Projector Parts

Control panel
Lamp cover
Speaker
Air exhaust vent
Audio input ports
Monitor
out port
Computer
input ports
Audio
out port
S-Video
port
Video input port
Power inlet
Rear adjustable foot

Specifications

General
Type of display
Poly-silicon TFT active matrix
×
Resolution
1024
(native format)
Color
Full color, 16.8 million colors
reproduction
Brightness
3,500 lumens (high brightness)
2,700 lumens (low brightness)
Contrast ratio
500:1
Image size
30 to 300 inches (0.8 to 7.6 meters)
(diagonal)
Projection
2.7 to 48.2 feet (0.8 to 14.7 meters)
distance
Wireless
Remote
module
receiver
(1815p only)
Zoom ring
Focus ring
A/V mute slide
Foot adjust lever
USB port type B
Network port (1815p only)
USB port type A
(1815p only)
Audio input ports
Remote receiver
768 pixels (XGA)
Projection
Front, rear, upside-down (ceiling mount)
methods
Internal
5 W monaural
sound system
Optical aspect
4:3 (horizontal:vertical)
ratio
(supports 16:9)
Zoom ratio
1:1.6
Noise level
32 dB (low brightness)
37 dB (high brightness)
Keystone
±30° vertical (automatic)
correction
±45° vertical (manual)
±45° vertical (Quick Setup)
±25° horizontal (manual/Quick Setup)
Mouse
Supports USB (type B)
compatibility
Projection Lamp
Type
UHE (Ultra High Efficiency)
Power
210 W
consumption
Lamp life
Approx. 3,000 hours (low brightness)
Approx, 2,500 hours (high brightness)
Part number
V13H010L40
Remote Control
Range
20 feet (6 meters)
Batteries (2)
Alkaline AAA
Dimensions
Height
3.4 inches (86 mm), feet retracted
Width
13.6 inches (345 mm)
Depth
10.1 inches (257 mm)
Weight
PowerLite 1810p: 6.5 lb (2.9 kg)
PowerLite 1815p: 6.9 lb (3.1 kg)
Electrical
Rated frequency
50/60 Hz AC
Power supply
100 to 120 VAC, 3.4A
200 to 240 VAC, 1.5 A
Power consumption
Operating:
100 to 120 VAC, 306 W
220 to 240 VAC, 286 W
Standby
(network off):
100 to 120 VAC, 2.6 W
220 to 240 VAC, 4.6 W
3/08
PowerLite 1810p/1815p
PowerLite 1810p/1815p
1
-
