2 SUBCAB (7GX+2×1.5) 3-phase, direct-on-line, ∆ ∆ ∆ ∆ ∆ 3-phase, direct on-line starting Conductors Connection starter Conductors Connection starter SUBCAB 7Gx 1 black SUBCAB 4Gx 1 brown ***red 2 black ***SUBCAB xAWG/4 2 blue ***white 3 black HØ7RN-F 4Gx 3 black ***black 4 black... - Page 10 CABLE CHART 3-phase, star-delta starting Single phase Conductors Connection starter Conductors Connection starter SUBCAB 7Gx 1 black SUBCAB 4Gx 1 brown ***red SO7E6E5-F 7x2.5 2 black ***SUBCAB xAWG/4 2 black ***black 3 black HØ7RN-F 4Gx 3 blue ***white 4 black BIHF 4Gx yellow/green earth...
-
Page 11: Transportation And Storage
TRANSPORTATION AND STORAGE The pump can be transported and stored in a vertical A frozen impeller can be thawed by allowing the pump or horizontal position. to stand immersed in the liquid for a short period before it is started. Never use a naked flame to thaw the pump. -
Page 12: Care And Maintenance
CARE AND MAINTENANCE Inspection Before starting work on the pump, make sure that the pump is isolated Regular inspection and preventive maintenance from the power supply and cannot ensure more reliable operation. be energized. The pump should be inspected at least once a year, This applies to the control circuit but more frequently under severe operating as well. -
Page 13: Oil Change
OIL CHANGE A check of the condition of the oil can show whether there has been leakage. Note! Air/oil mixture can be confused with water/oil mixture. Insert a tube (or hose) into the oil hole. Cover the top end of the tube and take up a little oil from the bottom. Change the oil if it contains too much water, i.e. -
Page 14: Available Motors
AVAILABLE MOTORS Motor For version with product code: 3067 .090 .180 .250 .590 .690 .170 .890 50 Hz 1.2 kW 2840 rpm × × × × × × × 60 Hz 1.4 kW 3400 rpm × × × × × ×... -
Page 15: Hydraulic Ends
HYDRAULIC ENDS... - Page 16 HYDRAULIC ENDS...
-
Page 17: Dimensions And Weights
DIMENSIONS AND WEIGHTS 3067.090 .180 All dimensions in mm (in). - Page 18 DIMENSIONS AND WEIGHTS 3067.090 .180 All dimensions in mm (in).
- Page 19 DIMENSIONS AND WEIGHTS B/D 3067.250 .590 .690 All dimensions in mm (in).
- Page 20 DIMENSIONS AND WEIGHTS 3067.170 .890 All dimensions in mm (in).
- Page 21 DIMENSIONS AND WEIGHTS All dimensions in mm (in). 3067.090 .180 All dimensions in mm (in).
-
Page 22: Service Log
SERVICE LOG Most recent Pump No. Hours of Remarks Sign. service date operation... - Page 24 www.flygt.com...
