Video
Controls the execution of UEFI and Legacy Video OpROM.
Other PCI devices
Determines OpROM execution policy for devices other than Network, Storage, or Video.
NCT6106D Hardware Monitor
This screen monitors hardware health status.
This screen displays the temperature of system and CPU, cooling fans speed in RPM and
system voltages (VCC_CPU, DDR, +12V, +5V and +3.3V).
CPU FAN = FAN1; SYS FA = FAN2; AUX FAN = FAN3 .
Note
AMI BIOS Setup Utility
IMB523 / 524 / 525 LGA1151 ATX Motherboard
37
