- Page 1 Alfatron Electronics GmbH Germany www.alfatronelectronics.com ALF–EXT60IR HDMI over Cat Extender...
-
Page 2: Safety Precaution
ALF-EXT60IR Statement Please read this user manual carefully before using the product. The functions described in this version are updated as of March 2021. In the constant effort to improve our product, we reserve the right to make functions or parameters changes without notice or obligation. Safety Precaution ... -
Page 3: Fcc Statement
ALF-EXT60IR FCC Statement This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. It has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. - Page 4 ALF-EXT60IR markings. By reusing, recycling or other forms of utilisation of old devices you make an important contribution to the protection of our environment. Please contact your local authorities for details about collection points.
-
Page 5: Package Contents
ALF-EXT60IR Introduction The Alfatron EXT-60IR extends HDMI signal between Transmitter and Receiver over CAT6 cable. It supports 1080p@60Hz video signals up to 50m including embedded multi-channel audio and HDCP 1.4. Built-in EDID makes this product compatible with most display and source devices, to ensure HDMI transmission. -
Page 6: Panel Description
ALF-EXT60IR Panel Description Transmitter (TX) RESET HDMI OUT HDMI IN DC 5V CAT OUT IR IN IR OUT ① CAT OUT: RJ45 connector with Green and Yellow indicators. Connect to Receiver over CAT6 cable. The Green indicator lights up when powered on. The Yellow indicator lights up when linked between Transmitter and Receiver successfully. -
Page 7: Connection Diagram
ALF-EXT60IR Receiver (RX) HDMI OUT SYNC CAT IN IR IN IR OUT ① CAT IN: RJ45 connector with Green and Yellow indicators. Connect to Transmitter over CAT6 cable. ② IR IN: Connect with IR Receiver. ③ IR OUT: Connect with IR Emitter. ④... -
Page 8: Specifications
ALF-EXT60IR Specifications Transmitter Receiver Input (1) HDMI (1) CAT (1) 19-pin type-A Input Connector (1) RJ45 female HDMI Output (1) HDMI, (1) CAT (1) HDMI (1) 19-pin type-A (1) 19-pin type-A Output Connector female HDMI, female HDMI (1) RJ45 Control (1) IR IN, (1) IR OUT (1) IR IN, (1) IR OUT (2) 3.5mm mini... - Page 9 ALF-EXT60IR Warranty 1.1 This limited warranty covers defects in materials and workmanship in this product. 1.2 Should warranty service be required, proof of purchase must be presented to the Company. The serial number on the product must be clearly visible and not have been tampered with in any way whatsoever. 1.3 This limited warranty does not cover any damage, deterioration or malfunction resulting from any alteration, modification, improper or unreasonable use or maintenance, misuse, abuse, accident, neglect,...
- Page 10 ALF-EXT60IR including, without limitation, the technology and/or integrated circuit(s) included in the product, will not become obsolete or that such items are or will remain compatible with any other product or technology with which the product may be used. 1.5 Only the original purchaser of this product is covered under this limited warranty.
- Page 11 ALF-EXT60IR proper claim under this limited warranty: 1.10.1 Elect to repair or facilitate the repair of any defective parts within a reasonable period of time, free of any charge for the necessary parts and labour to complete the repair and restore this product to its proper operating condition.;...
- Page 12 ALF-EXT60IR 1.13 Please be aware that the Company’s products and components have not been tested with competitor’s products and therefore the Company cannot warrant products and/or components used in conjunction with competitor’s products. 1.14 The appropriateness of the goods for the purpose intended is only warranted to the extent that the goods are used in accordance with the Company’s installation, classification and usage instructions.
