- Page 1 ALFATRON ELECTRONICS GmbH GERMANY ALF-TPUK150-RS 18Gbps HDMI over HDBaseT Extender with Bi-directional IR (150M) VER 1.0...
- Page 2 ALF-TPUK150-RS Preface For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lightning strikes, etc.
-
Page 3: Table Of Contents
ALF-TPUK150-RS Table of Contents Introduction ...................... 1 Features ......................1 Package Contents ..................2 Specifications ....................3 Operation Controls and Functions ............5 Transmitter Panel ..................5 Receiver Panel ..................6 IR Pin Definition ..................8 Application Example ................. ..10 After Sales …………………………………………………………………...11... -
Page 4: Introduction
ALF-TPUK150-RS 1. Introduction This ALF-TPUK150-RS is an 18Gbps HDMI Extender that can extend high-definition video/audio signal, RS-232, and bi-directional IR at distances of up to 492ft / 150 meters between the transmitter and receiver via a single CAT 6 cable. It supports resolution up to 4K2K@60Hz 4:4:4, 18Gbps and HDCP 2.2. -
Page 5: Package Contents
ALF-TPUK150-RS 3. Package Contents Item TPUK150 Transmitter TPUK150 Reciever IR Emitter cable (1.5 meters) 20 ~ 60KHz IR Receiver cable (1.5 meters) Mounting Ears 3-pin Phoenix connector 24V/1A Locking Power adapter User Manual / 13... -
Page 6: Specifications
ALF-TPUK150-RS 4. Specifications Technical HDCP Compliance HDCP 2.2 / HDCP 1.4 Video Bandwidth 18Gbps 4K2K 50/60Hz 4:4:4 4K2K 50/60Hz 4:2:2 4K2K 50/60Hz 4:2:0 Video Resolution 4K2K 30Hz 4:4:4 1080p, 1080i, 720p, 720i, 480p, 480i All HDMI 3D TV formats All PC resolutions including 1920 x 1200... - Page 7 ALF-TPUK150-RS Inputs: 1x HDBT IN [RJ45, 8-pin female] Outputs: 1x HDMI Type A [19-pin female] 1x AUDIO OUT [3.5mm Stereo Mini-jack] Receiver Control: 1x IR IN [3.5mm Stereo Mini-jack] 1x IR OUT [3.5mm Stereo Mini-jack] 1x RS-232 [Phoenix jack] 1x SERVICE [Mini-USB, Update port]...
-
Page 8: Operation Controls And Functions
ALF-TPUK150-RS 5. Operation Controls and Functions Transmitter Panel Name Function Description Power LED Red LED indicates that the transmitter is powered. SERVICE port Firmware update port. DC 24V/1A power supply input port. Note that the extender supports PoC function, which means... -
Page 9: Receiver Panel
ALF-TPUK150-RS IR output port for control of source device. This IR output 10 IR OUT signal is from the IR IN port of the receiver. 3-pin Phoenix connector for RS-232 command 11 RS-232 transmission. The RS-232 command will pass through from the transmitter to the receiver or from the receiver to the transmitter. -
Page 10: Ir Pin Definition
ALF-TPUK150-RS 7 HDMI OUT HDMI output for display. AUDIO OUT 3.5mm stereo connector for analogue audio output. IR IN IR input port for receiving the signal of IR remote. IR output port for control of display device. This IR output 10 IR OUT signal is from the IR IN port of the transmitter. - Page 11 ALF-TPUK150-RS The following is an IR system diagram about the IR cable use method. Note: When the angle between the IR receiver and the remote control is ± 45°, the transmission distance is 0 - 5 meters; when the angle between the IR receiver and the remote control is ±...
-
Page 12: Application Example
ALF-TPUK150-RS 6. Application Example / 13... -
Page 13: After Sales
1) Product Limited Warranty: Alfatron warrants that its products will be free from defects in materials and workmanship for seven years, which starts from the first day of purchase. -
Page 14: Warranty
ALF-TPUK150-RS 8.Warranty 1 This limited warranty covers defects in materials and workmanship in this product. 1.2 Should warranty service be required, proof of purchase must be presented to the Company. The serial number on the product must be clearly visible and not have been tampered with in any way whatsoever. - Page 15 ALF-TPUK150-RS 1.9 A 7 (seven) year limited warranty is given on the aforesaid product where used correctly according to the Company’s instructions, and only with the use of the Company’s components. 1.10 The Company will, at its sole option, provide one of the following three remedies to...
- Page 16 ALF-TPUK150-RS 1.16 If delivery is not refused, and the Customer does not notify the Company accordingly, the Customer may not reject the goods and the Company shall have no liability and the Customer shall pay the price as if the goods had been delivered in accordance with the Agreement.
